- Page 1 DIGITAL AMPLIFIER SM-DA-8000 OPERATING MANUAL...
-
Page 2: Important Safety Instructions
15. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. 16. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. page 2 | © Copyright 2012 Soundmask Australia Pty Ltd. All Rights Reserved... -
Page 3: Specifications
Description The SM-DA-8000 is an 8 channel digital amplifier, single rack, with an output of 50 watts RMS per channel @ 8 ohms. It features individual channel level control on the front panel, XLR inputs (received from the SM-DX-4800) for each channel and stereo banana jack outputs. -
Page 4: Front Panel Functions
2. XLR inputs – Separate 3-pin XLR connectors are provided for each audio input from the SM-DX-4800 Digital Distributor. All I/O connectors have pin 1 as ground (shield), pin 2 as + and pin 3 as - . 3. Banana jacks – Outputs to Soundmask’s transducers, up to 100 transducers for each pair of jacks. Power Supply External power supply with standard IEC socket and compatible plug for your country (not pictured). - Page 5 SM-DA-8000 Notes: Soundmask Transducer > Each SM-T-2200 pictured (Under oor) represents 100 transducers. SM-T-2200 The SM-DA-8000 is capable of servicing up to 800 transducers. > Diagram not to scale. Contact Soundmask Australia Pty Ltd PO Box 4068 Balwyn VIC 3103...
- Page 6 No liability or otherwise is assumed for the accuracy of this document. No war- ranty is given or implied as to the accuracy of any part of the document. page 6 | © Copyright 2012 Soundmask Australia Pty Ltd. All Rights Reserved...
