Page 2: Table Of Contents
User Manual CONTENTS Safety Instruction ..................................1 Chapter 1:DVR Features ................................2 Chapter 2:Layoutt..................................3 2.1 Front Panel ..................................3 2.1.1 4-CH Front Panel (Details please refer to the real product)..................3 2.1.2 8-CH Front Panel (Details please refer to the real product)..................3 2.2 Rear Panel.................................. - Page 3 User Manual Chapter 6:NetViewer Program .............................. 23 6.1 Plug-ins download and installation ..........................23 6.2 Log-in to NetViewer ................................ 23 6.3 Main Interface of Net-viewer ............................23 6.3.1 Menu column................................. 24 6.3.2 PTZ Control ................................26 6.3.3 Live play Control..............................26 Chapter 7:Specification ................................
-
Page 4: Safety Instruction
User Manual Safety Instruction Use proper power source. Do not use this product with a power source that applies more than specified voltage (100-240V AC). Never insert anything metallic into the DVR case. Putting something into the DVR case can be a source of dangerous electric shock. Do not operate in wet &... -
Page 5: Chapter 1:Dvr Features
User Manual Chapter 1:DVR Features Real time monitoring Supports real time surveillance via Monitor Saves Recordings DVR saves real-time recording image to HDD Backup Recordings Supports DVR backup via USB flash drive and hard drive. Playback Recordings Supports DVR single CH and multiple CH playback of recorded files Network operation Supports remote surveillance by multiple users simultaneously Supports HDD &... -
Page 6: Chapter 2:Layoutt
User Manual Chapter 2:Layoutt 2.1 Front Panel 2.1.1 4-CH Front Panel (Details please refer to the real product) List 2-1 Item Key title/Indicator Marks Functions Power Switch Turn Power on and off Power indicator If the “Green” indicator is on the system is getting power IR Receiver Receives signal from Remote Control When the “Red”... -
Page 7: Rear Panel
User Manual Power Switch PAUSE: Pause / Frame Play PWR: PWR Indicator PLAY: Play IR receiver for Remote Control FWD: Play Forward / Move Right HDD: HDD Indicator STOP: Stop Playback; Stop manual Recording SEARCH: Recording Search REC: Manual Recording MUTE: Audio Mute key MENU/ESC: Menu / Escape CH-: Switch to previous channel... -
Page 8: Remote Controller （Only For Reference)
User Manual CH1-8: Video inputs Audio Output Video Outputs USB port Audio Input Mouse port LAN: LAN port for Network Access RS-485/Sensor / Alarm port Not used Power switch port 8-CH: RS485/Sensor/Alarm port functions 4-CH: RS485/Sensor/Alarm port (from left to right): functions (from left to right): Pin 1-2：PTZ Control port Pin 1-2：PTZ Control port... -
Page 9: Chapter 3:Dvr Installation
User Manual Mouse Operation You can use a mouse instead of front panel buttons or remote control. In menu lock mode, Enter into pop-up menu and clicking any sub menu to pop up Log-in window; on menu unlock mode, enter into pop-up menu, and then clicking left key to enter into any sub menu directly. -
Page 10: Chapter 4: Dvr Boot Up
User Manual Chapter 4: DVR Boot up 4.1 System Initialization After connecting the power adapter and turning On the power button, the system will boot-up and start initializing. Picture 4-1 4.2 Main Interface After finishing system initialization you are allowed to enter into main interface. -
Page 11: Main Menu Preview
User Manual 5.1 Main Menu Preview Camera Color set Recording Search Network Playback Rec. Search Detail File File Backup HDD Management E-mail setting Alarm Setting Device PTZ Setting Management Mobile Area setting Motion Time Setting User password Video Setting System Language Select System Information System Maintenance... -
Page 12: Camera Setup
User Manual 5.2.1 Camera setup Go to [Main Menu Camera] to set up the name display and position display of each channel (Shown as Picture 5-3), You can also adjust image brightness, saturation, contrast and hue settings of each channel after entering into [Color] Menu and set up whether each channel can be previewed or not under Live display and/or Recording mode. -
Page 13: Network Set
User Manual Recording options include All, CH-1, CH-2, CH-3, CH-4 respectively. Please click the channel you need, the channel you select will be highlighted in “Blue” unselected channels will be “Grey”. To setup weekly schedules, click on the box of the recording status you want (Alarm, General, or No Record) and then click on each box in the schedule time line that you want this method to apply to. -
Page 14: Recording Search
User Manual If you apply for DDNS service and set up net parameter of DVR accordingly, you could visit DVR remotely via IE browser. (shown as picture 5-10) Picture 5-10 If you need to visit DVR via Internet, you should setup the inflection of video port at the public Router located in the DVR (shown as Picture 5-11). -
Page 15: Multi Player
User Manual LAST (Last page): Indicates the last page of recording history you have searched. When you view other pages, clicking [Last page] button will take you to the Last page. ALL (Select All): Allows you to select all the events on the current page. INVERSE (Select Invert): Allows you to select other events on the current page except those you have currently selected. - Page 16 User Manual （2） 、Click pop-up menu button on the bottom of multimedia player and [Play- ] button, then the backup file will be played on the according channel. （3） 、The Menu brief on the bottom of multimedia player: Date: recording date for the current backup file shown as right corner; 24H recording time: lie under [Date] menu.
-
Page 17: Device Management
User Manual 5、Refer to the below for [Audio on] setting procedure. (Setting parameter will be available after re-starting multimedia player after [Audio on] set up.) Setting Audio channel setting Normal video Bar Select the channel you want to playback the audio Select the channel has audio files Apply OK. - Page 18 User Manual 5.2.6.2 Alarm Set Click [Main Menu Device Alarm] to enter into [Alarm setup] menu to setup Alarm warnings (shown as Picture 5-32). I/O STATUS ： Options include NO (Normal-open), NC (Normal-close) and OFF. Set to “Normal-open” if you use external sensor alarms that are normally open, Set to “Normal-close”...
-
Page 19: Ptz Setup
User Manual Please set SSL to “On” via Gmail.com server, and set to “Off” via other mail server. If your setting is still not right, please contact the web site where you have applied for your email box to get SMTP server and SSL of mail box. Picture 5-35 SMTP Port: indicates sender port of SMTP server. -
Page 20: Mobile Phone Access
User Manual 5.2.6.4 Mobile Click [Main menu Device Mobile] to enter into [Mobile] menu. User Name: indicate user name of DVR. User password: indicate user password of DVR Server port: Mobile monitoring port. Setting range is between 1024 and 65535. Please note that Explanation: Please connect DVR to Internet before setting DVR port number and the server port no is not equal to network menus. - Page 21 User Manual 4. After installation finishes, click the icon named QQeye (red box in Pic 5) to run the program. This will display the program screen in Pic 6. 5. Settings: Click [Setting] button (red box in Pic 6) to enter the Setting menu shown as Pic 7 Pic 9 Pic 7 Pic 8...
-
Page 22: Server Port
User Manual After the phone finishes preparation it will display Pic 4 asking for permission to install the program. Select the Yes button (red box in Pic 4). This will display the window in Pic 5. Pic 5 Pic 4 Pic 6 3. -
Page 23: System Function
User Manual Password： Same as password setup on DVR. (Please press Function key to save the password, left soft key won’t be able to save the password) Channel: Select the channel you want to monitor and click [OK] button to start video connection Network connection status: percentage of buffer display, connection success, connection fail, play and stop. -
Page 24: Time Set
User Manual 5.2.7.1 Time Set Click the [Main menu System Date/Time] in turn to enter into [Time Set] menu. You could not only modify system date, time and format, but also set daylight saving time and mode. Picture 5-41 5.2.7.2 Password This option allows you set the device ID for the DVR and set the system password if you want to use one. -
Page 25: Menu Lock
User Manual 5.2.7.5 Info. Click [Main Menu System Info] to enter into [System Information] menu to view system info, including Device type, Software (firmware) version and MAC address etc. Picture 5-46 5.2.7.6 System Maintenance This option allows you reset the DVR to factory default settings, update system software (firmware), and set system auto-maintenance. -
Page 26: Chapter 6:Netviewer Program
User Manual Chapter 6 NetViewer Program 6.1 Plug-ins download and installation Open IE browser and input IP address and web port of DVR, such as http://172.18.6.202:80/ and confirm to download and install webcam. If your computer is connected to internet, computer will auto download and install the webcam. -
Page 27: Menu Column
User Manual 6.3.1 Menu column Menu column include [Live] menu, [Replay] menu and [Setup] menu. 6.3.1.1 Live After Logging-in to system, system will enter into Live display (shown as Picture 6-3). 6.3.1.2 Replay This option allows you to playback recordings remotely. - Page 28 User Manual Click the [Schedule] menu to enter into its sub menu (shown as Picture 6-6). Remote setup methods are the same as local DVR setup. Please refer to Section 5.2.2 Record Setup Picture 6-6 ② Alarm Click [Alarm] menu to enter into its sub menu (shown as Picture 6-7).
-
Page 29: Ptz Control
User Manual ○ 4 Network Click [Network] to enter into [Network] menu. Remote setup methods are the same as local DVR setup. Please refer to Section 5.2.3. – Network Set. Picture 6-10 Setting ○ Click [setting] menu to enter into the menu interface (shown as Picture 6-11);... -
Page 30: Chapter 7:Specification
User Manual Chapter 7:Specification Model Video System NTSC / PAL(Optional) Compression Format Video：H.264 / Audio：8kHz*16bit ADPCM Video Output 4-CH BNC Input/ 2-CH BNC Output 8-CH BNC input/2-CH BNC output 1-CH RCA audio input/ 1-CH RCA audio Audio I/O 4-CH RCA audio Input / 1-CH RCA audio Output output Display Resolution D1：704×576(PAL) 704×480 (NTSC) -
Page 31: Chapter 8: Windows Vista User
User Manual Chapter 8: Windows Vista User 1、Open IE browse firstly, then enter into Tool bar- and select appear the below picture: 2、Second, select icon tick the settings of “ActiveX controls and plug-ins”to Enable, details as follows: Lastly after tick all the “Enable”, please click to exit. -
Page 32: Chapter 9: Appendix
User Manual Chapter 9: Appendix 9.1 Operation Function Table Type Title Description Page Time setting Setting system date, time and format and day-light saving time setting Language Select Setting system language Setting CH title and position; adjusting image color parameter value; setting CH display to CH Setting ON / Off and time display/recording time overlaying to On/Off. -
Page 33: Recording Alarm Setting
User Manual 9.2 Recording Alarm setting Please refer the below matrix: “⊥” stand for “only alarm but no recording”; “AMR” stand for “alarm recording”; “NLR” stand for “normal recording”; and “NOR” stand for “ no recording”. Once alarm is triggered, alarm icon will occur, and when many alarms are triggered, alarm remarks will occur on the screen. -
Page 34: Email Server Check List
User Manual 9.4 Email server check list （The below info only for your ref.） （Web site） Email address Sender server（25） Receiver server（110） @163.com smtp.163.com pop3.163.com smtp.vip.163.com pop.vip.163.com @vip.163.com smtp.188.com pop.188.com @188.com www.163.com @126.com smtp.126.com pop3.126.com @netease.com smtp.netease.com pop.netease.com @yeah.net smtp.yeah.net pop.netease.com www.163.net smtp.163vip.net... -
Page 35: System Connection Configuration
User Manual 9.6 System connection Configuration 4-CH 8-CH... - Page 36 User Manual The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
