- Page 1 THE MANUAL: AURORA ENVIRONMENTAL VSN-ENVIRO-ENTRY Model Number: VSN-ENVIRO-CMML...
- Page 2 Internet is connected properly and verify that the data in being received. The Aurora Environmental is SunSpec compliant and uses a 2-wire half duplex serial port for Modbus communication to a host. Contact Power-One if you need to modify or program the unit or change the Modbus address.
- Page 3 Aurora Environmental Installation Overview AE-Commercial Vane for Wind Ambient Speed and Direction Temperature Sensor Second Pyranometer (For Solar Panel Plane) Pyranometer Connector Case Mounting PV Panel Mast Temperature Sensors AE-Entry Pyranometer Ambient Temperature Sensor Mounting Connector Case Mast PV Panel...
-
Page 4: Installation Steps
We supply: You supply: Aurora Environmental Appliance, Mounting Hardware which includes: Tripod or pole mount base Aurora Environmental Weather Station Guy wire kit, if necessary PV Panel Temperature Sensor 24VDC Power Second Pyranometer (Commercial Model Only) Twisted Pair Wires Second PV Panel Temperature Sensor (Commercial Model Only) Site Selection and Mounting The ideal site is level and well away from obstructions such as buildings, tress, and steep slopes. - Page 5 Lining up the two holes in each mast prevents rotation. At this point the entire unit should be secured to the support structure. It is crucial that the device be oriented as precisely as possible. For the Commercial version, the wind direction measurement is directly related to this positioning.
-
Page 6: Sensor Mounting Requirements
Sensor Mounting Requirements The pyranometer is attached to the sensor assembly and is oriented to measure global irradiance. To Global Irradiance accurately measure this quantity the sensor must be level, orientated either TRUE SOUTH or TRUE NORTH if you are in the northern or southern hemisphere, respectively, and objects above 10° above the horizontal plane must not block the sensor. - Page 7 This sensor is designed to attach directly to any solar panel. When PV Temperature Sensors placed on the center back side of the panel, it accurately measures the temperature of the panel. Prior to installation of the PV temperature sensor onto the PV panel, the installation area of the panel back should be thoroughly cleaned.
- Page 8 Wiring Instructions for the Aurora Environmental Run wire from the 24VDC power source to the weather station. Supply 24VDC Power Find the back of the connection case on the weather station. Unscrew the four retaining screws at the corners with a Philips screwdriver. See the figure below.
-
Page 9: Southern Hemisphere Adjustment
24VDC Connectors: Earth GND 24VDC Power Commercial Entry Leave the case open to install the other wires as described in the next section. Weather Station Electronics Board For the Commercial model, if you are in the southern hemisphere, the jumper at J11 must be set to Southern Hemisphere Adjustment Southern. - Page 10 Jumper J8: Jumper Common to On: RS485 Termination Jumper Common to Off: No RS485 Termination RS485 Connectors: RS-485 A (-) RS-485 B (+) RS-485 GND RS-485 Shield Commercial Entry The default address of the weather station is 60. Contact Customer Support if it is required to change Weather Station Electronics Board, Jumper for RS485 Termination the address.
- Page 11 Connect Second Pyranometer PV Panel Temperature Sensor Connect Second PV Panel Temperature Sensor The Pyranometer sensors are not interchangeable. The secondary sensor must be wired to Weather Station Electronics Board, Connect Secondary Sensors (Commercial Model) Pyranometer #2. The PV sensors are not polarity sensitive. Therefore, each signal wire is interchangeable. The sensor comes with a 25ft length of cable.
- Page 12 PV Panel Temperature Sensor The PV sensor is not polarity sensitive. Therefore, each signal wire is interchangeable. The sensor Connect PV Panel Sensor (Entry Model) comes with a 25ft length of cable. If a temperature sensor is not used, it should be terminated with a 0-ohm shunt between the positive and negative signal.
-
Page 13: System Activation And Validation
This section shows how to tap the 24VDC power and make RS485 connections from an Aurora Connections to Aurora Universal Universal management system. Most other monitoring systems will have a means of supplying 24VDC power. Consult your monitoring system documentation for information. -
Page 14: Specifications
If you are using Aurora Environmental in conjunction with Prime Edition software, go to and log in to Prime Edition with your account name and password. Using your product license key, set up the connection to Aurora Environmental appliance. www.auroravision.net... -
Page 15: Hardware Specifications
Hardware Specifications Power Requirements: 10 to 30VDC at 50mA Power Specifications: Temperature: -40°C to 60°C (-40 to 140°F) Operating Environment: Humidity: 0-100% Condensing Range: 0 to 1750 W/m Pyranometer Sensors: Accuracy: +/-5% Cosine Response 45° +/-1% Cosine Response 75° +/-5% Operational Temperature: -25 to 55°C (-13 to 131°F) Range:... - Page 16 Customer Support E-mail: www.power-one.com service.us@power-one.com ©2011, 2012 Power-One Corporation. Power-One is a registered trademark and Aurora Vision is a trademark of Power-One Corporation. All rights reserved. All other brand or product names are trademarks or registered trademarks of their respective holders.
- Page 17 ® Power Service China +86 755 2988 5888 Aurora Power Service Singapore +65 6896 3363 ® Aurora Power Service Malaysia +603-8025 9963 ® Release NA1.0 - Aurora ® is a trademark by Power-One - Product is subject to technical improvements...
