Elan Hardware Co HC-600 Operating Manual

Odg v1 / odgv3

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

HC-600

ODG V1 / V3

Model

ON DEMAND COFFEE GRINDER

Designed in EU. Produced in China by Elan (Changzhou) Hardware Co. Ltd

Building #6, #2 Tenglong Rd, Wujin Economic Development Zone, Jiangsu, 213161 China

©ELAN (Changzhou) Hardware Co. Ltd.

Version 2.1, September 2012

Table of Contents

Need help?

Do you have a question about the HC-600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Elan Hardware Co HC-600

Page 1 HC-600 ODG V1 / V3 Model ON DEMAND COFFEE GRINDER Designed in EU. Produced in China by Elan (Changzhou) Hardware Co. Ltd Building #6, #2 Tenglong Rd, Wujin Economic Development Zone, Jiangsu, 213161 China ©ELAN (Changzhou) Hardware Co. Ltd. Version 2.1, September 2012...
Page 2: Warranty Information
WARNINGS This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
Page 3: Table Of Contents
TABLE of CONTENTS 1) Preface………………………………………………….…………………………………………….4. 2) Technical Specifications …….………………..………………………………………………4. 3) General Description …………………………..…………………………………………..……4. 4) Unpacking and installation ……………..…………………………………………………..5. 5) Operation (V1 models) ………………………………………..………………………………6. 6) Operation (V3 models) ……………………………………..…………………………………8. 7) Accessories…………………………………………………….…………………………………10. 8) Safety devices………………………………………………..………………………………….12. 9) Safety instructions………………………………………………………………………….….12. 10) Maintenance and service………………………………….……….…………………….13. 11) Cleaning………………….……………………………………………………….……………….13.
Page 4: Preface
Congratulations for purchasing the HC-600 On Demand Grinder (ODG). The HC-600 is a commercial appliance to be used in coffee shops, espresso bars, hotels, restaurants, and so on. HC-600 will grind whole been coffee into variable, user selectable (from super fine to course) coffee powder and will dose a pre-defined (on V1 models) dose to your espresso machine filter holder.
Page 5: Unpacking And Installation
4) UNPACKING AND INSTALLATION: Warning: All appliances’ technical handling operations such as installation, maintenance, or service should be performed by certified personnel or by your local dealer. After opening the box, make sure that the appliance is intact and that there is no visible damage. If there is •...
Page 6: Operation (V1 Models)
Modes of operation: The HC-600 ODG can be operated in 3 different modes. Activating (or deactivating) each one of the modes, is achieved by single pressing on the relative mode selector button. Once activated, a green LED will turn to ON state on each one of the selectors.
Page 7 Additionally different type of coffee blends and coffee shops are requiring different dose size for their single and double cups (6.5gr to 9.5gr per single cup and 11gr to 18gr for double cup). The HC-600 ODG is supporting the need of the user to change grinding time setting frequently.
Page 8 Fig 5.1 A Modes of operation: The HC-600 ODG V3 grinder is installed with a simple operating main switch consisting of 2 running modes. (fig. 5.1 A) Continues mode, while selecting the ON position, the grinder will run and grind coffee •...
Page 9: Accessories
6) Accessories 1. Porte filter holder accessory (for models sold after August 2009). Fig-1-1 Fig-1-2 1. Notice the two holes under the filter fork support (fig 1-1) 2. Unpack the accessory (fig 1-2), which is packed separately within the grinder packaging. 3.
Page 10 2. Outlet powder restrictor (on models earlier than 2012) Fig-1-1 Fig-1-2 1. In some cases for specific Porte filters’ height you may require to restrict the flow of the outlet powder to avoid unnecessary waste. 2. Unpack the accessory (fig 1-2), which is packed separately within the grinder packaging. 3.
Page 11: Safety Devices
7) SAFETY DEVICES A) Thermal overload protection In order to eliminate the risk of fire the motor is equipped with an overheat protection device which will cutoff the motor’s power supply should it reach a high temperature. In the event that the thermal protection is tripped as a result of malfunction (e.g.: jammed blades, worn out •...
Page 12: Maintenance And Service
9) MAINTENANCE AND SERVICE Warning: All appliances’ technical handling operations, such as installation, maintenance, or service should be performed by certified personnel or by your local dealer. Check the state of the grinding blades periodically (approximately every 50kg of grinded coffee) Good condition blades will result in a high quality grind and prevent the appliances over heating.
Page 13 Cleaning the grinding chamber grinding parts and powder outlet housing Follow the instruction below for grinding chamber and grinding parts cleaning: STEP1 By using a screw driver take out the dial’s safety screw. Rotate the grinding dial clock wise to take it off. STEP 2 Pull out the upper blade holder;...
Page 14 Do not use sharp objects to scrape coffee residue off of the blades or the internal Teflon coating of the outlet • port. Examine both of the blades’ condition and replace them if necessary. • The replacement and assembly of a new set of blades is a delicate task. •...
Page 15: Elan (Changzhou) Hardware Co. Ltd
Add your remarks here Date Event Remark Purchasing Important details and telephone numbers: Local dealer Address: ________________________________________________________________ Telephone number: ____________________Fax number:_______________________ Technician mobile number: ____________________name: __________________ Coffee beans supplier details:_________________________________________________________________ Telephone number: ____________________Fax number:_______________________ ©ELAN (Changzhou) Hardware Co. Ltd. Version 2.1, September 2012...
