Hello
Classic
User's manual

Advertisement

Table of Contents
loading

Related Manuals for Bibo Classic

Summary of Contents for Bibo Classic

  • Page 1 Hello Classic User’s manual...
  • Page 2 We want you to get the most from your BIBO, so before you use it please read this manual carefully. If you have any queries once your BIBO is up and running, please first refer to this manual, it will provide you with helpful and practical advice.

  • Page 3: Table Of Contents

    4 • BIBO overview • The touch screen panel Using your BIBO page 6 • Important: before using your BIBO for the first time • Main features • Menu options & personal settings BIBO information & maintenance page 14 •...

  • Page 4: Meet Your Bibo

    Meet your BIBO BIBO overview 1. Touch screen panel 9. Refrigeration condenser 2. Drip tray cover 10. Hot tank switch 3. Removable drip tray 11. Water inlet 4. 2.8”TFT LCD screen 12. Rear panel 5. Water outlets 13. Cooling fan 6.

  • Page 5: The Touch Screen Panel

    “return” key in menu mode) menu mode) key in menu mode) menu mode) Heating & hot water Chilling & cold water temperature bar temperature bar Menu & set key Water outlet indicator light (red for hot, blue for cold) bibo brighter water...

  • Page 6: Using Your Bibo

    Performance tip: Depending on your local water pressure it may be necessary to reduce the flow of water into your BIBO to control the rate at which the water is dispensed particularly from the hot tank. If the flow from the hot tap is too fast this may reduce the number of consecutive cups of very hot water available in one go.

  • Page 7: Main Features

    Main features To dispense hot water: The BIBO has a safety lock so you must first touch then touch Hot water will flow until you touch any key to stop the water. If you require near-boiling water touch the dispenser will display the following: Once boiling has finished you can dispense water from the BIBO.

  • Page 8: Menu Options & Personal Settings

    The menu allows you to control temperature settings, water quantity settings, time and date settings, energy saving mode, child lock settings, filters and UV lamp change settings, language settings, ring tone settings and there’s also an option to restore BIBO’s factory settings. To enter the menu Touch on the panel, then follow the on-screen prompts.
  • Page 9 Sleep Mode Sleep mode allows you to set your BIBO to go into a low power state if you don’t use it for between 1 and 4 hours. When sleeping the cold water temperature is unaffected and stays chilled; the hot water temperature slowly drops to 60C.
  • Page 10 Power on/off mode Power on/off mode allows you to set your BIBO to come on and go off at different times of day – exactly like your central heating. There are three timed ‘periods’ available when the BIBO can switch itself on then off again. Select the Power option in the menu;...
  • Page 11 If you want to turn your BIBO on before the programmed time, touch any key and the screen will display this: Touch the key to confirm you want it to turn on. When BIBO switches back on again from the power on/off mode, the hot tank will take approximately 5 minutes to heat back up to the maximum temperature and the cold tank will take approximately 15 minutes to chill back down to the minimum temperature.
  • Page 12 Ring/beep setting You can programme your BIBO to beep every time a key is pressed by choosing “Ring” from the main menu, and selecting whether you want it on or off. Restore factory settings To restore all settings to factory settings, choose “Restore”...
  • Page 13 water...

  • Page 14: Bibo Information & Maintenance

    Turn the handle firmly anti-clockwise until the filter cartridge releases, then pull it up and out of the BIBO. In the event that the cartridge is too stiff to turn it may help to relieve the water pressure in the BIBO. To do this turn off the water supply to the BIBO, then touch the key to dispense a small amount of cold water.
  • Page 15 You will see the white top of the UV filter lamp towards the front of your BIBO. When your BIBO was installed you will have been given a white plastic key to release the UV lamp. Put the key into the slot indicated above, release the latch and rotate the UV lamp anti-clockwise to the “OPEN”...
  • Page 16 Cleaning your BIBO Clean your BIBO by simply wiping it down with a damp cloth. Soap or any other gentle detergent can also be used if you wish. The drip tray can be removed and cleaned in your dishwasher.

  • Page 17: Technical Information

    • When your BIBO is turned on for the first time, or after a period of not being used, please run at least 2 litres of water through both the hot and cold outlets before drinking any, to ensure the water is fresh.

  • Page 18: Overview

    • Install the BIBO in a cool, dry place where it is well ventilated. It must be kept away from any heat source. • The rear of the BIBO will get warm so please keep it at least 5cm (2”) away from the wall to ensure that this part of the dispenser is well ventilated.

  • Page 19: Troubleshooting

    If a fault should occur, please first use the troubleshooting guide below to determine the fault type, then follow the steps listed to resolve the issue. This should help you resolve the fault with the minimum effort. If you find that your BIBO is not working properly, or if the problem persists, your BIBO may need to be professionally help@bibowater.co.uk repaired.

  • Page 20: Appendices

    In case you need to turn off the mains water supply to you home, identify were the tap/isolation valve is located. If you have a water softener fitted in your home you can safely connect a BIBO to the softened water supply but please bear in mind that anyone on a low-sodium diet may be advised to avoid artificially softened water because the softening process replaces calcium ions with sodium ions.
  • Page 21 Remove the drip tray then locate 1x (smaller) screw to the left of the drip tray space. Remove the lid of the BIBO then loosen the 3x screws in the top panel that run in a line on the left from front to back.
  • Page 22 BIBO settings). 2. Turn off the water supply to the BIBO by twisting the blue tap at the back of the BIBO so that the lever is at right angles to the white water pipe.
  • Page 23 3. Flick the power and hot tank switches at the back of your BIBO to off (‘0’). 4. At the water connection on the back of your BIBO, twist the blue tap lever so it’s at right angles to the water pipe.
  • Page 24 www.bibowater.co.uk 0800 678 5969 Call us free on...
