600/
500/
200
CS
CS
IS
IMAGE SCANNER
USER'S MANUAL
MANUAL NO. CS600-UM-152

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Graphtech CS600

  • Page 1 600/ 500/ IMAGE SCANNER USER’S MANUAL MANUAL NO. CS600-UM-152...

  • Page 2: To Ensure Safe And Correct Use

    TO ENSURE SAFE AND CORRECT USE • To ensure safe and correct use of your Image Scanner, read this Manual thoroughly before use. • After having read this Manual, keep it in a handy location for quick reference as needed. •...

  • Page 3: Safety Precautions

    Safety Precautions WARNING Do not disassemble, repair, or remodel this scan- ner. • Such action may cause a fire hazard or electrical shock. No disassembly • Such action could impair the scanner’s performance and cause it to malfunction or break down. If the scanner generates smoke, is abnormally hot, emits a strange odor, or otherwise functions ab- normally, do not continue using it.
  • Page 4 Safety Precautions (Continued) WARNING Do not connect the scanner to a non-rated power supply. • Use of a different supply voltage may result in a fire hazard or electrical shock. Prohibited CAUTION Be sure to ground the earth terminal. • Unless the scanner is grounded, the operator could suffer an electrical shock in case of current leakage.
  • Page 5 Safety Precautions (Continued) CAUTION Be careful not to damage the power cord or the interface cable and never use a damaged cord or cable. • Do not use unnecessary force to bend, pull, twist, or bind the cord and cable, place a heavy object Never damage or on them, nor remodel them.
  • Page 6 Safety Precautions (Continued) CAUTION Do not install, use, or store the scanner in a loca- tion that does not meet the specified temperature and humidity ranges. • Such location may impair the scanner’s perform- ance and cause the scanner to malfunction or break down.
  • Page 7 Safety Precautions (Continued) CAUTION Do not use sharp, pointed articles on the scanner. • Such action may impair the scanner’s performance and cause the scanner to malfunction or break down. Prohibited Do not exert pressure on the scanner. • Such action may impair the scanner’s performance and cause the scanner to malfunction or break down.

  • Page 8: Introduction

    INTRODUCTION Thank you for purchasing a Graphtec CS600/CS500/IS200 Series Image Scanner. The CS600/CS500/IS200 Series scanners are capable of performing high-speed scanning of documents ranging in size from ISO A4 to ANSI E (ISO A4 to ANSI D in the case of the CS500-06 and IS200-06 models).
  • Page 9 Scanner Configuration CS600-11/CS500-11 CS500-06/IS200-11 Note: The stand is an option for the CS500-06 models CS600-11 CS600-11eN CS600-11eN-PRO CS500-11 CS500-11eN CS500-11eN-PRO USB/Ethernet model CS500-06 CS500-06eN-PRO IS200-11 IS200-11eN IS200-11eN-PRO – viii –...
  • Page 10 (Refer to Section 5.1, “Opening and Closing the Top Cover”.) Scanner Warm-up A warm-up period is not usually required for the CS600/CS500/IS200 Series scanners. However, if you plan to scan a color document (in particular a document with many light colors), we recommend that you allow the CS600/CS500/IS200 Series scanners to warm up for 10 minutes before scanning the document.

  • Page 11: Table Of Contents

    Contents TO ENSURE SAFE AND CORRECT USE ............. I Conventions Used in This Manual ..................i Description of Safety Symbols ....................i Safety Precautions ....................... iii INTRODUCTION ..................VII 1. OVERVIEW ..................... 1-1 Features ........................1-1 Unpacking the Scanner ..................1-2 2.
  • Page 12 6. TROUBLESHOOTING PROCEDURES ..........6-1 The scanner is turned on but doesn’t operate at all ..........6-1 The scanner operates improperly after connection to the computer ...... 6-1 The control panel’s red Error lamp is lit ..............6-2 The control panel’s red Error lamp is flashing ............6-3 The document isn’t properly fed to the initial scanning position ......

  • Page 13: Overview

    ITA (Intelligent Thickness Adjustment) Function (CS600 Series models only) The CS600 Series models are capable of scanning documents with a thickness of up to a maximum of 20.3 mm. The ITA function performs automatic detection of the document’s thickness, thereby eliminating complex operations and enabling easy loading...

  • Page 14: Unpacking The Scanner

    (CS500-06/IS200-06) Document support plates Document supports (CS600-11/CS500-11/IS200-11) 1 set Document support wires Thick document support unit (CS600 only) Carrier sheet Calibration/Color correction sheets 1 set • One Calibration sheet • One Color correction sheet* IS0907 : CS600-11/CS500-11/IS200-11 * : CS600/CS500/IS200-PRO only...

  • Page 15: Preparation

    2. PREPARATION 2.1 Assembling the Scanner The stand is an option for the CS500-06 models. CS600-11/CS500-11 Two persons are required for the assembly operation. Assemble the stand before mounting the scanner unit. (1) Assemble the caster frames and the side stays using the four screws provided.
  • Page 16 Side cover Rubber feet Fixing plate Fixing plate Coin screw Coin screw Center bar Fixing plate Notch Groove (4) Secure the side stays in place by tightening up the four center bar fixing screws (see (2) above). 2 – 2 CS600/CS500/IS200...
  • Page 17 Screw A Screw A Frame 3 (7) Always ensure that you remove the cushion material that is included below the document hold-down unit before using the product. (Refer to Section 5.1, “Opening and Closing the Top Cover”.) CS600/CS500/IS200 2 – 3...
  • Page 18 (2) Attach the center bar to the side stays temporarily using the four screws provided. Side stay Side stay Center bar Groove Caster Caster Attach the center bar loosely. Tighten the screws securely after the scanner unit has been mounted on the stand. 2 – 4 CS600/CS500/IS200...
  • Page 19 Side cover Rubber feet Fixing plate Fixing plate Coin screw Coin screw Center bar Notch Fixing plate Groove (4) Secure the side stays in place by tightening up the four center bar fixing screws (see (2) above). CS600/CS500/IS200 2 – 5...
  • Page 20 Screw A Screw A Frame 3 (7) Always ensure that you remove the cushion material that is included below the document hold-down unit before using the product. (Refer to Section 5.1, “Opening and Closing the Top Cover”.) 2 – 6 CS600/CS500/IS200...

  • Page 21: Part Names And Functions

    Top cover Control panel Lock Cover sensor Basket Release Release Document guides Stand Caster CS600-11/ICS500-11 Lock Basket Release Release Stand Caster CS500-06/IS200-11 (The stand is an option for the CS500-06 models.) Top cover Open the top cover to clean the document hold-down unit and transparent contact plates.
  • Page 22 Power switch Ethernet connector AC line inlet connector The above illustration is of the CS600-11/CS500-11 model. Power switch Controls the on/off status of the power supply to the scanner. AC line inlet Connect the power cord’s female plug here. USB connector Used to connect the USB interface cable.
  • Page 23 2. PREPARATION Control panel (CS600) POWER LED POWER Unlit : The scanner is turned off. PAPER ERROR Lit (green) : Lights when the scanner is turned on and remains lit while it is operating normally. SCAN Flashing (orange) : Flashes while the scanner is in power-saving mode.
  • Page 24 : Lowers the top cover. If the document has been inserted on top of the two paper sensors at the front and rear of the scanner, the document thickness is automatically detected. STOP key Compulsorily stops scanning of the document. 2 – 10 CS600/CS500/IS200...
  • Page 25 Feeds the document toward you. When this key is pressed in Scan READY status, the Scan READY status is cancelled and the document is ejected toward the front of the scanner. STOP key Compulsorily stops scanning of the document. CS600/CS500/IS200 2 – 11...

  • Page 26: Attaching The Document Support

    2.3 Attaching the Document Support Always ensure that the document support wires are attached to the scanner unit before scanning a document. Note: Drawings of the CS600-11/CS500-11 model are used for the explanations. Normal documents [Up to 1.5 mm thick]...
  • Page 27 As with the first end, insert the other end of the wire so that it fits into the hidden slot on the lower level. Document support wire end Hidden slot on the lower level CS600/CS500/IS200 2 – 13...
  • Page 28 Document support plate (2) Attach the second document support plate in the same manner. Detach the document support plates when moving or packing the scanner. Lift the plates up and out of the slots to detach them. 2 – 14 CS600/CS500/IS200...
  • Page 29 2. PREPARATION Attaching the thick document support unit (CS600 only) Use the two screws that are provided with the thick document support unit to attach the unit to the rear of the scanner. Make sure that the document support unit is not attached at an angle. If the unit is not attached correctly, the document may not be fed correctly.

  • Page 30: Preparing To Operate The Scanner

    Memory: 256 MB or more Monitor: 1024 × 768 pixels, High Color or higher resolution USB 2.0 interface (that comes standard with your computer) Ethernet interface (100 BASE-TX) For 8-bit/24-bit color data (CS600/CS500/IS200-PRO* only) CPU: Pentium 4 Memory: 512 MB or more Monitor: 1024 ×...

  • Page 31: Connecting The Scanner To A Power Supply

    3. PREPARING TO OPERATE THE SCANNER 3.2 Connecting the Scanner to a Power Supply Note: Drawings of the CS600-11/CS500-11 model are used for the explanations. Connecting the Power Cable Insert the female plug of the power cord provided into the scanner’s AC line inlet and insert its male plug into an electrical socket supplying AC voltage.
  • Page 32 When the scanner has been initialized, the POWER lamp lights up. When resetting the scanner by turning it off then back on again, wait at least five seconds before turning it back on. CS600/CS500/IS200 3 – 3...

  • Page 33: Connecting The Scanner To A Computer

    3. PREPARING TO OPERATE THE SCANNER 3.3 Connecting the Scanner to a Computer Note: Drawings of the CS600-11/CS500-11 model are used for the explanations. The scanner can be connected to a computer using the USB interface or the Ethernet interface.
  • Page 34 (1) Ensure that you have an Ethernet cable that works with your computer. Plug the Ethernet cable into the Ethernet connector located on the right-hand side of the scanner unit. Ethernet connector To the computer Ethernet interface cable CS600/CS500/IS200 3 – 5...

  • Page 35: Connecting The Scanner Via An Ethernet Interface

    Windows Help for more information. Installing the Network Utility The following procedure assumes that you are using the CS600-11eN/11eN-PRO, CS500- 11eN/11eN-PRO, CS500-06eN-PRO, or the IS200-11eN/11eN-PRO connected via an Ethernet interface as part of your system. The scanner name displayed in the windows is the name of the scanner connected to the computer.
  • Page 36 3. PREPARING TO OPERATE THE SCANNER (3) Click [Setup]. (4) Click [Device Setup]. The following window appears. (5) Click [Next] to proceed (6) The “Software License Agreement” window appears. Carefully read the provisions of the agreement. CS600/CS500/IS200 3 – 7...
  • Page 37 When the setting will be performed from a location that a router is used to access, depending on the type of router used, there may be locations that cannot be searched. In this case, make the setting within the same segment. (8) Click [Next] to display the following window.. 3 – 8 CS600/CS500/IS200...
  • Page 38 Please contact your network administrator if you do not know your IP address. Two or more identical IP addresses may cause network problems. (9) Confirm the settings, and then click the [Execute]. (10) This completes the Device Setup operation. CS600/CS500/IS200 3 – 9...
  • Page 39 (14) Click [Yes] to continue with installation. The following window appears. Select the destination folder for installation. To specify a folder, click [Reference] and then select a folder, The default destination folder is C:\Program Files\Graphtec\Graphtec Network Utility. 3 – 10 CS600/CS500/IS200...
  • Page 40 3. PREPARING TO OPERATE THE SCANNER (15) Click [Next]. Specify the program folder name. (16) Click [Next]. (17) Click [Start] to start the installation procedure. (18) When installation has been completed, click [Finish]. CS600/CS500/IS200 3 – 11...
  • Page 41 If Windows XP Service Pack 2 is used to install a network utility, or if Windows XP was updated using Service Pack 2, the following settings must be made. (1) Launch the Control Panel from the [Start] menu. (2) Click the “Security Center” icon. (3) Click “Windows Firewall”. 3 – 12 CS600/CS500/IS200...
  • Page 42 (4) Click “Exceptions” to display the following window. Click [Add Program]. (5) Click [Browse], and then select the “Device Setup” program from the CD-ROM. If the CD-ROM is in drive E: Select [E:\English\Network\Utility\Quickset\Gdsetup.exe], and then click [Open]. Click [OK]. CS600/CS500/IS200 3 – 13...
  • Page 43 Enter “Graphtec Network Utility” in the Name box, 19540 in the Port number box, and then select “UDP”. (7) Click [OK] to add “Graphtec Network Utility” to the “Programs and Services” list. (8) Click [OK] to close “Windows Firewall”. 3 – 14 CS600/CS500/IS200...
  • Page 44 Note: Even if [No] is selected, you can still proceed to the registration window by clicking When entering the IP address, enter both the [IP address] and the [Server Name]. Click [Search] to search for the destination server. CS600/CS500/IS200 3 – 15...
  • Page 45 (4) Click [Register] to connect from the Utility. (5) Click [Connect]. (6) After connecting with the utility, specify the CS600-11eN/11eN-PRO, CS500-11eN/ 11eN-PRO, CS500-06eN-PRO, or IS200-11eN/11eN-PRO driver as appropriate, and perform installation. For further details on the installation procedure, see Section 3.5, “Installing the Driver Software”.
  • Page 46 Set the browser’s proxy server to off when performing the initialization settings. (1) Launch Internet Explorer. (2) Enter “http://scanner IP address/ja/index/htm” in the Address bar at the top of the screen. Example: http://192.168.21.123/ja/index/htm (3) Click “Factory Default”. CS600/CS500/IS200 3 – 17...
  • Page 47 (4) Enter “root” in the User name box and then click [OK]. (User name: root; Password: blank box) (5) The “Do you wish to load the factory default?” window appears. Click [Yes]. (6) The screen shown below is displayed when the setting has been made. 3 – 18 CS600/CS500/IS200...
  • Page 48 (7) Restart the network board. Click “Relaunch Network Scanner” to display the “Are you sure to restart this Network Scanner?” window. Click [Yes]. (8) The following window is displayed after the setting has been made. (9) This completes the initialization of the scanner’s network environment. CS600/CS500/IS200 3 – 19...

  • Page 49: Installing The Driver Software

    Windows with administrator rights. Consult your Windows 2000 or Windows XP manual for more information. For Windows 2000 The following procedure assumes that you are using the CS600-11 connected via the USB interface. The scanner name displayed in the windows is the name of the scanner connected to the computer (CS600-11 is used in this section).
  • Page 50 (5) Select the check box entitled “Specify a location” and click Next. Click [Browse] and select the DRIVER folder in the CD-ROM drive or enter a CD- ROM drive name and \DRIVER using the keyboard. Example: For drive E, enter “E:\DRIVER.” CS600/CS500/IS200 3 – 21...
  • Page 51 Click [Yes] to continue the installation. (8) The screen shown below is displayed when the wizard has finished installing the driver. Click the [Finish] button. (9) The Windows 2000 desktop appears, and the scanner is recognized by the computer. 3 – 22 CS600/CS500/IS200...
  • Page 52 3. PREPARING TO OPERATE THE SCANNER For Windows XP The following procedure assumes that you are using the CS600-11 connected via the USB interface. The scanner name displayed in the windows is the name of the scanner connected to the computer (CS600-11 is used in this section).
  • Page 53 \DRIVER using the keyboard. Example: For drive E, enter “E:\DRIVER.” (5) When you click [Next] the wizard will start searching for the driver. (6) The screen shown below is displayed. Click [Continue Anyway] to continue the installation. 3 – 24 CS600/CS500/IS200...
  • Page 54 (7) The screen shown below is displayed when the wizard has finished installing the driver. Click the [Finish] button to close the “Welcome to the Found New Hardware” wizard. (8) The Windows XP desktop appears, and the scanner is recognized by the computer. CS600/CS500/IS200 3 – 25...

  • Page 55: Checking The Interface Connection

    3.6 Checking the Interface Connection For Windows 2000 The following procedure assumes that the CS600-11 is connected in your system. The scanner name displayed in the windows is the name of the scanner connected to the computer (CS600-11 is used in this section).
  • Page 56 3. PREPARING TO OPERATE THE SCANNER For Windows XP The following procedure assumes that the CS600-11 is connected in your system. The scanner name displayed in the windows is the name of the scanner connected to the computer (CS600-11 is used in this section).

  • Page 57: Installing The Scanning Master 21+ Application

    • If the application has been properly installed, “Scanning Master 21+” will be newly listed in the Program menu accessed from the Start button. For more details, open the README.TXT file provided in the “Scanning Master 21+” folder. 3 – 28 CS600/CS500/IS200...

  • Page 58: Loading A Document

    4.1 Compatible Document Types Because the scanner scans a document while feeding it, the document types that it can scan are subject to the following restrictions. Compatible Media Widths for Scanning Documents with a maximum width of 1066 mm (CS600-11/CS500-11/IS200-11) Size Size ANSI 210 mm ×...
  • Page 59 Diazo photo-sensitive paper Compatible Media Thicknesses for Scanning The CS600 scanner cannot scan a document that is thicker than 0.8 inches (20.3 mm). When thick paper is scanned, the material used and the condition of the document may affect the quality and precision of the scanned results.

  • Page 60: Loading A Document

    4. LOADING A DOCUMENT 4.2 Loading a Document Document Loading Flowchart (CS600 only) Start document loading Is the document thicker than 1.5 mm Attach the document Attach the document support wires. support unit. (See“Section 2.3, Attaching the (See “Section 2.3, Attaching the Document Supports”...
  • Page 61 Document edge This ensures that the document does not get damaged if it is fed at an angle. Document guides Document-scanning table The above illustration is of the CS600-11/CS500-11 model. 4 – 4 CS600/CS500/IS200...
  • Page 62 • Load the document in the center of the scanner, as the document may be fed in at an angle and not scanned correctly if it is significantly off-center. (CS600 only) • When loading a thick document, make sure that there is sufficient space in front of and behind the scanner.
  • Page 63 4. LOADING A DOCUMENT Detecting the thickness of the document to be scanned (CS600 only) [When scanning a thick document (thicker than 1.5 mm)] (1) Press the ITA key to switch to ITA mode (the ITA LED lights). (2) When the document is placed over the paper sensor as shown below and inserted into the recess, the top cover starts to rise automatically after approximately two seconds.
  • Page 64 (3) When the ITA LED stops flashing, remove your finger from the REVERSE key. (4) With the ITA LED in the unlit status, press the ITA key to switch to READY mode (the READY LED lights). CS600/CS500/IS200 4 – 7...

  • Page 65: Handling Documents According To Their Material And Thickness

    • The end of the document is not scanned. Such problems may be avoided by taking the following corrective measures. • Lower the scanning speed. • Support the document at the front and the back of the scanner. 4 – 8 CS600/CS500/IS200...

  • Page 66: Distance Correction

    The values entered here must be within the range of the distance correction. (6) Click the OK button to calculate the correction value. The distance will be corrected the next time a document is scanned. CS600/CS500/IS200 4 – 9...

  • Page 67: Using The Carrier Sheet

    Transparent sheet (front surface) Target document (the surface to be scanned faces up) White surface (background surface) The above illustration is of the CS600-11/CS500-11 model. • When handling the carrier sheet, be very careful not to scratch it or otherwise damage it.
  • Page 68 4. LOADING A DOCUMENT CS600/CS500/IS200 4 – 11...

  • Page 69: Daily Maintenance

    90 degrees. Top cover Open levers The above illustration is of the CS600-11/CS500-11 model. (3) Close the top cover until the left and right latches on the top cover lock into position, making sure that you don’t get your fingers caught.

  • Page 70: Cleaning The Document Hold-Down Unit

    Latch Latch The above illustration is of the model. CS600-11/CS500-11 (3) Wipe clean the underside of the document hold-down unit (see below) using a soft cloth that has been soaked in water or diluted neutral detergent and thoroughly wrung out.

  • Page 71: Cleaning The Image Sensors

    Transparent contact plates The above illustration is of the model. CS600-11/CS500-11 (4) Completely remove any moisture on the transparent contact plates by wiping them off again using a soft, dry cloth. (5) Close the top cover as described in Section 5.1 “Opening and Closing the Top Cover”.
  • Page 72 (unexpected white or black streaks in the data) due to scratches on the transparent contact plate or other reasons, please perform the calibration procedure (see Section 5.6, “Calibration”). If the scanning results do not improve after calibration, the transparent contact plate(s) will need to be replaced. 5 – 4 CS600/CS500/IS200...

  • Page 73: Cleaning The Paper Sensors

    Paper sensors The above illustration is of the model. CS600-11/CS500-11 (4) Close the top cover as described in Section 5.1 “Opening and Closing the Top Cover”. Take care not to get your fingers caught in the cover. Use a cotton swab or something equally soft to gently wipe the paper sensors. Do not use any chemicals to clean the sensors.

  • Page 74: Removing A Jammed Document

    Select the procedure that is appropriate for your scanner model and/or document thickness. CS600 (thin document up to 1.5 mm thick)/CS500/IS200 (1) Turn off the scanner. (2) Open the top cover as described in Section 5.1 “Opening and Closing the Top Cover”.
  • Page 75 5. DAILY MAINTENANCE CS600 (documents thicker than 1.5 mm) (1) Press the ITA key to switch the scanner to ITA mode (the ITA LED lights). (2) Hold down the FORWARD key. The top cover will start to rise. The ITA LED flashes while the cover is rising.

  • Page 76: Calibration

    A low-resolution monitor will make it difficult to discern any problem areas. Calibration of the document-thickness settings for the CS600 scanner is performed in the status that is set for thin documents. (See “Detecting the thickness of the document to be scanned”...
  • Page 77 (1) Connect the scanner to the computer. Switch on the scanner, then switch on the PC. (2) Launch the Scanner Adjustment program (as described earlier). (3) Select Model Setup on the Scanner menu. (4) Select the connected scanner and click the [OK] button. CS600/CS500/IS200 5 – 9...
  • Page 78 (8) Clicking the [OK] button begins calibration. (9) Calibration ends after approximately 10 minutes. Click the [OK] button to complete calibration. (10) To check the calibration results, click the Confirm button in the Calibration menu (shown in step (5) above). 5 – 10 CS600/CS500/IS200...
  • Page 79 (17) Return to step (10) and verify the calibration results. If you perform the calibration procedure several times with no discernible results, there may be a problem with the scanner itself. In this case, please contact your Graphtec vendor. CS600/CS500/IS200 5 – 11...
  • Page 80 Graphtec vendor. Color correction sheet (for the CS600-11/CS500-11/IS200-11eN-PRO models) Color correction sheet (for the CS500-06 model) (1) Select Color Correction on the Scanner menu.
  • Page 81 (6) Click in the center of the color tile indicated by the numbers 1 to 6 (1 to 4 in the case of the CS500-06 model). Align the cursor crosshairs with the printed lines at the sides of the tile. CS600-11/CS500-11/IS200-11eN-PRO models Cursor lines (red) Align with the printed lines, then click.
  • Page 82 (11) Click the Fit icon to display the entire image, and check whether there is any discrepancy in color. If there is no discrepancy, color correction is complete. Click the Close button. If there is still some color discrepancy after performing Color Correction, repeat steps (6) through (11). 5 – 14 CS600/CS500/IS200...

  • Page 83: Troubleshooting Procedures

    (when using the Ethernet connection) Has Windows XP Service Pack 2 been Windows XP Service Pack 2 provides a higher installed in your computer? security level. See page 3-12 and make the (when using the Ethernet connection) settings accordingly. CS600/CS500/IS200 6 – 1...

  • Page 84: The Control Panel's Red Error Lamp Is Lit

    Set the “Model Setup” settings in Scanning correctly set in Scanning Master 21+. Master 21+ to match the scanner that is connected (CS600-**, CS500-**, IS200-**). For details, see the Scanning Master 21+ User’s Manual. Is the “Connection Method” of the Ensure that the “Connection Method”...

  • Page 85: The Control Panel's Red Error Lamp Is Flashing

    (the surface to be scanned) facing down. The scanning conditions set were Set the scanning conditions again (they can be inappropriate for the document. controlled from the scanning software provided). CS600/CS500/IS200 6 – 3...

  • Page 86: The Image Quality Has Dropped

    Moreover, fine adjustment to correct such deviation can be performed using the driver software if the deviation causes are overlapped or missing data. Overlapped data Original document Data overlaps Missing data Original document Data is missing Deviation due to scanner specifications Original document Deviation caused by specifications 6 – 4 CS600/CS500/IS200...
  • Page 87 Document feed direction Sensor 2 Sensor 3 Sensor 1 Markings on the document scanning table Document feed direction Because the document is loaded face down, Sensor 1 is the leftmost sensor in the driver software’s display windows. CS600/CS500/IS200 6 – 5...

  • Page 88: Smudges Not Appearing In The Original Document Appear In The Scanned Data

    (Scanning Master 21+) provided with for a document of a different paper type. your scanner, select the Distance Correction The scanning precision varies according function to adjust the precision. to the type of document. 6 – 6 CS600/CS500/IS200...

  • Page 89: Stripes Or Moiré Patterns Which Are Not In The Original Document Appear In The Scanned

    Cause Remedy The scanner’s image scanning quality has Run the “Scanner Adjustment Program” deteriorated. (see Section 5.6, “Calibration”), and perform calibration. You are using a carrier sheet with a color Don’t use the carrier sheet. document. CS600/CS500/IS200 6 – 7...

  • Page 90: The Document Cannot Be Fed Correctly

    The thick document that has been inserted Press the ITA key to raise the top cover. is slipping, and cannot be fed. (CS600) Remove the document, and then reload it. 6.16 “Document size cannot be acquired” is displayed Cause...

  • Page 91: The Document Stops During The Thickness-Detection Process

    Foreign matter is obstructing the document Remove the document, and then remove the movement. foreign matter. The safety sensor has been activated. The paper jam sensor has been activated. Press the FORWARD key to raise the top cover. CS600/CS500/IS200 6 – 9...
  • Page 92 6. TROUBLESHOOTING PROCEDURES 6 – 10 CS600/CS500/IS200...

  • Page 93: Appendix A. Optional And Miscellaneous Items

    Stand (for the CS500-06 model) Consumables Code Item name IS0907 Carrier sheet (A0) IS0908 Carrier sheet (A1) IS0917 Calibration/Color correction Sheets (CS600-11/CS500-11/IS200-11eN-PRO) IS0918 Calibration/Color correction Sheets (IS200-11eN) IS0915 Calibration/Color correction Sheets (CS500-06) EM-CP Cleaning paper (50 sheets) CS600/CS500/IS200 A – 1...

  • Page 94: Appendix B. Standard Specifications

    APPENDIX B. STANDARD SPECIFICATIONS APPENDIX B. STANDARD SPECIFICATIONS Item CS600-11eN/CS600-11eN-PRO Document size ANSI E to ISO A4 Maximum width: 1092 mm; minimum width: 210 mm Effective scanning area Width : 1066.8 mm (centered) Length : 16 m* If the thickness exceeds 1.5 mm, 762 mm (30 inches) maximum Guaranteed scanning 841 mm x 1189 mm, maximum thickness 1.5 mm...
  • Page 95 The precision figures above were measured under the operating conditions described below. • Special test chart used : Mylar sheet #200 • Guaranteed precision conditions : Temperature 20°C ±3°C; Humidity: 60% ±10% RH *4 The USB 2.0 and Ethernet interfaces cannot be used at the same time. B – 2 CS600/CS500/IS200...
  • Page 96 The precision figures above were measured under the operating conditions described below. • Special test chart used : Mylar sheet #200 • Guaranteed precision conditions : Temperature 20°C ±3°C; Humidity: 60% ±10% RH *4 The USB 2.0 and Ethernet interfaces cannot be used at the same time. CS600/CS500/IS200 B – 3...
  • Page 97 • Special test chart used : Mylar sheet #200 • Guaranteed precision conditions : Temperature 20°C ±3°C; Humidity: 60% ±10% RH *4 The USB 2.0 and Ethernet interfaces cannot be used at the same time. *5 PRO only. B – 4 CS600/CS500/IS200...

  • Page 98: Appendix C. External View

    APPENDIX C. EXTERNAL VIEW APPENDIX C. EXTERNAL VIEW External Dimensions CS600-11/CS500-11 1205 IS200-11 1205 CS500-06 Unit : mm Dimensional precision error : ± 5 mm CS600/CS500/IS200 C – 1...

  • Page 99: Index

    Troubleshooting .......... 6-1 FORWARD key ........... 2-9 USB connector ........... 2-8 Usage precautions ........ix IEEE 1394 connector ......... 2-8 Image sensors, cleaning the ..... 5-3 Warmup ............ix Interface ............1-1 Missing data ..........6-4 Overlapped data ......... 6-4 CS600/CS500/IS200 Index – 1...
  • Page 100 The specifications, etc., in this manual are subject to change without notice. CS600-UM-152 OCTOBER 15, 2005 1nd edition-01 GRAPHTEC CORPORATION...

This manual is also suitable for:
