Getting to know your machine:
2
1 Air Purifier Door: Easily remove to gain access to the filter at front
of machine.
2 Main Filter: Filter particles from the air that passes through the filter.
3 Odour Filter: Reduce odours from the air that passes through the
filter.
4 Side Intake Grill: Where air enters the unit.
5 Main Filter Light: Indicates the main filter may need to be replaced
when lit.
6 Odour Filter Light: Indicates the odour filter may need to be replaced
when lit.
7 Light Reset Button: This button resets both the main filter and odour
filter lights.
8 Timer: Set the run time for two, four or eight hours, before
automatically turning OFF.
9 Fan Speed: The fan runs at three speeds. The lights indicate the
current fan speed.
L: Low for the Silence Technology
®
M: Medium for typical use
H: High for maximum cleaning
10 Power: Turn the unit ON and OFF.
11 Exhaust Grill: Direct the flow of air as it exits the unit.
* Included in your machine: Main filter and odour filter.
Technical specifications see page 9.
Getting started:
BEFORE YOU BEGIN
Important: Remove all packaging covering the air purifier and filters.
Make sure the filters are in place and correctly fitted before turning on.
Stand the air purifier on a hard flat surface away from candles and flames.
Never block the air grills, keep air grills free from any obstruction
HORIZONTAL POSITION
1
2
CHECK the air purifier
PLACE the air purifier on
for the filters. Be sure the
a hard surface such as the
supplied filters are properly
floor, a table or desk. Be sure
in place and all plastic is
the grilles are not blocked by
removed before turning the
other objects, and there are
unit on.
no candles or flames near
the unit. The air purifier can
be placed in a horizontal or
vertical position.
• IMPORTANT •
This unit is equipped with a
smart panel that senses your
touch. Heavy pushing of
.
buttons is not recommended.
3
PLUG IN into nearest standard electrical outlet.
4
LIGHTLY TOUCH the power button to turn the air purifier on. Touch
the power button again to turn the air purifier off.
5
SELECT THE FAN SPEED. To select the speed, lightly touch and
release the fan speed button until the desired speed is reached.
L = low (Silence Technology
), M = medium or H = high.
®
6
ADJUST THE TIMER feature. The time can be selected from two,
four or eight hours. The unit will turn off once it runs for the
selected hours.
Note: The unit will run continuously if all the timer lights are off.
7
THE CHECK FILTER LIGHTS will light up when the filters may
need to be replaced. Touch and hold the button for several seconds
until the filter indicator shuts off.
3
