Summary of Contents for RED 585-160
- Page 1 HDMI DVD Player Model 585-160 / SKU 121665201(online) 110-240V~ 50/60Hz FOR HOUSEHOLD AND INDOOR USE ONLY Please read these instructions before use and retain for future reference Region code...
- Page 2 SAFETY • PLACE THE APPLIANCE ON A FLAT, STABLE SURFACE WITH ADEQUATE VENTILATION AND AWAY FROM OTHER SOURCES OF HEAT. MINIMUM DISTANCES AROUND THE APPLIANCE FOR ADEQUATE VENTILATION IS 10CM. DO NOT COVER OR RESTRICT VENTILATION OPENINGS. • CHILDREN SHOULD BE SUPERVISED TO ENSURE THEY DO NOT PLAY WITH THE APPLIANCE, AND THE APPLIANCE AND CABLE SHOULD BE KEPT COMPLETELY OUT OF REACH OF YOUNG CHILDREN.
-
Page 3: Dvd Player
COMPATIBILITY EXPLANATION OF DVD SYMBOLS This DVD player is compatible with the following disc types Region code 8 & 12cm Single sided, single and doubled layered Dolby Digital Surround 8 & 12cm Double sided, single layered Number of Audio Tracks CD –... -
Page 4: Remote Control
REMOTE CONTROL Remote Control - functions ON / Standby function Power ( ) Step Frame advance Goto Goes to a specific play time / point on a DVD 0 – 9 Number entry buttons Repeat Accesses the repeat play mode Return Returns to the disc menu Video... -
Page 5: Connecting Dvd Player
Remote control - use To use the remote control unit, insert batteries into the battery compartment of the remote control unit. Ensure that the POWER buttons on the TV and DVD player are switched on. Point the infrared transmitter on the remote control towards the remote control sensor on the DVD player and press the function button of choice. - Page 6 CONNECTING DVD PLAYER - continued Television To HDMI input HDMI Cable (not included) To HDMI output AC 110-240V~ 50/60Hz,10W VIDEO VIDEO OUT CAUTION ! ALL EQUIPMENT MUST BE TURNED OFF AND DISCONNECTED FROM THE MAINS BEFORE INSTALLATION CONFIGURE THE TV The DVD player is set to UK PAL TV type as standard;...
-
Page 7: Playing A Disc
PLAYING A DISC Playing a disc - DVD 8.1.1 Switch on the DVD player at the mains (the blue power light will illuminate), turn on the TV and amplifier (if connected) and press the POWER ( ) button. 8.1.2 Press the OPEN / CLOSE ( ) button (‘open’ will appear on the TV screen) and insert a disc (label side up). For a double-sided disc place the disc with the A/1 up. -
Page 8: Step Function
Playing a disc – picture CD 8.3.1 Switch on the DVD player at the mains (the blue power light will illuminate), turn on the TV and amplifier (if connected) and press the STANDBY ( ) button. 8.3.2 Press the OPEN / CLOSE button (‘open’... -
Page 9: Zoom Function
REPEAT PLAY FUNCTIONS (in play mode) 11.1 To repeat a DVD chapter, title or CD track continuously, press the REPEAT button. • Press the REPEAT button ONCE, to repeat the same DVD chapter or CD track continuously. • Press the REPEAT button TWICE to repeat the DVD title or all tracks of the CD continuously. •... - Page 10 QUICK ACCESS BUTTONS MENU Press the MENU button to display DVD root, CD or picture CD menu and select the desired option. Press the button again to resume play. TITLE Press the TITLE button to return to the DVD title menu and select the desired option. SET UP Press the SETUP button to display the set up menu.
-
Page 11: Setting The Parental Lock
SETTING THE PARENTAL LOCK Some DVD’s have a parental level assigned to the complete disc or particular scenes on the disc. This feature allows the viewing limit to be set and settings are region specific. To activate the parental settings 20.1 Press the SETUP button, use the UP / DOWN buttons ( ) to display the RATING menu. -
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Observation Potential cause / solution No power (blue front panel Is the power lead connected to the mains socket correctly? light does not come on) Does the socket that is being used have power? Blue front panel light does This is normal.
