Summary of Contents for Munro Sonic EGG 150
-
Page 1: Operation Manual
Operation Manual ® Munro Sonic EGG 150 MONITORING SYSTEM... -
Page 3: Table Of Contents
EGG 150 Monitoring System Contents EGG 150 MONITORING SYSTEM Dual Input Amplifier (Control Panel) Front Pg 4 Dual Input Amplifier (Control Panel) Back Pg 5 SETTING UP YOUR SYSTEM Setup and Operation Pg 6 Positioning Pg 6 Equalisation Pg 7... -
Page 4: Dual Input Amplifier (Control Panel) Front
EGG 150 Monitoring System Thank you for purchasing your Munro Sonic EGG 150 Monitoring System, designed by Mr Andy Munro, one of the world’s leading acousticians and monitor experts, and manufactured in the UK. Your system has been constructed using the finest quality components and extensively tested to ensure years of trouble free operation. -
Page 5: Egg 150 Monitoring System
Egg system are very high quality, impedance matched multicore and under no circumstance should these be changed or extended without advice from Munro Sonic. See diagram for pin connections. The focal point aiming LEDs on the speakers can be switched off once the system is aligned and no further adjustment is likely. -
Page 6: Setting Up Your System
Setting up your System Setup and Operation The Egg 150 is designed specifically for near-field, free standing operation. This means that adjacent equipment and surfaces will have some effect on the performance of the system and this should be taken into account when planning and installing the speakers. -
Page 7: Equalisation
Setting up your System Equalisation The Egg 150 is naturally neutral in its frequency response. This is mainly a result of the acoustically optimal enclosure and the choice of small drivers with almost perfectly controlled directivity. However, not all rooms are neutral and also the positioning of the speakers will affect the response. -
Page 8: Running In
Setting up your System Running In High quality drivers are used in the Egg 150 Monitoring Systems. When new, they will reach their optimum working performance after approximately 24 hours of operation and after that should still be allowed to warm up before serious mixing is carried out. -
Page 9: Technical Information
HF Amp Main Level Main I/P LF Amp Level Equalisation Aux I/P Headphone Amp Headphone HF Amp Main Level Main I/P LF Amp Level Equalisation Aux I/P Right Channel Egg 150 Monitoring System schematic EGG 150 MONITORING SYSTEM Operation Manual... -
Page 10: Important Safety Information
MUNRO SONIC cannot be held responsible for any damage caused by improper use or modifications of the system or power supply. EGG 150 MONITORING SYSTEM... - Page 12 ® Munro Sonic 3 Hunting Gate, Hitchin, Hertfordshire, SG4 0TJ, United Kingdom Tel. +44 (0)845 500 2 500 www.MunroSonic.com...
