Princeton Vizz Operating And Maintenance Instruction

Led headlamp

Advertisement

ENGLISH

Battery Installation - See Figure 1

3 AAA
• Alkaline (LR03)
• Lithium (L92)
• Rechargeable NiCad or NiMH
PrincetonTec cares about the environment
and recommends recycling batteries. For
more information about battery recycling,
please go
to www.batteryrecycling.com.
Observe proper battery polarity. Improper
installation of the batteries will damage the
light and void the warranty.
WARNING
• Never mix fresh and used batteries.
• Never mix different battery brands or
chemistry types.
• Always remove drained batteries
immediately.
• Remove batteries during long periods of
storage.
NOTE: Lithium batteries offer extended con-
stant brightness time, extreme cold weather
performance, and lighter weight. Rechargeable
NiCad or NiMH batteries may result in reduced
brightness due to lower nominal voltage.
The Vizz battery compartment has a wa-
terproof seal. It is important to keep this
seal free from dirt and away from harsh
chemicals in order to preserve waterproof
integrity. Inspect the seal every time batteries
are changed. If dirt is present, wipe gently
with a damp cotton swab and mild soap until
dirt is removed.
Switch Operation -
See Figure 2
Ultrabright Red and Maxbright White modes
are selected via short button presses. Single
press turns on Ultrabright Red. Double press
turns on Maxbright White. Ultrabright White
mode is selected by holding button. Ultra-
bright White mode starts at lowest bright-
ness level; intensity increases until button is
released. If button is held continuously, light
intensity will scroll up and down until button
is released. If another brightness is desired
after button has been released, holding but-
ton will resume scrolling through Ultrabright
intensity levels.
A single press more than two seconds after
the previous button press will turn light off.
From off state, triple press will lock light to
prevent accidental turn on and resulting bat-
tery drain.The Indicator LED (located inside
the power button) will blink three times to
confirm lock.Triple press from the locked
state will unlock the light and the indicator
Figure 1 – Battery Replacement
1
Figure 2 – Switch Operation
SINGLE PRESS
RED ULTRABRIGHT LEDs
DOUBLE PRESS
MAXBRIGHT LED
TRIPLE PRESS
LOCK OUT
Princeton Tec calculates total burn time as the time it takes for the light source to produce a minimum of
0.25 lux at 2 meters. 0.25 lux is about the equivalent of a full moon on a clear night.
Princeton Tec berechnet die Gesamtbrenndauer bezogen auf eine von der Stirnlampe erzeugte minimale
Beleuchtungsstärke von 0,25 Lux in 2 Meter Abstand. 0,25 Lux entsprechen in etwa der Beleuch-
tungsstärke des Vollmonds in einer klaren Nacht.
Princeton Tec défi nit la durée totale d'éclairage comme le temps nécessaire à la source
lumineuse pour produire un minimum de 0,25 lux à 2 mètres. 0,25 lux équivaut à peu près à la
luminosité d'une pleine lune dans un ciel nocturne dégagé.
LED will flash to confirm unlock. Removal and
replacement of batteries will also reset Vizz to
unlocked state.

Troubleshooting

If the Vizz fails to light:
• Check the batteries for proper installation.
• Replace batteries if proper installation is
confirmed.
• Check circuit board for water (the seal may
have been compromised by improper rear
cover installation or dirty seal).The light will
resume normal operation once the water
is shaken or blown out and the light is left
open until completely dry. If the light has
been contaminated with salt water, flush
the unit with fresh water and dry as
described above.

Low Battery Indicator

The Low Battery Indicator is a red LED located
inside the power button. When Vizz is turned off
with approximately 20% of battery power re-
maining, this indicator LED will flash for around
12 hours. NOTE:The indicator LED only flashes
when headlamp is turned off, and will not blink
while headlamp is turned on. Flashing ceases
when the headlamp is locked out.
USA Lifetime Warranty - International
10-YearWarranty
Due to International regulations, Princeton
Tec's lifetime warranty can only be offered to
customers in the USA. PrincetonTec offers a
10-year warranty to our customers outside
the USA. FULL WARRANTY - PrincetonTec
warrants this product to be free from defects
in workmanship and materials under normal
use for as long as you own this product.This
warranty covers all of the component parts
of the product except batteries.This warranty
does not cover deterioration due to normal
wear or damage due to misuse, alteration,
Remplacement des piles
2
3
Modes de fonctionnement
HOLD
WHITE ULTRABRIGHT LEDs
(LOW)
SINGLE PRESS
TURNS LIGHT OFF
ULTRABRIGHT RED LEDs
ULTRABRIGHT WHITE
150H
23
negligence, accidents, or unauthorized repair.
PrincetonTec will repair or replace parts
which are defective In workmanship or mate-
rials.Your authorized PrincetonTec Dealer and
PrincetonTec are the only facilities authorized
to repair the product. After (3) unsuccessful
attempts to repair the product, you have the
right to elect replacement of the product or a
refund of the purchase price less allowance
for use of the product. NO INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARE INCLUDED
INTHIS WARRANTY. (Some states do not
allow the exclusion or limitation of incidental
or consequential damages, so the above limi-
tations or exclusions may not apply to you.)
This warranty gives you specific legal rights,
and you may also have other rights which
vary from state to state.
PrincetonTec reserves the right to change
product specifications without notice.

Return Policy

If your light fails to operate, follow these
simple steps:
1) Check batteries. Replace if necessary.
2) Contact PrincetonTec customer service at
800-257-9080 to request an RMA number in
order to send your light for repair or replace-
ment. No warranties will be accepted without
an RMA number.
3) If the light continues to function improp-
erly, return it without batteries to: Princeton
Tec, 5198 Rt. 130 Bordentown, NJ 08505.
Postage due and freight collect items will not
be accepted.
PrincetonTec
PO Box 8057 ,
Trenton, NJ 08650
Phone: 609-298-9331
Fax: 609-298-9601
Batteriewechsel
4
Schalterbetätigung
(HIGH)
MAXBRIGHT LED
DIMMABLE LEDs
160H
110H
39
90
www.princetontec.com
© 2012 PrincetonTec
