Bizon Pumps BPN-330C Installation Instructions Manual

WARNING: All pumps are shipped with a stainless steel male pipe thread hose adaptor. You may
connecting a hose to the hose adaptor on the pump. CONSULT YOUR LOCAL PLUMBING CODE!!
BISON PUMPS
PO BOX 977
HOULTON, ME 04730
INFO@BISONPUMPS.COM
WWW.BISONPUMPS.COM
1-800-339-2601
Inspect the contents of the box to be sure everything you ordered has been received. Be sure to check
the serial number on the pump head assembly to verify it matches the serial number on your
invoice/packing list.
Read All Instructions Before Beginning the Actual Pump Installation
 DO NOT begin the installation without first reading the entire instruction booklet, studying and
understanding the diagrams.
 DO NOT attempt the installation by yourself.
 DO NOT begin the installation of the pump without first checking the water level in your well to be
sure you have enough pipe and rod to install the pump cylinder at least 20' below the static water
level.
 DO NOT over tighten the 1 ¼" pvc piping into the pvc female pipe thread bell end of the sch. 120
plastic pipe. The pipe can be threaded with a pair of pliers or a 12" pipe wrench.
 DO NOT use large pipe wrenches for the assembly of the pvc piping.
 DO NOT install the pump during a thunder and lightning storm. Be aware of any overhead power
lines.
 DO NOT hurry the installation of your pump. Think before you act.
 DO NOT screw multiple lengths of pipe and rod together, laid out on the ground, and then try to lift
all the pipe and rod to a vertical position to lower it into the well.
 DO NOT lower the pump and pipe sections into the well by the safety rope. Grab the pipe securely
with both hands and lower the pipe, cylinder and safety rope into the well 8' at a time, using the
paddle as a stop. The safety rope should be tied off to a secure object, i.e. the well casing so that it
can be lowered slowly and safely.
If you are going down more than 14 lengths of pipe and rod, mechanical means of
lowering them into the well is recommended along with the Bison lifting tool and
adjustable rod. Gloves are recommended when handling rope.
BISON DEEP WELL HAND PUMP
Installation Instructions
want to check local codes to see if a hose Bibb backflow preventer should be used when
DO'S & DON'TS FOR PUMP INSTALLATION
