EmberGlo E2424 Installation, Service Instructions & Parts

Installation, Service Instructions & Parts
Warranty
See the back of this manual for the warranty.
This warranty does not apply to damages resulting from
accident, misuse, abuse or alteration.
No equipment may be returned without written authorization
from EmberGlo (or Midco International Inc.) . Returned goods
must be shipped prepaid to the factory.
Warranty card must be fi lled in and returned to EmberGlo (or
Midco) to validate warranty.
CAUTION: This manual contains suffi cient information
for installation of the EmberGlo Broiler in normal locations.
In the United States, installation must conform with local codes.
CODE COMPLIANCE IS THE SOLE RESPONSIBILITY OF
THE INSTALLER.
CAUTION: Cooking equipment should be used in
an environment protected by an automatic fi re suppression
system. Consult the National Fire Protection Association NFPA
Code 96 or the latest edition of Standards for Installation of
Equipment for Removal of Smoke and Grease-Laden Vapors
From Commercial Cooking Equipment.
CAUTION: To avoid grease fi lter fi re hazard,
commercial kitchen exhaust hoods should be positioned at a
minimum of 3½ feet above the broiler cooking surface, as speci-
fi ed by Commercial Grease Removal, Building Offi cials & Code
Administrators International Inc. and the National Mechanical
Code, 1990 Seventh Edition (or latest edition), Article 5, Section
M504.0, Table M504.3.2.
EmberGlo
A Div of Midco® International Inc.
4140 West Victoria Street
Chicago, Illinois 60646
toll free 866.705.0514
tel 773.604.8700
fax 773.604.4070
web www.emberglo.com
e-mail sales@emberglo.com
SAFETY INFORMATION TERMS: The following terms are used to identify hazards, safety precaution of
special notations and have standard meanings throughout this manual. They are printed in all capital letters
using a bold type face as shown below, and preceded by the exclamation mark symbol. When you see the
safety alert symbol and one of the safety information terms as shown below, be aware of the hazard potential.
DANGER: Identifi es the most serious hazards which will result in severe personal injury or
death.
WARNING: Signifi es a hazard that could result in personal injury or death.
CAUTION: Identifi es unsafe practices which would result in minor personal injury or product and
property damage.
Quality Designed for Proven Performance
Electric Char Broiler
E2424
WARNING: Additions, changes, conversions and
service must be performed by an authorized EmberGlo
representative or service agency. Use only EmberGlo specifi ed
and approved parts.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operat-
ing and maintenance instructions thoroughly before
installing or servicing this equipment.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable liquids
and vapors in the vicinity of this or any other appliance.
PURCHASER: Retain these instructions for future use.
INSTALLER: Inform and demonstrate to the user the correct
operation and maintenance of the equipment. Inform the user
of the hazards of storing fl ammable liquids and vapors in the
vicinity of this equipment and remove such hazards.
USER: Retain this manual for future reference. If other than
routine service or maintenance as described in this manual
and associated literature is required, contact a qualifi ed service
agency. DO NOT ATTEMPT REPAIRS. An inadvertent service
error could result in a dangerous condition.
AVOID ERROR IN PARTS SELECTION. When ordering
use complete EMBERGLO Part Number and Description.
Furnish Model Number, Bill of Material Number and Serial
Number (if available) from the specifi cation plate found on
the product.
IMPORTANT: Availability of parts as well as specifi cations
are subject to change without notice. Please consult factory
for item availability.
613
8471 64
Printed in USA
