Page 1 Smart Power Drive SecurePRO User Manual Version_010...
Page 2: Table Of Contents
Index Getting to know Smart Power Drive SecurePRO ........3 Use of Smart Power Drive SecurePRO ............5 System Requirements ................5 Connecting to PC/NB ................5 Disconnecting from Mobile Phone Safely ..........5 Install Smart Power Drive SecurePRO App ..........7 Start Using Smart Power Drive SecurePRO ..........
Page 3: Getting To Know Smart Power Drive Securepro
Getting to know Smart Power Drive SecurePRO Standard USB port Connect to an Android phone for file transmission and charging. Micro SD card slot Supports a Micro SD card with capacity up to 32GB Micro USB port Connecting it with a cable at its Micro USB port to any PC/NB, USB charger, power bank USB port and any 5V output USB port to charge your Smart Power Drive Power On/Off...
Page 4 Blue indicator 1 on、Blue indicator 2 flashes→power 25%~50% Blue indicator 1~2 on、Blue indicator 3 flashes→power 50%~75% Blue indicator 1~3 on、Blue indicator 4 flashes→power 75%~99% Fully charging：Blue indicator 1~4on...
Page 5: Use Of Smart Power Drive Securepro
Use of Smart Power Drive SecurePRO Connect the USB port with USB Male to Micro USB Male cable to Android phone and turn on the power. You can start to transfer the file between Smart Power Drive SecurePRO and phone and charge the phone. Note: Smart Power Drive SecurePRO cannot be used as a PC card reader.
Page 6 Figure 1 Figure 2...
Page 7: Install Smart Power Drive Securepro App
3. Download and install the APP as prompted by the Play Store. The APP icon displays on desktop screen once the installation is completed. You may search for ”afdiskpro” directly from the Play Store for the APP download and installation.
Page 8: Start Using Smart Power Drive Securepro
Start Using Smart Power Drive SecurePRO Note: 1. Please insert the micro SD card before using it. 2. If Smart Power Drive SecurePRO cannot be identified or work normally, please restart your phone to find the situation. 1. Insert your Smart Power Drive SecurePRO then press the Power button to turn it on.
Page 9: Main Screen
Smart Power Drive SecurePRO main screen description Main Screen The APP's main screen displays the default folder of the “Local Storage” (Figure 1) which contains all the folders in your mobile phone's internal memory and the micro SD card (Figure 2). Figure 1 Figure 2 Tap on the “Local Storage”...
Page 10: About & Help
Smart Power Drive SecurePRO storage area About & Help Press your phone's function key to display the “About and Help” menu.
Page 11 About: APP Version、Android OS Version、Phone Model and Firmware Version displays. Help: Visit our online service website for operation instructions, FAQs and a list of compatible mobile phones. Note: Please ensure that your mobile phone is connected to a WiFi hot point or 3G network.
Page 12: File Encryption/Decryption
File Encryption/Decryption Your Smart Power Drive SecurePRO can encrypt and decrypt any folders/files contained in the Local Storage when connected to your mobile phone. Otherwise, it is unavailable as it does not appear in the APP list. Tap on the file/folder icon to select the desired option (Figure 1). The circle of the file/folder is then checked and the “Encrypt”...
Page 13: Decryption
Figure 1 Figure 2 Figure 3 Decryption Select the files to be decrypted, tap on in the tool bar, type the original set of password (Please note that the password is case sensitive) to decrypt the selected files. The encrypted files will restore to original files after the files are decrypted. Note: The decryption function has to be complied the following conditions, otherwise it is impossible to decrypt the file.
Page 14: File Management
File Management Single File Operation The list of files in the storage is displayed once you enter the Local Storage/External Storage menu. Tap on and hold each file to open the function menu for 「Open」, 「Rename」, 「Delete」, and 「Send via mail」 or tap on 「Cancel」 to exit to the file list screen.
Page 15 Tap on「Delete」to remove selected file after taping on 「OK」. Send via mail Tap on「Send via mail」, then select the desired email app and send the file with the email.
Page 16: Multiple File Operation (Local Storage)
Multiple File Operation (Local Storage) The list of files in the internal storage is displayed once you enter the Local Storage menu while the 「Return to root」,「Return on top」,「Create new directory」, and 「Select all」 function icons are displayed in tool bar. Return to root Tap on to return to the default directory (APP main screen) of your “Local...
Page 17 Select all Tap on to select all files and folders in the current directory. Tap on the file/folder icon to select the desired option (Figure 1). The circle of the file/folder is then checked (Figure 2) and the「Remove all」, 「Cut」, 「Copy」, 「Delete」...
Page 18 Remove all Tap on to deselect the files and folders that have been selected. Tap on to move the selected file/folder to another directory (Figure 1). The directory position and grid lines turn yellow for the selected files (Figure 2) and you can move them to the desired destination.
Page 19 Easy Copy Tap on to copy selected files/folders to “AFDisk” folders auto created in the “External Storage (Smart Power Drive SecurePRO device)”. Copy Tap on to copy the selected file/folder to another directory. The directory position and grid lines turn yellow for the selected files and you can move them to the desired destination.
Page 20: Multiple File Operation (External Storage)
Multiple File Operation (External Storage) The list of files in the internal storage is displayed once you enter the External Storage (Smart Power Drive SecurePRO) menu while the 「Create new directory」, 「Auto create directories」 , 「Select all」 , and 「Format」 function icons are displayed in tool bar.
Page 21 Auto create directories to create the 「Audio」, 「Document」, To manage files, tap on 「Image」 and「Video」folders automatically. Select all...
Page 22 Tap on , and select all files and folders of the directory. Format Tap on to format the External Storage (Smart Power Drive SecurePRO) and remove any files/folders contained in it. Icons of advanced functions displayed in the tool bar after selecting any file/folder, including 「Remove all」, 「Cut」, 「Copy」, 「Delete」, and 「Send via Mail」...
Page 23: Limit On Its Uses
Limit on its uses Limits on Smart Power Drive SecurePRO device Please insert the micro SD card into your Smart Power Drive SecurePRO before using Limits on External Storage Do not remove the Smart Power Drive SecurePRO device when a mobile phone is connecting Smart Power Drive SecurePRO to run the Open, Copy, Cut, Delete, Send via mail functions in the External storage as this may cause damage or loss of files! Limits on Remove Smart Power Drive SecurePRO Safely...
Page 24: Troubleshooting
Troubleshooting Do self checks as below in case of Smart Power Drive SecurePRO operation failure: 1. Is the micro SD / micro SDHC card inserted correctly? 2. In case you cannot connect to a mobile phone or play a video or file, please remove your Smart Power Drive SecurePRO and plug in again for smooth operation.
