  • Page 1 VIZIO USER MANUAL Models E50-C1 & E55-C1...
  • Page 2 This product qualifies for ENERGY STAR in the “factory default” setting and this is the setting in which power savings will be achieved. Changing the factory default picture settings or enabling other features will increase power consumption that could exceed the limits necessary to qualify for ENERGY STAR rating.

  • Page 3: Important Safety Instructions

    Welcome THANK YOU FOR CHOOSING VIZIO IMPORTANT SAFETY INSTRUCTIONS And congratulations on your new VIZIO HDTV. Your TV is designed and manufactured to operate within defined design limits. Misuse may result in electric shock or fire. To To get the most out of your new VIZIO product, read these prevent your TV from being damaged, the following instructions instructions before using your product and retain them for future should be observed for the installation, use, and maintenance of...
  • Page 4 source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or   local power company. • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or •...
  • Page 5 • WARNING: Keep your TV away from moisture. Do not - The performance of your TV changes substantially. expose your TV to rain or moisture. If water penetrates into • This apparatus shall not be exposed to dripping or your TV, unplug the power cord and contact your dealer. splashing and no objects filled with liquids, such as vases, Continuous use in this case may result in fire or electric shall be placed on the apparatus.
  • Page 6 TELEVISION ANTENNA CONNECTION Lightning Protection PROTECTION For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system. If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system Power Lines...

  • Page 7: Table Of Contents

    Table of Contents Installing the TV .............9 Adjusting the Color Tuner Settings ........32 Creating a Custom Picture Mode ........35 Inspecting the Package Contents ..... . 9 Locking and Unlocking the Custom Picture Modes ...
  • Page 8 Setting the Time Zone ............51 Adding an App to the My Apps Tab ........67 Using the Parental Controls ..........52 Deleting an App from the My Apps Tab ......67 Accessing the Parental Controls Menu ......52 Moving an App in My Apps ..........68 Enabling or Disabling Program Ratings ......

  • Page 9: Installing The Tv

    Installing the TV INSPECTING THE PACKAGE CONTENTS Before installing your new TV, take a moment to inspect the package contents. Use the images below to ensure nothing is missing or damaged. VIZIO LED HDTV Remote Control 2 x Quick Start Guides with Batteries (1 x English, 1 x French/Spanish) TV Stands...

  • Page 10: Installing The Tv

    INSTALLING THE TV To install the stands: After removing the TV from the box and inspecting the package contents, you can begin installing the TV. Your TV can be installed in two ways: • On a flat surface, using the included stand •...
  • Page 11 Insert the left and right stands into the base of the TV. (The stands are identical.) Secure each stand to the TV with two Phillips screws (included). Insert the screws into the back of the TV and tighten them using a Phillips screwdriver. When you are finished, place the TV on a stable, level surface.

  • Page 12: Installing The Tv On A Wall

    To mount your TV on a wall, you will need a wall mount. Consult Installing a TV on a wall requires lifting. To prevent injury or damage to the TV, ask someone to help you. E50-C1 E55-C1 Screw Size: Hole 200 mm (V) x 200 mm (H)

  • Page 13: Front Panel

    REMOTE SENSOR & POWER INDICATOR When using the remote, point it directly at this sensor. The power indicator flashes on when the TV turns on, then goes out after several seconds. To keep the power indicator on as long as the TV is on, see Turning the Power Indicator On or Off on page 56.

  • Page 14: Rear Panel

    REAR PANEL Note:  The image shown here is for illustrative purposes only and may be subject to change.  The actual number of ports and their locations may vary, depending on the model. USB - Connect a USB thumb drive to play photos, music, or video. HDMI - Connect an HDMI device.

  • Page 15: Remote Control Front

    APP LAUNCHER Quickly launch the pictured App. (Also turns on the TV if it is off.) INPUT POWER Change the currently displayed input. Turn TV on or off. A/V CONTROLS Control USB media player and video streaming playback. MENU CLOSED CAPTIONS Display the on-screen menu.
  • Page 16 Replacing the Batteries 1. To remove the battery cover, press on the logo and slide the cover out. 2. Insert two batteries into the remote control. Make sure that the (+) and (-) symbols on the batteries match the (+) and (-) symbols inside the battery compartment.

  • Page 17: Connecting Your Devices

    Connecting Your Devices CONNECTING A DEVICE Your TV can be used to display output from most devices. Cable/Satellite Box 1. Verify that your device has a video port that matches an available port on the TV (HDMI-1, HDMI-2, Comp, etc.). 2.

  • Page 18: Connecting A Device - Audio And Video Cable Types

    CONNECTING A DEVICE - AUDIO AND VIDEO CABLE TYPES AV CABLE COAXIAL CABLE AV cables (or Composite cables) are the traditional way Coaxial cables are the traditional way of connecting of connecting your devices to your TV. Video signals are antennas and cable television signals to your TV.
  • Page 19 COMPONENT CABLE HDMI CABLE Component cables are designed to carry HD (high HDMI is the intelligent, all-digital interface that delivers definition) video signals along with additional audio both dazzling quality and unmatched ease of use. HDMI connections. Colors are delivered with color information technology transmits crystal-clear digital video along with over three connectors for video (separated into red, multi-channel surround audio.

  • Page 20: Connecting An Audio Device

    CONNECTING AN AUDIO DEVICE Your TV can output sound to an audio device, such as a receiver or sound bar. Home Audio Receiver 1. Verify that your device has an audio port that matches an available port on the TV (HDMI, Optical, or RCA). 2.

  • Page 21: Connecting An Audio Device - Audio Cable Types

    CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES RCA CABLE OPTICAL/SPDIF CABLE HDMI CABLE RCA cables (or Composite cables) are the traditional Optical/SPDIF cables transmit audio signals as HDMI technology transmits crystal-clear digital way of connecting your devices to your audio pulses of light through a cable made of plastic multi-channel surround audio through a single device.

  • Page 22: Connecting An Audio Device - Arc

    CONNECTING AN AUDIO DEVICE - ARC Without HDMI ARC With HDMI ARC Built-in Tuner Built-in Tuner VIZIO Internet Apps Plus ® VIZIO Internet Apps Plus ® Your TV Your TV HDMI transmits Without an HDMI ARC setup, all-digital audio from your TV your TV needs an extra cable to your home audio receiver, to connect it to your home...

  • Page 23: Connecting To Your Network

    CONNECTING TO YOUR NETWORK Your TV is Internet-ready. It can be connected to your home Connecting to a Wireless Network network with a Wired or Wireless connection. 1. Ensure you have a router or modem broadcasting as high-speed wireless signal (802.11n recommended). Connecting to a Wired Network (Best) 2.

  • Page 24: Completing The First-Time Setup

    Completing the First-Time Setup The first time you turn on the TV, the Setup App will guide you 4. Use the Arrow buttons on through each of the steps necessary to get your TV ready for use. the remote to highlight your country, and then press the OK Before you begin the first-time setup: button.
  • Page 25 8. Use the Arrow buttons on the remote to highlight your TV source and press OK. If you have cable TV, select whether you have a cable box or if you connect the TV directly to a cable from the wall. 9.

  • Page 26: Using The On-Screen Menu

    Using the On-Screen Menu Your TV features an easy-to-use on-screen menu. CHANGING THE INPUT SOURCE To open the on-screen menu, press the MENU button on the remote. External devices such as DVD players, Blu-ray Players, and video game consoles can be connected to your TV. To use one of these From this menu, you can: VIZIO devices with your TV, you must first change the input source in the...

  • Page 27: Changing The Screen Aspect Ratio

    CHANGING THE SCREEN ASPECT RATIO The TV can display images in five different modes: Normal, Stretch, • Wide stretches a 4:3 aspect ratio picture to the edges of Panoramic, Wide, and Zoom. Each mode displays the picture the screen. Since the picture is being stretched, the display differently.

  • Page 28: Viewing Video With The Menu Open

    VIZIO VIEWING VIDEO WITH THE MENU OPEN Wide Zoom Normal Panoramic When the on-screen menu opens, it covers the left-hand portion of VIZIO the picture. The picture can be displayed in three different ways: Wide Zoom Normal Panoramic PICTURE • Overlay - The picture stays in its normal position and the Exit Picture Mode...

  • Page 29: Adjusting The Picture Settings

    ADJUSTING THE PICTURE SETTINGS Your TV display can be adjusted to suit your preferences and viewing 4. To manually change each of the picture settings, use the Up/ conditions. Down Arrow buttons on the remote to highlight that picture setting, then use the Left/Right Arrow buttons to adjust the To adjust the picture settings: setting: 1.

  • Page 30: Adjusting The More Picture Settings

    Adjusting the More Picture Settings • Game Low Latency - Reduces video delay (lag) when gaming. Select On or Off. This option is not available for To adjust the More Picture settings: devices connected using a coaxial cable. 1. From the PICTURE menu, use the •...

  • Page 31: Adjusting The Color Temperature

    Adjusting the Color Temperature Adjusting the Picture Mode Edit Settings Adjusting the color temperature changes the white balance of the To adjust the Picture Mode Edit settings: picture. 1. From the PICTURE menu, use the To adjust the color temperature: VIZIO Arrow buttons to highlight More VIZIO...

  • Page 32: Adjusting The Color Calibration Settings

    Adjusting the Color Calibration Settings Adjusting the Color Tuner Settings The Color Tuner settings allow you to adjust the Hue, Saturation, Color Calibration Settings allow you to make precise adjustments to and Brightness (HSB) color and 11 point white balance, turn color the picture and to create picture modes to save groups of picture channels off for testing, and display color bar, flat, and ramp test settings.
  • Page 33 To turn color channels off and on: To adjust the 11 Point White Balance settings: 1. From the PICTURE menu, use the Arrow buttons to highlight 1. From the Color Tuner menu, use the Arrow buttons to Color Calibration and press the OK button. The COLOR highlight Color Tuner, and then press the Left/Right Arrow CALIBRATION menu is displayed.
  • Page 34 To show or hide the Color Bar Test Pattern: To show or hide the Flat Test Pattern: 1. Ensure that you are on an input that is displaying active 1. Ensure that you are on an input that is displaying active content.

  • Page 35: Creating A Custom Picture Mode

    To show or hide the Ramp Test Pattern: Creating a Custom Picture Mode Custom picture modes allow you to save a group of custom settings 1. Ensure that you are on an input that is displaying active for various viewing conditions and video sources. content.

  • Page 36: Locking And Unlocking The Custom Picture Modes

    Locking and Unlocking the Custom Picture Modes Deleting a Custom Picture Mode Custom picture modes can be locked with a unique PIN to prevent Custom picture modes that are no longer needed can be deleted. accidental changes to their settings. Inputs assigned to a deleted custom picture mode To lock all custom picture modes: become assigned to the Calibrated picture mode.

  • Page 37: Adjusting The Audio Settings

    ADJUSTING THE AUDIO SETTINGS volume leveling off. • Balance - Adjusts the loudness of the audio output from Adjusting audio settings creates a custom audio mode which can be the left and right speakers. further modified or restored to factory defaults (deleted). •...

  • Page 38: Changing The Equalizer Settings

    Changing the Equalizer Settings Delete the Custom Audio Mode To select a pre-set audio mode: To delete the custom audio mode: 1. Press the MENU button on the remote. The on-screen menu is 1. Press the MENU button on the remote. The on-screen menu is displayed.

  • Page 39: Setting Timers

    SETTING TIMERS Setting the Auto Power Off Feature To help save energy, your TV is set by default to turn off after This TV has timers that save energy, can turn off the TV when you go 10 minutes without a video or audio signal. This feature can be to sleep, and can blank the screen when you stream music.

  • Page 40: Blanking The Screen

    Blanking the Screen You can blank the screen while there is audio streaming. This feature helps save energy and the life of the screen. To blank the screen: • From the TIMERS menu, use the Up/Down Arrow buttons on the remote to highlight Blank Screen, and then press OK.

  • Page 41: Using The Network Connection Menu

    USING THE NETWORK CONNECTION MENU Changing the Manual Setup Settings Advanced users can fine-tune the network settings using the Manual Your TV is Internet-ready, featuring both an Ethernet port and Setup feature. built-in high-speed Wireless-N. To change advanced network settings: Connecting to a Wireless Network 1.

  • Page 42: Finding Mac Addresses For Network Setup

    Finding MAC Addresses for Network Setup Connecting to a Hidden Network The security settings on your router may require you to enter the To connect to a wireless network whose network name (SSID) is not TV's MAC address in the router's settings. being broadcast: To find the TV's MAC address: 1.

  • Page 43: Setting Up Channels

    SETTING UP CHANNELS Selecting a Channel Source 1. On the remote control, press Input and use the Arrow button You can use the TV’s Tuner menu to: to highlight TV (antenna icon), then press OK. • Select a channel source 2.

  • Page 44: Adding New Channels

    Adding New Channels To add a single new analog channel: Occasionally, you may need to add a new range of channels or add 1. From the CHANNELS menu, VIZIO a new analog channel. You can do this by using the Partial Channel highlight Add Analog Channel Search and Add Analog Channel options.

  • Page 45: Skipping Channels

    Skipping Channels After a channel scan is completed, you may find that some channels are too weak to watch comfortably. There may also be some channels you do not want to view. You can remove these channels from the TV’s memory with the Skip Channel feature. Channels that have been removed with the Skip Channel feature can still be viewed if the channel is entered using the Number Pad.

  • Page 46: Changing The Audio Language

    Changing the Audio Language To use the Digital Language feature: Some free-to-air, cable, and satellite channels broadcast programs in more than one language. The Analog Audio and Digital Language 1. From the CHANNELS menu, features allow you to listen to audio from Secondary Audio VIZIO highlight Digital Language Programming (SAP).

  • Page 47: Setting Up Closed Captioning

    SETTING UP CLOSED CAPTIONING Changing the Appearance of Digital Closed Captions Digital closed captions can be displayed according to your Your TV can display closed captions for programs that include them. preference. See the diagram on the next page for an explanation of Closed captions display a transcription of a program’s dialogue.
  • Page 48 • Background Color - Change the color of the background Typical choices include: directly behind the text. • Opaque background, transparent window—Only a strip of • Background Opacity - Change the transparency of the background appears behind the text, expanding as the text background directly behind the text.

  • Page 49: Renaming Inputs (Using The Devices Menu)

    RENAMING INPUTS (USING THE DEVICES MENU) Inputs can be renamed to make them easier to recognize on the Input menu (see Changing the Input Source on page 26). For Input Port example, if you have a DVD player connected to the Component input, you can rename that input to display “DVD Player.”...

  • Page 50: Changing The Tv Settings

    CHANGING THE TV SETTINGS Viewing System Information To view technical data and status information about your TV and Using the system menu, you can: network connection: • View technical system and 1. Press the MENU button on the remote. The on-screen menu is VIZIO networking information displayed.

  • Page 51: Changing The On-Screen Menu Language

    Changing the On-Screen Menu Language Setting the Time Zone Your TV can display the on-screen menu in different languages. To ensure the correct time is displayed when you press the GUIDE button, set the TV’s time zone: To change the on-screen menu language: 1.

  • Page 52: Using The Parental Controls

    Using the Parental Controls Enabling or Disabling Program Ratings The TV’s parental controls allow you to prevent the TV from To manage program content according to its rating, you must displaying certain channels or programs without a password. enable the Program Rating feature. The Parental Controls menu only appears when: To enable or disable the Program Rating feature: •...

  • Page 53: Blocking And Unblocking Content By Rating

    Blocking and Unblocking Content by Rating Changing the Parental Control Passcode A channel may sometimes broadcast programs that are meant for If you use the parental controls, you should change the passcode to children, and at other times broadcast programs that are meant prevent children from accessing inappropriate material.

  • Page 54: Changing The View Mode Settings

    Changing the View Mode Settings Adjusting the Wide Mode (Aspect Ratio) You can resize the video content to fit while the menu is open. The TV can display images in five different modes: Normal, Stretch, Panoramic, Wide, and Zoom. Each mode displays the picture To change the on-screen menu language: differently.

  • Page 55: Changing Your Tv's Dlna Name

    Changing Your TV's DLNA Name Controlling Other Devices with CEC DLNA allows your TV to display content from DLNA-certified The CEC function on your TV enables you to control devices computers, cameras, tablets, and smartphones. connected to the HDMI (ARC) input with the included remote, without any programming.

  • Page 56: Turning The Power Indicator On Or Off

    To begin device discovery: Turning the Power Indicator On or Off • From the CEC menu, highlight Device Discovery and press The Power Indicator on the front of your TV normally does not glow when the TV is on. You can change this setting if you prefer the light to be on.

  • Page 57: Restoring The Tv To Factory Default Settings

    Enabling and Disabling Smart Interactivity Restoring the TV to Factory Default Settings You can use the TV’s Reset & Admin menu to restore the TV to its Your TV can display program-related information as part of a factory default settings. broadcast.

  • Page 58: Using The Guided Setup Menu

    USING THE GUIDED SETUP MENU The TV’s Setup App can be used to easily set up channels on the TV or to connect the TV to your network. To use guided setup: 1. Press the MENU button on the VIZIO remote.

  • Page 59: Using The Info Window

    USING THE INFO WINDOW The Info Window can be displayed by pressing the GUIDE or INFO buttons on the remote: • Press the GUIDE or INFO button once to display channel, input, and display information. • Press the GUIDE or INFO button twice to display the program title, program rating, audio information, and the start and end times of the program.

  • Page 60: Using The Usb Media Player

    Using the USB Media Player USING THE USB MEDIA PLAYER Displaying USB Media To display your USB media: The USB media player allows you to connect a USB thumb drive to 1. Connect your USB thumb drive to the USB port on the side of your TV and view photos.
  • Page 61 Back Button Back Button Folder Contents Highlight this button and Highlight and press OK to return to left column. This area displays the contents of press OK to return to the the currently selected folder. You Connected previous screen. can browse files and folders using Sources Current Folder the Arrow and OK buttons on the...
  • Page 62 Now Playing Information Displays song title, album title, and artist name. Back Button Album Art Highlight this button and Progress Bar If included on the USB press OK to return to the Displays the duration of the current- thumb drive and associated previous screen.
  • Page 63 Back Button Highlight this button and press OK if you would like to return to the previous screen. Connected Sources VIZIO Displays Video connected USB USB1: MyFlashDrive devices. MyFlashDrive\Video\root\My Videos File Date Duration Family Vacation - California 00:23:43 Current Folder 26th Birthday Party 00:38:18 My Videos...

  • Page 64: Using Vizio Internet Apps Plus (V.i.a. Plus)

    Using VIZIO Internet Apps Plus (V.I.A. Plus) ® Vizio Internet Apps Plus (V.I.A. Plus) delivers popular online content Using the App Launcher Keys to your TV. V.I.A. Plus features a selection of Apps that allow you to Use the App Launcher keys on the remote to launch the apps watch movies and TV shows, listen to music, get weather and news pictured on the buttons.

  • Page 65: Using The Fullscreen V.i.a. Plus Apps Window

    USING THE FULLSCREEN V.I.A. PLUS APPS WINDOW The Fullscreen V.I.A. Plus Apps Window allows you to add and store 3. Press the OK button on the remote to launch the App. Apps. The Apps on the first page are displayed in the Dock and 4.

  • Page 66: Fullscreen V.i.a. Plus Apps Window Overview

    FULLSCREEN V.I.A. PLUS APPS WINDOW OVERVIEW The Fullscreen V.I.A. Plus Apps Window allows you to add, delete, • All Apps: Displays every App that is available for download. and organize your Apps. The My Apps tab displays Apps that are •...

  • Page 67: Customizing The V.i.a. Plus Apps Window

    CUSTOMIZING THE V.I.A. PLUS APPS WINDOW Deleting an App from the My Apps Tab To delete an App from your TV: You can add, delete, and move Apps around on your My Apps tab 1. Use the Arrow buttons on the remote to highlight the App you for a custom look and feel.

  • Page 68: Moving An App In My Apps

    Moving an App in My Apps You can organize your Apps on your My Apps tab by moving them 3. Use the Arrow buttons to move the App to the desired location and press OK to place the App. When you can move the App, it where you want.

  • Page 69: Troubleshooting & Technical Support

    Troubleshooting & Technical Support Do you have questions? Find answers at SUPPORT.VIZIO.COM Find help with: • New product setup • Connecting your devices • Technical problems • Product updates and more Live chat support available You can also contact our award-winning support team at: Phone: (877) 698-4946 (toll-free)
  • Page 70 The TV displays “No Signal.” There is no sound. • Press the INPUT button on the remote control to select a • Press Volume Up on the remote control. different input source. • Press the MUTE button on the remote to ensure mute is •...
  • Page 71 The image quality is not good. I see “noise” or static on the screen. • For the best image quality, view high-definition programs • When your TV’s digital capabilities exceed a digital using digital sources. Connect your devices with HDMI broadcast signal, the signal is up-converted (improved) to cables.

  • Page 72: Specifications

    Specifications E50-C1 E55-C1 Screen Size: 50" Class 55" Class Viewable Area: 49.50" 55" Dimensions w/ Stand: 44.24" x 28.27" x 10.04" 48.76” x 30.75” x 10.04” w/o Stand: 44.24" x 25.91" x 2.52" 48.76” x 28.39” x 2.52” Weight w/ Stand: 28.44 lbs...
  • Page 73 E50-C1 E55-C1 Remote Control Model: XRT122 XRT122 Certifications: UL, cUL, NOM, FCC Class B, BET7/ICES-003 Class B, IC, IFETEL, HDMI (CEC, ARC), Dolby Digital Compliance: Energy Star 6.1, NRCan, CONUEE, NOM-032 Voltage Range: 120V @ 60 Hz 120V @ 60 Hz Power Consumption: 58.8W...

  • Page 74: Limited Warranty

    Limited Warranty ON PARTS AND LABOR and set-up issues or any repairs attempted by anyone other than by a VIZIO authorized service center. Products with unreadable or removed serial Covers units purchased as new in United States and Puerto Rico Only. VIZIO numbers, or requiring routine maintenance are not covered.

  • Page 75: Legal & Compliance

    Legal & Compliance FCC Class B Radio Interference Statement Radiation exposure statement: NOTE: This equipment has been tested and found to comply with the limits This equipment complies with FCC radiation exposure limits set forth for an for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits uncontrolled environment.
  • Page 76 FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF VIZIO SOFTWARE LICENSE AGREEMENT CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION The following terms and conditions govern the use of any software on your WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
  • Page 77 products or services purchased, that is gathered periodically to facilitate the any way responsible for any such use by you. provision of software updates, product support and other services to you, 7. Internet Access Required. To use these VIA Services, you must obtain access including additional or different VIA Services related to the VIZIO Software to the Internet, either directly or through devices that access the Internet and and to verify compliance with the terms of this License Agreement.
  • Page 78 OF VIA SERVICES AND THIRD PARTY LICENSORS (COLLECTIVELY REFERRED TO purposes prohibited by United States law, including, without limitation, the AS “VIZIO” FOR THE PURPOSES OF SECTIONS 10 AND 11) HEREBY DISCLAIM development, design, manufacture or production of missiles, or nuclear, ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE VIZIO SOFTWARE chemical or biological weapons.
  • Page 79 © 2015 VIZIO INC. ALL RIGHTS RESERVED. 141208OC-US-NC...
