PANTONE 072 C
PANTONE 123 C
DISPOSAL
• Please respect the environment!
• Dispose of the packaging according to the local recycling regulations.
• Dispose of the appliance at the end of its life span according to environmental considerations.
DECLARATION OF CONFORMITY
Easylife Group Ltd
11-13 King's Terrace
London
NW1 0JP
Declares that the following product
EL5820 10-in-1 Steam Mop
Are in conformity with the provisions of the following EC Directives, including all amendments and with
national legislation implementing these directives:
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
The following standards are applied:
EN 60335-2-10: 2003+A1:2008
EN 60335-2-54:2008
EN 60335-1:2012
EN 62233:2008
EN 50564:2011
This product carries the CE Mark.
WARNING
This product is intended for domestic use only.
TECHNICAL SPECIFICATION
Handle: Spilt design, steam button in handle Water Tank: Removable, 360ml capacity
Voltage: 220-240V Output Power: 1500W Waterproof Level: IPX4
Steam Output: Full tank will last around 20 minutes intermittent use.
Imported and distributed by Easylife Group Ltd, London NW1 0JP
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
IN5820-1 © 2014 Easylife Group Ltd
10-in-1 Steam Mop
INSTRUCTION MANUAL
Steam
through
101
cleaning
jobs
Model No. EL5820
Please read carefully before use and keep for future reference
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
Advertisement
Table of Contents
Related Manuals for Easylife EL5820
Summary of Contents for Easylife EL5820
- Page 1 Voltage: 220-240V Output Power: 1500W Waterproof Level: IPX4 Model No. EL5820 Steam Output: Full tank will last around 20 minutes intermittent use. Please read carefully before use and keep for future reference Imported and distributed by Easylife Group Ltd, London NW1 0JP Customer service: 0871 855 6100 For more innovative products from Easylife please visit: www.easylifegroup.com Customer service: 0871 855 6100 IN5820-1 ©...
- Page 2 • Injuries caused by touching any moving parts. • D o not pull or carry by the cord, do not use the cord as a handle, close the door on the cord, pull cord around sharp corners or expose cord to heated surfaces. • Injuries caused by touching any hot parts. • D o not use appliance in an enclosed space filled with vapour given off by oil-base paint thinner, some • Injuries caused when changing any parts or accessories. moth-proofing substances, flammable dust, or other explosive or toxic vapours. • I njuries caused by prolonged use of the appliance. When using any appliance for prolonged periods • D o not use on leather, wax polished furniture or floors, synthetic fabrics, velvet or other delicate, ensure you take regular breaks. steam-sensitive materials. Customer service: 0871 855 6100 For more innovative products from Easylife please visit: www.easylifegroup.com...
- Page 3 Round Brushes fridges, etc. carpet fibres 6. WINDOW SQUEEGEE (C) – Streak free window, glass and mirror cleaning Stove tops, taps, tile grout, Angle Nozzle microwaves, sinks, hard to 7. ANGLE NOZZLE (G) – Clean sink holes, small gaps and hard to reach corners reach places. 8. MICROFIBRE CLOTH (L) – Lifts grease and stubborn stains from clothes and fabrics Cleaning all grout lines, sanded 9. SCRAPING TOOL (I) – Steam and scrape away dried on dirt in tight spaces Grout Cleaner or non-sanded 10. GROUT CLEANER (H) – Clean grout between floor and wall tiles Scraping baked on food, grime Scraping Tool and grease. Removing residue or other difficult substances. For use when steaming Microfibre Cloth garments, tablecloths, etc. For general cleaning of hard Microfibre Floor Cleaner floors and refreshing carpets Customer service: 0871 855 6100 For more innovative products from Easylife please visit: www.easylifegroup.com...
- Page 4 Method one: O pen the water tank by turning the knob anti-clockwise and fill 360ml of water using the Handle measuring cup (J). Replace the knob by turning clockwise to close water tank (see Fig 3). Push the spindle button (1) and fully extend the handle (2) until it clicks into place See Fig 1. Method two: R emove the water tank from main body, open the water tank by turning the knob anti- clockwise. Fill the water tank from a tap the then replace the knob by turning it clockwise (see Fig 4). FIG. 3 FIG. 1 FIG. 4 2. Plug in the steam mop into the mains outlet. 3. W hen you switch the appliance on the indicator LED lights will turn red at the each side of water tank, this will indicate the water in the tank is pre-heating. 4. I t will take approximately 25 seconds for preheating to complete. Once the steam mop is ready to use the water tank will glow blue. Customer service: 0871 855 6100 For more innovative products from Easylife please visit: www.easylifegroup.com...
- Page 5 Cleaning Microfibre Floor Cleaner Machine washable on “warm” setting. Always use a mild detergent. For best care results lay flat to dry. PLEASE MAKE SURE THAT THE APPLIANCE IS DISCONNECTED FROM THE MAINS POWER IMPORTANT: A llow the steamer to fully cool down before performing any maintenance or OUTLET WHEN CLEANING THE MOP AND ACCESSORIES. DRAIN ANY REMAINING WATER IN THE TANK AND CLEAN THE TANK AFTER EVERY USE. troubleshooting checks. Please use detergent to clean the accessories (Jet Nozzle and Round Brush) when they are dirty then IMPORTANT: N ever use bleach or fabric softener when washing the microfibre floor cleaner. wash with clean water and dry How to descale the Water Tank To clean calcium deposits / lime scale that builds up inside the water tank, add one or two tablespoons of white vinegar to a full water tank. Close the water tank cap and then shake the contents. DO NOT TURN THE STEAMER ON. Customer service: 0871 855 6100 For more innovative products from Easylife please visit: www.easylifegroup.com...
- Page 6 Reduced steam or no steam Water tank may be empty or low Fill water tank to its max level Main body Steam nozzle may be blocked Clean steam nozzle There is no power to the Make sure the appliance is appliance plugged in Steam is not coming out as required Turn the steam knob clockwise to increase the volume of steam Appliance will not turn on Fuse may have blown Replace fuse and / or reset circuit breaker in your home Handle cavity Power cord not plugged in Try plugging appliance into a working circuit Customer service: 0871 855 6100 For more innovative products from Easylife please visit: www.easylifegroup.com...
