Summary of Contents for Eastern Tools & Equipment PT9600DN

  • Page 1 PT9600DN Middle Speed Dome Camera Series User Manual English v1.03...

  • Page 2: Table Of Contents

    WARNING CONTENTS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN 1. Precaution............OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR 2. Features............OTHER OPENINGS ON THE EQUIPMENT. 3.

  • Page 3: Precaution

    2.FEATURES 1.PRECAUTION Refer all work related to the installaion of this product to qualified service The middle speed dome camera series are designed for video surveillance personnel or system installers. applications. The integrated, motorized pan-tilt mechanic allows users to maneuver the camera to any position (360°...

  • Page 4: Packing List

    3.PACKING LIST 4.INSTALLATION Safety Instructions before starting Outdoor - Do not install and operate this appliance in a flammable and / or explosive environment. - Make sure that the installation is done according to the local electricity safety regulations of your country. - Before installation and maintenance, make sure that the appliance is disconnected from the power source.
  • Page 5 4.INSTALLATION 4.INSTALLATION Connector description Using optional accessories The speed dome camera series can be connected to various optional accessories through the standard connector types, which simplifiy the cable handling and avoid possible mistakes. All accessories are tested for max. Compatibility and best performance.
  • Page 6 4.INSTALLATION 4.INSTALLATION RS485 Termination Video Cable Devices using RS485 control are usually connected in daisy-chain which Coaxial cable with 75 Ω impedance with copper conductor at the center and shielded reqiuers termination with 120 Ω resistor on both ends. The following graphic with 95% copper.

  • Page 7: Operating The Speed Dome

    5.OPERATING THE SPEED DOME 6.OSD Initial Screen OSD Menu After powering up, the camera will enter into FIRMWARE V1.03 the self-test mode and display the status Protocol: PELCO The dome camera are equipped with the new OSD Menu function. All operational functions screen (see picture left).

  • Page 8: System Setting

    6.OSD - System Setting 6.OSD - Map System Setting SYSTEM SETTING In the system setting menu, you can modify operation EDIT DOME LABEL and display settings, such as dome label, temperature INITIAL INFO and display of various values on the operational DISPLAY SETUP screen.

  • Page 9: Camera Setting

    6.OSD - Motion, Clear 6.OSD - Camera Setting Camera Setting Motion control C A M E R A S E T T I N G MOTION In the camera setting menu, you can access camera module ZOOM SPEED HIGH AUTO FLIP : Auto.

  • Page 10: Preset, Scan

    6.OSD - Preset, Scan 6.OSD - Patterns, Tours Function Setting FU N C T I O N S E T T I N G Patterns P A TT ER N S In function setting menu, you can define and activate PRESETS Patterns record the user’s movement while different PTZ funcitons, such as preset points, auto...

  • Page 11: Protocol Setting

    6.OSD - Zones and Privacy Mask 7.PROTOCOL SETTING Protocol Setting Zones ZON ES This procedure is needed if a connection of the You can define the zones in the whole PT range up to telemetric control with the keyboard device is 8 zones.

  • Page 12: Address Id

    8. Address ID, 1 to 67 8.Address ID, 68 to 135 Switchnumber (Sw1) Switchnumber (Sw1) Switchnumber (Sw1) Switchnumber (Sw1) Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 0 0 1 0 0 0 1 0 0 0 0 0 0 0 0 0...
  • Page 13 8. Address ID, 136 to 203 8. Address ID, 204 to 255 Switchnumber (Sw1) Switchnumber (Sw1) Switchnumber (Sw1) Switchnumber (Sw1) Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 (Bit)1 2 3 4 5 6 7 8 (Bit)1 2 3 4 5 6 7 8 0 1 0 1 0 1 0 1 0 0 0 1 0 0 0 1...

  • Page 14: Specifications

    9.SPECIFICATION PT9600DN Model Day / Night Signal Format PAL / NTSC Progressive Scanning Image Sensor 1/4 inch Ex-View CCD 530 TVL (High Resolution) H. Resolution Viewing Angle 57.8° (Wide end) 1.7° (Tele end) 36× Opt. / 12× Digital Zoom Min. Illumination Day: 1.4Lx (1/50), 0.1Lx (1/3)
