Gorke Electronic RSU KO2/2 Specification And User Manual

the set contains: 2-channel RSU KO2/2 receiver and two 2-button PUK 102 remote controls
The operating range: the following range (100m) concerns the open space (without any obstacles, when the
receiver and the remote control can "see each other"). If there are any obstacles between the receiver and the
sender, one must assume that the range would be reduced: for wood and plaster it would be 5-20% lower, for
bricks 20-40% lower, and for reinforced concrete 40-80% lower. If there are many obstacles we advise to
configure sets using the receivers of the SH class, to use retransmitters or stronger remote controls. If there are
metal obstacles, using the radio systems is not recommended. In such situation, one should consider installing
WLC 201 module, which helps to avoid the problem. The double value given in the technical specification of the
remote control concerns cooperating with different types of receivers. The first value (the smaller one) concerns
the superreactive receivers of the RSU type, the second one (the larger one) – with the superheterodyne
receivers, for example OPC, IDO.
Gorke Electronic
SPECIFICATION AND USER's MANUAL: 2-channel RSU-KO2/2 set
SPECIFICATION AND USER's MANUAL
type of the device: 2-channel set, type: RSU KO2/2

TECHNICAL PARAMETERS OF THE RECEIVER

• class: C
• type of receiving module: superreaction
• sensitivity: -100 dBm
• frequency: 433,92 MHz
• radio transmission: Keeloq hopping code by Microchip
Technology
• memory capacity: 14
• voltage supply:
- nominal: 12 V DC
- allowable: 10-15 V DC
• power consumption:
- static: 17 mA
- maximal: 60 mA
• capacity:
- relay output: 1A/ 30 V DC
- S transistor output: 0,5A/ 12 V DC
- sabotage output: 50mA/ 12 V DC
• number of relays: 2
• relay's operating mode: mono or bistable
• time scope for the mono mode: ~1s-4min20s
• operating temperature range: 0 to +40
• dimensions (mm): 48*68*26
• cooperation: any GE sender
• operating range (m)*: 100-500
• colour: white

TECHNICAL PARAMETERS OF THE REMOTE CONTROL

• class: C
• frequency: 433,92 MHz
• transmission: coded (Keeloq hopping code by Microchip
Technology)
• number of buttons: 2
• sending power: <5mW
• power supply: 1 battery 12V
• dimensions (mm): 29*61*11
• colour: black
• cooperation: any GE receiver
• operating range (m):
- with superreactive receiver: 100
- with heterodyne receiver: 200
43-200 Pszczyna, ul. Staromiejska 31b
tel. 032 326 30
www.gorke.com.pl, e-mail:
* range depends on the type of the sender
70, fax 032 447 73 30
biuro@gorke.com.pl
