Summary of Contents for Smartplanet SmartSolar
- Page 1 SmartSolar™ Solar Power Kits For Automatic Technology Openers SmartPlanet Solutions INSTALLATION INSTRUCTIONS | OWNERS COPY...
- Page 2 Automatic Technology (Australia) Pty Ltd Product in accordance with these installation instructions. SmartSolar™ Installation Instructions & Owners’ Manual...
-
Page 3: Table Of Contents
SmartSolar™ Solar Power Kits For Automatic Technology Openers Important Safety Instructions SmartSolar™ Features Package Contents Charger Board Layout Installing the Solar Panel Swing Gate Opener Set Up Sliding Gate Opener Set Up Overhead Door Opener Set Up ® Roll Up Door Opener Set Up (GDO-6 EasyRoller Roll Up Door Opener Set Up (GDO-8 EasyRoller ®... -
Page 4: Important Safety Instructions
DO NOT connect any other source of power to the opener if a SmartSolar™ kit is installed. DO NOT use the SmartSolar™ kit to power other devices - it is specifi cally designed for Automatic Technology door and gate openers and some accessories only. -
Page 5: Smartsolar™ Features
SmartSolar™ Features Thank you for purchasing the SmartSolar™ solar power kit for Automatic Technology opener products. The unique and exciting new technologies of SmartSolar™ makes cost effective green or remote location automation a reality. Using only quality components and materials, this product will provide years of smart, simple and secure operation. -
Page 6: Package Contents
Package Contents SmartSolar™ Kit (Fig. 01) SmartSolar™ Solar Power Kits For Automatic Technology Openers Solar Panel - 30 Watt STP030-12/Lb Battery Pack (2 X 12Ah) Charger Board (with harness) SmartPlanet Solutions 2.5 meter two core cable INSTALLATION INSTRUCTIONS | OWNERS COPY fi... - Page 7 30 watt solar panel. J5 Connector 30watt jumper this jumper has to be on both pins of j5 connector for 30watt solar panel and must be removed for 20 watt solar panel. Installation Instructions & Owners’ Manual SmartSolar™...
-
Page 8: Installing The Solar Panel
GDO-9 SecuraLift® overhead door opener, proceed to Page 11 connecting GDO-6 EasyRoller ® roll up door opener, proceed to Page 12 connecting GDO-8 EasyRoller ® roll up door opener, proceed to Page 12 SmartSolar™ Installation Instructions & Owners’ Manual... -
Page 9: Swing Gate Opener Set Up
“OPEN” and CLOSE” buttons. Setup travel limits and transmitters as per the DCB- 05 instruction manual. Press either “OPEN” or “CLOSE” buttons, or use a transmitter to operate the gate. Refi t the Control Box’s cover. Installation Instructions & Owners’ Manual SmartSolar™... -
Page 10: Sliding Gate Opener Set Up
® ESV-24 EasySlider & ESV-24MS EasySlider PLEASE NOTE: CB-11 fi rmware must be v0.65 or higher for SmartSolar™ compatibility WARNING: Do not connect the batteries until Step B5 is completed. Step B4 - Mount the Charger Board Unplug the drive unit from mains power. -
Page 11: Overhead Door Opener Set Up
Overhead Door Opener Set Up GDO-9 SecuraLift ® PLEASE NOTE: Control board fi rmware must be v1.32 or higher for SmartSolar™ compatibility WARNING: Do not connect the batteries until Step C5 is completed. Step C4 - Mount the Charger Board Unplug the drive unit from mains power. -
Page 12: Roll Up Door Opener Set Up
Refi t the timing cover, main cover and light diffuser. Step D7 - Re-setup and Test the Opener Setup travel limits and code transmitters as per the GDO-6 instruction manual. Press either the “OSC” buttons, or use a transmitter to operate the opener. SmartSolar™ Installation Instructions & Owners’ Manual... -
Page 13: Roll Up Door Opener Set Up (Gdo-8 Easyroller ® )
Refi t covers and chassis enclosures to the opener. Step E7 - Re-setup and Test the Opener Setup travel limits and code transmitters as per the GDO-8 instruction manual. Press either the “OSC” buttons, or use a transmitter to operate the opener. Installation Instructions & Owners’ Manual SmartSolar™... -
Page 14: Specifi Cations
Specifi cations SmartSolar™ Technical Specifi cations* Garage Door Slider Swing Gate Load Voltage Load Continuous Current 3 - 5A 5 - 10A Number of Cycles per Day Average Cycle Time (Opening and Closing) 40 seconds 90 seconds 72 seconds Max. Standby Current... -
Page 15: Warranty
2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants: SmartSolar™ kit for twelve (12) months from the date of purchase (specifi ed in the sales docket receipt) as free of any defects in material and workmanship. - Page 16 , SecuraLift ® , SecureSwing ™ , SecureSwing S ™ , SmartSolar ™ , SmartPlanet ™ and Elite ™ are trademarks and registered trademarks of Automatic Technology (Australia) Pty Ltd. No part of this document may be reproduced without prior permission. In an ongoing commitment to product quality we reserve the right to change specifi...
