Summary of Contents for Heden Carat CT-100 FF
-
Page 1: Operation Manual
HEDÉN ® CARAT Hedén Remote Control Unit Hand Unit (Tx) and Reciever unit (Rx) Operation Manual Version 0.9 Beta Copyright © 2014 by Hedén Engineering Co. Hedén Engineering AB SWEDEN www.heden-engineering.com email: sales@heden-engineering.com 1 ... -
Page 2: Table Of Contents
Table Of Contents Introduction…………………………………………………………………………………………………...3 Hand Unit (Tx)………………………………………………………………………………………………...4 Hand Unit buttons-…………………………………………………………………………………………...5 Hand Unit LED´s….………………………………………………………………………………………….6 Hand Unit overview...…………………………………………………………………………………….….7 Receiver (Rx) …………………………………………………………………………………………….…..8 Receiver (Rx) buttons..……………….. ……………………………………………………………..……..8 Receiver (Rx) LED´s….…………………………………………………………………………….……….8 Receiver (Rx) overview…….…………………………………………………………………………….….9 Installation …………………………………………………………….…………………………………….10 Troubleshooting………………….…………………………………………………………………….…...11 Specifications…………………………………………………………………………………………….…12 ... -
Page 3: Introduction
Congratulationsy you are now a proud owner of a high quality product from Hedén Engineering Co. The Hedén Carat CT-100 FF-system is delivered with following parts: 1 x Hand Unit (Tx) 1 x Receiver (Rx) 1 x Digital motor (M21VE,M21VE-L or M26VE) with gear module 0.8... -
Page 4: Hand Unit (Tx)
2. USB The hand unit has a mini-usb connector that is used for the Heden PC GUI. 3. Neckstrap. The neckstrap can be safely attached to the 1/4” SS thread at the bottom of the hand unit. ... -
Page 5: Hand Unit Buttons
Setting the drag of the knob: The drag of the knob can be adjusted. This done by connecting the HLC via the mini-USB port to a PC that runs the Heden GUI. Instructions how to adjust the drag is found in the Heden PC GUI under potentiometer calibration. -
Page 6: Hand Unit Led´s
9. Lens limits button (J) (lens mapping) This function allows the operator to mapp out a part of the total lens travel to correspond to the full travel of the knob. Quick press button (J) to set the first lens limit, LED (I) flashes at 4Hz turn the knob and go to the second desired lens limit and quick press button (J) again, now LED (I) now flashes at 2Hz indicating that a lens limit now is set and ready to use. -
Page 7: Hand Unit Overview
Hand unit Fig 1 A. Power on/off button / Reset button B. Power on LED and battery status LED C. Bluetooth LED D. Camera run LED and motor feedback LED E. Camera Run button and Bluetooth Pairing button F. Auto lens calibration button & serial FIZ button G. -
Page 8: Receiver (Rx)
Receiver (Rx) Receiver can be mounted using Dual-Lock, velcro or by using the ¼” thread and the backside. You can also use the optional V-lock mounting plate. Don´t drill holes in the receiver box as it easily could damage the electronics inside. Bluetooth Pairing Button (6) Press button (6) for at least 2 seconds to start up the Bluetooth pairing process. -
Page 9: Receiver (Rx) Overview
1. Digital motor, Hedén M21VE or M26VE, Lemo 7- pin, EGG.1B.307.CYM 2. Aux motor/ serial , Fujinon Cabrio servo motors Lemo 5-pin, EGG.1B.305.CYM 3. Power in. Lemo 2-pin, EGG.0B.302.CYM (10 – 30 VDC) 4. Power LED (not available on Carat Rx) 5. -
Page 10: Installation
Installation 1. Hand unit with receiver (Rx) , Bluetooth connection mode. Hand unit (Tx) and receiver (Rx) connected in wireless mode Engage motor to lens using appropiate gear module. Make sure that the gears are not to tight. Connect the Dtap power cable to the receiver unit . Connect camera run cable to receiver unit if neccessary Switch on hand unit. -
Page 11: Troubleshooting
Troubleshooting 1. The hand unit will not turn on. Check your battery if the voltage is below 5V it will not start up the hand unit. 2. Motor is not running smooth. Check that the motor the system was delivered with is used. If not please contact us. 3. -
Page 12: Specifications
Wireless system: Bluetooth Long Range Adaptive Radio, 2.4 GHz Radio type approved in US/Canada, Europe & Japan CE & FCC Antenna: External robust, unbreakable Mini-USB interface for Heden PC GUI ¼” thread with neckstrap hole Receiver unit: Dimensions: 70mm x 60mm x 30mm Weight: 135g Power input 10 –... - Page 13 13 ...
