Outdoor and Indoor Electric Refrigerator
This Refrigerator can be for indoor and outdoor use and is intended for storing beverages
and fresh foods at temperatures higher than 0°C/32°F.
PLEASE READ THE MANUAL THOROUGHLY PRIOR TO
EQUIPMENT SET-UP, OPERATION AND MAINTENANCE.
ref: ORFR-1-verision-2.0-Manual-9-15-2014
ORFR-1
USER'S MANUAL
ORFR-1
1
Advertisement
Table of Contents
Summary of Contents for Summerset Professional Grills ORFR-1
- Page 1 USER’S MANUAL This Refrigerator can be for indoor and outdoor use and is intended for storing beverages and fresh foods at temperatures higher than 0°C/32°F. ORFR-1 PLEASE READ THE MANUAL THOROUGHLY PRIOR TO EQUIPMENT SET-UP, OPERATION AND MAINTENANCE. ref: ORFR-1-verision-2.0-Manual-9-15-2014...
-
Page 2: Installation
■ For proper ventilation, please leave 6" of space at each side of the unit inside of the countertop, and please be sure that the underside of the unit is left unobstructed. And there should be air vent opened to the outside of the island ref: ORFR-1-verision-2.0-Manual-9-15-2014... -
Page 3: Parts Diagram
Upper Shelf ORFR003 Glass Shelf ORFR004 Basket ORFR005 Shelf Support Clip ORFR006 Glass Shelf Protective Pad ORFR007 Shelf Bracket ORFR008 Slide Set ORFR009 Caster ORFR010 Level Adjuster ORFR011 Door Gasket ORFR012 Door Key ORFR013 Upper Hinge ORFR014 Bottom Hinge ref: ORFR-1-verision-2.0-Manual-9-15-2014... - Page 4 Lower Hinges in different corners. Remove the hardware on the Control Panel and Hinges as shown. Place the hinges and door to your preference. Reinstall the Control Panel and Hardware. Each unit comes with a top Left-handed hinge. ref: ORFR-1-verision-2.0-Manual-9-15-2014...
-
Page 5: Control Panel
All units should be plugged into a grounded and properly-sized electrical outlet with appropriate overcurrent protection. Please refer to the electrical requirements on the nameplate. Please make sure that your unit has its own dedicated outlet. Do not use an extension cord. ref: ORFR-1-verision-2.0-Manual-9-15-2014... -
Page 6: Safety Warning
Failure to do so could cause damage to the compressor. ■ Do not defrost the appliance with other electric appliances (for example a hair dryer) and never attempt to scrape /remove ice/frost with sharp objects. Use only enclosed tools or tools recommended by the manufacturer. ref: ORFR-1-verision-2.0-Manual-9-15-2014... -
Page 7: Regular Maintenance
(when the compressor has cycled off) defrost automatically. Defrost water collects inside the drain by passing through the drain outlet in the inner back wall into a drain pan situated above the compressor. From there it automatically evaporates. CLEANING THE CONDENSER COIL ref: ORFR-1-verision-2.0-Manual-9-15-2014... -
Page 8: Troubleshooting
TROUBLE SHOOTING Before requesting any service on your unit, please check the following points. Please note that this guide serves only as a reference for solutions to common problems. ref: ORFR-1-verision-2.0-Manual-9-15-2014... - Page 9 Evaporator coil iced over. (see above) Cabinet is Loose part(s). Locate and tighten loose noisy. part(s). Tubing vibration. Ensure tubing is free from Fan is unbalanced or best blades. contact with other tubing or components. ref: ORFR-1-verision-2.0-Manual-9-15-2014...
