Summary of Contents for OEM Optical IVS-CCAM3
- Page 1 Miniature Color CCD Camera IVS-CCAM3 / IV-CCAM3P OPERATING MANUAL For Customer Use : Please record the model No. and the serial No. in the spaces provided below. These numbers located on the bottom of the camera. Keep this manual for future reference.
- Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL. This lightning flash with arrowhead WARNING : symbol is intended to alert the user to the presence of uninsulated “dangerous TO PREVENT THE RISK OF FIRE OR ELECTRIC...
-
Page 3: Table Of Contents
Thank you for purchasing this Color CCD camera. Before using this camera, please read this operating manual carefully to obtain the best result and keep this manual for future reference. CONTENTS PRECAUTIONS ....3 Back light compensation . -
Page 4: Precautions
PRECAUTIONS Do not install the camera where the temperature could Operating Ø exceed the allowable range. Before using, make sure of power supply and Ø Be sure the ambient temperature is less than 40°C for connection of video output. Power supplied without voltage stabilization or the long term continuous operation. -
Page 5: Features
FEATURES High sensitivity White balance 1/3” 470,000 pixels for PAL CCD with on-chip micro Three control modes of auto-tracking preset and lenses and low noise signal processing circuit provide manual white blance can be selected according to high sensivity down to 0.8 lux(F1.2). conditions. -
Page 6: Name And Functions
NAME AND FUNCTIONS Lens mount Back-focus screw Mount for installing the lens. C-mount A screw is provided to fix the lens mount. lens can be used when C-mount adapter See page 21. is attached and CS-mount lens can be used when it is removed. DIGITAL COLOR CCD CAMERA Lens mount cap... - Page 7 Power indicator S-VIDEO connector Lights up when the camera is Output connector seperated powered. Y/C video signal. Connector to the S-VIDEO input connector of video Video output connector monitor. See page 19. BNC connector that outputs a composite video sihnal. VIDEO S-VIDEO 12VDC...
-
Page 8: Menu System
MENU SYSTEM GENERAL The camera settings and adjustments can be changed to The menu system can activate all the features and accommodate usage conditions. option of the camera. When connected to a monitor, convenient on-screen The menus are superimposed on the image menus facilitate checking and changing the settings and displayed on the screen. -
Page 9: Menu Description
Menu Description MAIN MENU (page 8) SHUTTER WHITE BACK TEXT SPECIAL BALANCE LIGHT DISPLAY MENU (page 10) (page 11) (page 12) (page 13) (page 14) (page 15) AGC on/off control White balance control Text display H On H Auto-tracking (ATW) H Off H Off H Preset (AWC) -
Page 10: Main Menu
MAIN Menu 3) If changes are unnecessary, shift the cursor to the END 1) Press the Set button to display the main menu on the position and press the Set button to return the normal monitor screen. video screen. 2) Check the present settings at the main menu. 4) When a setting is changed by pressing the Setup buttons, the new setting is stored in the internal memory by pressing the Set button with position the... -
Page 11: Lens
Lens AGC on/off 1) Press the Set button to display the main menu on the 1) Press the Set button to display the main menu. monitor screen. 2) Position the cursor at AGC and press the left or right 2) Position the cursor at LENS and use the left or right button to setting the AGC off. -
Page 12: Electronic Shutter Control
MANUALSHUTTER Electronic shutter control ➔ Shutter Speed : 1/60 1) Press the Set Button to display the main menu. 2) Position the cursor at SHUTTER, and press the left or Press SET to Main Menu right button to setting the manual shutter. MAIN MENU 2) Press the left or right direction button to select a shutter LENS... -
Page 13: White Balance Control
Note : The ATW mode may not function properly in WHITE BALANCE CONTROL the following cases. 1) Press the Set button to display the main menu on the In such a case, set to the "manual" mode. monitor screen. When shooting with non-standard lighting or lighting Ø... -
Page 14: Back Light Compensation
MAIN MENU MANUAL (Manual white balance) LENS : VIDEO 1) Press the Set button to setting Manual white balance : ON when position the cursor at WHITE BALANCE and Shutter : OFF the mode is MANUAL. White Balance : ATW 2) Press the left, right, up, down direction buttons to ➔... -
Page 15: Text Display
Zoom 1 Zoom 2 Text display 1) Press the Set button to display the main menu on the monitor screen. Zoom 5 Zoom 6 Zoom 5 2) Position the cursor at TEXT DISPLAY and press the left or right button to setting the text display on. 3) Press the left or right button again, text display setting Zoom 3 Zoom 4... -
Page 16: Special Menu
TEXT GENERATION Special Menu A B C D E F G H I J K L M N O P Q R S The special menu function allows to change the video T U V W X Y Z a b c d e f g h i j k l output qualities to match the particular applications. - Page 17 COLOR ADJUSTMENT Ø GAMMA ADJUSTEMENT 1) Position the cursor at COLOR ADJ. and press the Set ➔ Level 14 button for color adjustment. Level gamma value SPECIAL MENU 0.45 Gamma ➔ Color Adj. Sharpness : LOW Press SET to Return Contrast : OFF Brightness...
- Page 18 SHARPNESS Ø SPECIAL MENU 1) Position the cursor at SHARPNESS and press the Gamma left or right button for setting the sharpness HIGH. Color Adj. 2) Press the left or right button again, the sharpness Sharpness : LOW setting returns to LOW. ➔...
- Page 19 FLICKERLESS PRESET Ø Ø If the camera is used with 50 Hz fluorescent lighting, This function is useful when the camera is used the and there is flickering on the monitor. frequently changed setup conditions. In this case, set the FLICKERLESS mode to ON. Preset mode provide the best image under the normal Otherwise it should be set to off.
-
Page 20: Lens Installation
LENS INSTALLATION Pin assignment : S-Video connector (4-pin) I Please attach a lens cable when using the Video type auto iris lens Pin No. Signal Y (Luminance. 1Vp-p, 75Ω) C (Chrominance, 0.286Vp-p, 75Ω) When using the VIDEO type Auto- iris lens, install the lens plug as follows. -
Page 21: Mounting A Lens
Mounting a lens ADJUSTING AUTO-IRIS LENSES Remove the lens mount cap from the camera. Make this adjustment after connecting the camera ➁ Attach or remove the C-mount adapter depending on to a power source and a monitor. the lens to be used. 1) Set AGC mode to off. -
Page 22: Back-Focus Adjustment
Back-focus adjustment WITH A ZOOM LENS 1) Fully open the aperture and set the lens to the maximum When a lens is mounted, adjustment of the back-focus may tele-photo position. Then turn the focus ring to focus. sometimes be required. Adjust the lens focus ring when the In the case of an auto-iris lens only, shoot a comparative- correct focus cannot be obtained. -
Page 23: Specifications
SPECIFICATIONS Signal system IV-CCAM3 : NTSC Shutter speed range 1/60 (1/50 PAL), 1/100, 1/120, IV-CCAM3P : PAL 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/30000, Pickup element Interline transfer 1/3” CCD 1/50000, 1/100000 Second Effective plxels IV-CCAM3 : 768(H) x 494(V) IV-CCAM3P : 752(H) x 582(V) White balance Selectable auto-tracking... -
Page 24: Supplied Accessories
SPECIFICATIONS Power requirement DC11~DC13V Lens connector plug (E4-191J-100) Power consumption 2.5 Watt Operating temperature DC Jack Plug (MP-121M) -10°C to + 50°C (14°F to 122°F) Lens mount cap Operating humidity less than 85% relative C-mount adapter Storage temperature -20°C to + 60°C Operation manual external dimensions 41(W) x 41(h) x 51.6(d)mm...
