Summary of Contents for HotZone HZE-1500W
- Page 1 Schaefer HotZone™ Electric Patio Heater Infrared Heater - High Output INSTALLATION & OPERATION INSTRUCTIONS HZE-1500W HZE-1500P ® 41344 800-779-3267 sales@schaeferfan.com • www.schaeferfan.com ©2008 Schaefer Ventilation Equipment...
-
Page 2: Specifications
Specifications Congratulations on purchasing a Schaefer HotZone™ Electric Patio Heater. Your new heater should give you many years of maintenance-free comfort. Unlike forced air heaters, HotZone™ heaters have no moving parts and warm people and objects, but not the air, with infrared radiation. -
Page 3: Installation Notes
Installation Notes When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all instructions before installing and using this heater. • Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, elecric shock, or injury to persons. -
Page 4: Wall-Mounting Bracket
The heater does NOT include hardware for attaching the mounting bracket to the wall. 1. Use the four Phillips head screws removed above to attach the junction HZE-1500W Wiring Schematic box cover. (Figure 1) (see page 6 for instructions) 2. Remove the mounting bracket from the hardware bag. -
Page 5: Pedestal Assembly
HZE-1500P Installation PEDESTAL ASSEMBLY The unit should be assembled in an area where it can be tipped down. 3. Insert the power cord through the 5. Insert the power cord through the 1. Insert the power cord through the other identical pole (lower end has top pole (lower end has threads on hole in the center of the base and threads on the outside). -
Page 6: All Models
Wiring Instructions (all models) ** HZE-1500W The power cord MUST be attached to the heater BEFORE the unit is secured to the wall. ** ** HZE-1500P The power cord MUST be attached to the heater AFTER it is secured to the pedestal. **... -
Page 7: Maintenance And Troubleshooting
Maintenance & Troubleshooting MAINTENANCE • The heater body can be washed with gentle detergent and a soft wash cloth. Do not use a pressure washer. With an air hose regulated to 30 psi, blow off any dust and dirt from in front of the heater that has accumulated on the reflective surfaces of the heater and reflective lens. -
Page 8: Element Replacement
Always disconnect the heater from the main electrical supply during installation and/or replacement of the heater element. Remove the heater from the wall bracket (HZE-1500W) by removing the two bolts, washers and nuts from the bracket. (Figure 2 and Figure 5) - Page 9 Element Replacement cont'd Loosen the four screws that hold the element in the frame. Remove the used Figure 8 - Element in frame element. (Figure 9) slides in/out of housing. Lay the new element into the frame. Center it and then tighten the four screws to hold it in place.
-
Page 10: Warranty
Warranty Schaefer Ventilation Equipment, LLC. warrants to the original purchaser that our products which prove to be defective in material or workmanship within one year (unless otherwise specified) from date of purchase will be repaired or replaced at the option of Schaefer Ventilation Equipment, LLC. F.O.B. Sauk Rapids, Minnesota. Products with warranty periods that differ from the stated one-year warranty are listed below.
