Light & Motion 2005 Owner's Manual

2005 bike light
Hide thumbs
Table of Contents

Advertisement

Quick Links

2005 Bike Light Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2005 and is the answer not in the manual?

Questions and answers

Related Manuals for Light & Motion 2005

Summary of Contents for Light & Motion 2005

  • Page 1 2005 Bike Light Owner’s Manual...
  • Page 2 Congratulations on your decision to purchase a Light & Motion Bicycle Lighting System. Prepare yourself to leave your car at home, rediscover your old stomping grounds and ride your bike year round. Please join us in viewing the world in a different light. To get the maximum satisfaction from your Light &...
  • Page 3 CAUTION - Bicycling in the dark is an inherently dangerous activity and no lighting system will guard you against inattentive motorists or other night time hazards. When not in use, ALWAYS unplug the light head from the battery. When unplugging the light head cable from the battery, always pull the connector, not the cable.

  • Page 4: Warranty And Repair Information

    Warranty Light & Motion offers a 30 day warranty on all lamps and a 90 day warranty on all batteries.All other facets of Light & Motion systems carry a one year warranty against manufacturer defects. Returning Products for Warranty Evaluation, or Repair: Should your system malfunction for any reason, contact the Light &...

  • Page 5: Table Of Contents

    Table of Contents Warranty and repair information ........4 ARC Li-ion parts identification .

  • Page 6: Arc Li-Ion Parts Identification

    Light & Motion ARC Li-ion and Li-ion Ultra HID system parts identification Please verify the contents of your Light & Motion lighting system. 1. Lithium ion Turbo Charger 2. 11.1v Li-ion battery 3. 11.1v Ultra Li-ion battery 4. ARC Li-ion HID light w/ bar mount 5.

  • Page 8: Arc Nimh Parts Identification

    Light & Motion ARC NiMH HID system parts identification 1. NiMH Turbo Charger 2. 10.8v NiMH Slimline battery 3. ARC HID light w/ bar mount 4. Handle bar mount w/ spacers 5. Cabeza helmet mount 6. Slimline battery frame mount with bomber strap 7.

  • Page 10: Solo Logic Li-Ion And Nimh Parts Identification

    Light & Motion Solo Logic Li-ion and NiMH Mv system parts identification A) Solo Logic Li-ion 1. Solo Logic Mv light w/“Lefty” wing mount 2. Handle bar mount w/ spacers 3. Cabeza helmet mount 4. Hook and loop bomber strap 5.

  • Page 12: Commuter Parts Identification

    Light & Motion Commuter parts identification 1.Trickle Charger 2. 7.2v NiMH battery 3. Commuter light w/ bar mount 4. Handle bar mount w/ spacers 5. Hook and loop bomber strap 6. Spare break-away disks (2)

  • Page 14: Vega Parts Identification

    Light & Motion Vega LED system parts identification 1.Vega wall charger 2.Vega light w/ bar mount 3. Handle bar mount w/ spacers 4. Spare break-away disks (2)

  • Page 15: Charging Your Battery Using The Turbo Charger

    Charging your battery using the Turbo Charger The Light & Motion Turbo Charger is a universal input system that will work on any wall voltage from 90-260 volts. Depending on the outlet style you may require an adapter to plug the charger into the wall outlet. Charging the battery using the Li-ion Turbo Charger.
  • Page 16 4) After approximately 2 hrs and 45 min. both the yellow and the green LED lights will be illuminated, this indicates the battery is 80% charged. 5) After an additional 2 hrs the battery will be fully charged and only the green LED on the left side will be liluminated. Two flashing LED lights indicate an error.
  • Page 17 Charging the battery using the NiMH Turbo Charger. Always fully charge your battery before its first use. Batteries are shipped partially charged and must be fully charged to achieve the proper run time. Note: NiMH batteries require approximately 5-10 charge and discharge cycles to reach full capacity.
  • Page 18 Two flashing LED lights indicate an error. If this happens, please remove the battery and unplug the Turbo Charger from the wall and wait about 5 minutes. Then try to charge the system again. The NiMH Turbo Charger will charge a fully depleted battery in approximately 3.5 hours.

  • Page 19: Charging The 7.2V Nimh Battery Using The Trickle Charger

    Charging the 7.2v NiMH battery using the trickle charger Always fully charge your battery before its first use. Batteries are shipped partially charged and must be fully charged to achieve the proper run time. Note: NiMH batteries require approximately 5-10 charge and discharge cycles to reach full capacity.

  • Page 20: Installation Of Light Head And Battery

    Installation of light head and battery Installing light head assembly Your Light & Motion Light head comes pre-assembled with the bar style mount attached to the light head. 1) Determine the best location for your handle bar mount as it relates to your specific brake/shifter bar layout. Ideally, the bar mount should be attached to the right and as close to the stem as possible.

  • Page 22: Bar Mounted Light Break-Away Disk Replacement

    Bar mounted light break-away disk replacement The multiple adjustability of the bar mount and light head allow it to resist varying degrees of impact. If the light head receives a hard enough impact, it is designed to break away from the mount, thus protecting the main components. If broken, remove the Phillips head screw from the underside of the bar mount and replace the break away disc (2 additional disks are included).Align the track on the disc with the cut out...

  • Page 23: Installing The Strap On The 7.2V Nimh And Li-Ion Battery

    Installing the strap on the 7.2v NiMH and 11.1v Li-ion battery Before mounting the battery to the frame you will need to first attach the supplied hook and loop strap to the battery. 1) Feed the strap through the slot on the side of the battery with the hook side facing outward.

  • Page 24: Installing The Strap On The 10.8V Nimh And 11.1V Ultra Battery Mount

    Installing strap on the 10.8v NiMH and 11.1v Ultra battery mount Before mounting the 10.8v NiMH, or 11.1v Ultra Li-ion battery to the frame you will need to first attach the supplied hook and loop strap to the battery mount. Feed the strap through the slot on the side of the battery mount with the hook side facing outward.

  • Page 25: Installing Battery On Frame

    Installing battery on frame 1) Press the side of the battery with the groove against the frame tube, or seat post. 2) Hold the battery between your thumb and fingers with the buckle oriented flush against the side of the battery near the top.Wrap the strap around the frame tube.

  • Page 26: Attaching The Light Head To The Battery

    Attaching the light head to the battery Plug the light head cable into the socket on top of the battery by aligning the arrow on the cable with the arrow, or colored (red, or yellow) dot on the top of the battery.You may choose to loosely coil the excess cable around the frame.

  • Page 27: Mounting The Light Head To The Cabeza Mount

    Mounting the light head to the Cabeza mount 1) Remove the Phillips head screw from the bottom of the handlebar mount 2) Remove both the small and large break-away disc. 3) The optional Cabeza mount comes fully assembled. Remove the Phillips head screw from the Cabeza mount. 4) Align the track on the disk with the cut out on the light head.

  • Page 28: Mounting The Cabeza Light Head

    Mounting Cabeza Light Head The Cabeza mount is designed to be mounted on any standard, vented bicycle helmet. Position the base of the light head on top of the helmet, in the middle and slightly forward of center. Slide the hook and loop strap down through the proper vent, back up through the opposing vent and through the slot in the base of the light head.

  • Page 29: Arc And Arc Li-Ion Hid Light Operation

    ARC and ARC Li-ion HID light operation The Light & Motion ARC HID lights all have one switch on the back of the head that controls power. Pushing it quickly twice turns the light on; the light starts in the 13w high mode. The light takes approximately 20 seconds to come to full strength;...

  • Page 30: Arc Nimh Low Battery Warning And Discharge Protection

    ARC NiMH low battery warning and discharge protection The ARC NiMH HID also incorporates a low battery warning mode. If the battery capacity drops below a certain threshold, or becomes discharged, the light head will automatically go into the lowest power setting and the LED will begin to flash quickly.

  • Page 31: Arc Hid Run Times

    ARC HID Run Times Power Level Watts Burn Time 10.8v NiMH Burn Time 11.1v Li-ion Burn Time 11.1v Li-ion Ultra High 13.5 3:00 3:30 3:00 4:00 4:50 6:05...

  • Page 32: Solo Logic Mv Light Operation

    Solo Logic Mv light operation The Light & Motion Solo Logic Mv light has one switch on the top of the head that controls power. Pushing it quickly twice turns the light on. The light turns on in the 13w mode; pushing the button again causes the light output to be reduced in 1/3 increments (10w and 7w respectively).

  • Page 33: Solo Logic Run Times

    Solo Logic Mv Run Times Power Level Watts Burn Time 7.2v NiMH Burn Time 10.8v NiMH Burn Time 11.1v Li-ion Burn Time 11.1v Li-ion Ultra Note: When using the Lithium-Ion battery the Low Battery Warning time will be extended to bwtween 15-40 minutes and the period before auto shut off will decrease to 30 seconds.

  • Page 34: Commuter Light Operation

    Commuter Light Operation The Light & Motion Commuter light has one switch on the top of the head that controls power. Pushing it once turns the light on; pushing it again turns it off Hint: The light head pans horizontally on the bar mount. With use the attachement point may loosen up.

  • Page 35: Vega Led Light Operation

    Vega LED Light Operation The Light & Motion Vega LED light has one switch located at the rear of the light. To turn the light on, push it quickly twice. The light turns on in the 4w mode; pushing the button again causes the light output to be reduced in 1/3 increments (2w and 1w respectively.) Pushing the button again in the low mode causes the Vega to go into the flash mode.

  • Page 36: Charging The Vega

    Charging the Vega The Vega comes with its own proprietary Light & Motion universal input charger which will work with any wall current from 90-260v. WARNING: Using any other charger will void the warranty and could be extremely dangerous. To charge the Vega, plug the charger pack into the appropriate wall socket, then remove the charger port plug from the bottom of the light.

  • Page 37: Lamp Replacement

    Lamp replacement ARC HID Lamp All lamp replacements for ARC systems must be performed by the Light & Motion service department.The front bezel is not designed to be rotated or removed. Tampering or removing the front bezel will void the warranty. If for any reason the front bezel is removed or the glass port breaks, DO NOT TOUCH the exposed lamp.
  • Page 38 by turning clockwise until tight. You can then turn the bezel counter-clockwise until the desired beam pattern is achieved. Commuter Halogen Lamp Disconnect the light head from the battery and allow lamps to cool before removing. Orient the light head facing upward and remove the bezel by rotating it counterclockwise.
  • Page 39 Light & Motion 300 Cannery Row • Monterey, CA 93940, USA 831-645-1538 • www.bikelights.com 905-0246-A...

This manual is also suitable for:

Arc li-ionArc li-ion ultra hidArc nimh hidSolo logic li-ionSolo logic nimh mvCommuter light ... Show all
