- Page 1 TRITON routing switcher High Definition Serial Digital Video Router 16x2 Product model no. TTN-HDS-1602 INSTALLATION MANUAL MANUAL PART NO. 071-8220-00 Rev. 0 MARCH 14, 2003 the most watched worldwide...
- Page 2 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
-
Page 3: Table Of Contents
Control Bus configuration notes Router configuration Router level Vertical interval trigger Power up mode Connecting video signals to the HDS-1602 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 7.1.1 Binary Code 7.1.2 Echo 7.1.3... - Page 4 RS232 Commands 7.5.1 Audio crosspoint set 7.5.2 Audio crosspoint set acknowledge 7.5.3 Video crosspoint set 7.5.4 Video crosspoint set acknowledge 7.5.5 Crosspoint status request...
-
Page 5: Electromagnetic Radiation Notice
Electromagnetic Radiation Notice The following information is given to note compliance with the United States Government Federal Communications Commission (FCC) Rules (47 CFR Part 15) designed to limit interference to radio and TV reception. The ruling establishes measurement procedures and frequency criteria for Class A computing devices (commercial and industrial applications) with the following conduction and radiation limits: CLASS A COMPUTING DEVICE: CONDUCTION LIMIT (Part 15.812) Frequency (MHz) -
Page 6: Hardware Warranty And Software License
Hardware Warranty and Software License Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you. -
Page 7: Revision History
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 14/03/03 Initial Revision... -
Page 9: General
The built-in RS-232 interface allows the user to control the router via the Triton Router Control System, with its many operational features. The control bus technology allows linking the unit with the BAS-1602 or BES-1602 to create an AFV router. One or several Triton remote control panels can control the HDS-1602 as well. - Page 10 HDS-1602 can also be delivered with DC ±5V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information.
-
Page 11: Connecting The Hds-1602 To Your Pc
Rev. 0 3 Connecting the HDS-1602 to your PC For connection to a PC with Triton Router Control System, the RS-232 interface is used. The RS-232 port on all Triton devices uses the standard DCE pin-out, see pin-out table under 4.3. -
Page 12: Ncb Connection
To get a control panel working with a specific router, configure the control panel to the same level as the router. Several panels can be configured to control the same router. The Triton panels can control 2 levels with breakaway function. If it is necessary to control more levels with breakaway an additional panel must be used. -
Page 13: Pin-Out And Cable Type
Rev. 0 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, including the HDS-1602, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected... -
Page 14: Rj45 To 5-Pin Din Converter
This means that the NCB OUT of the last unit must be connected to the NCB IN of the first unit in the NCB chain. To avoid problems with the control of Triton units the installer/user has to assure that the bus structure is installed according to this definition. - Page 15 Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. • Triton - RCS Complete the Control loop, by connecting all Control bus connections to all Triton devices, before • powering up any Triton device.
-
Page 16: Router Configuration
5 Router configuration Router level Switches 2 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router. -
Page 17: Power Up Mode
HDS-1602 Rev. 0 DIP-SW pos. 1 DIP-SW pos. 7 VIT 525/625 line Switch timing 30uS ± 5uS after Oh line 10 Don't care ON (SDTV) 30uS ± 5uS after Oh line 6 Don't care ON (SDTV) OFF (line 4) OFF (HDTV) 10-15uS after Ov. -
Page 18: Control And Connection Of Triton Systems, Interface Protocol
The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters. ASCII characters will not be accepted. -
Page 19: Example: Several Units Connected By Ncb
RS232 The RS-232 port is used for external control of Triton units. The RS-232 port allows the customer to control the equipment via the Triton Router Control System PC program or self-defined customized solutions. -
Page 20: Commands
HDS-1602 Rev. 0 Commands 7.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 21: Video Crosspoint Set Acknowledge
HDS-1602 Rev. 0 7.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
