Summary of Contents for DJ-Tech iVisa 500 BT
- Page 1 500 BT PORTABLE PA FOR iPod / iPhone / iPad USER MANUAL(ENGLISH)-------------------------------------------------------------------------------------E1-E10...
-
Page 2: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION The lightning flash with arrowhead symbol CAUTION inside an equilateral triangle is intended to RISK OF ELECTRIC SHOCK alert User that the presence of uninsulated DO NOT OPEN hazardous voltage within the product’s enclosure, which may be of sufficient CAUTION: TO REDUCE THE RISK OF ELECTRIC magnitude to induce a risk of electric shock to SHOCK, DO NOT REMOVE COVER (OR BACK). -
Page 3: Table Of Contents
CONTENTS FUNCTION DESCRIPTION......................…..4 OPERATION......................…......5-8 CD PLAYER……………………………………………………………………………………………...……5 Wireless MIC……………………………………………………………………………………….….….…..6 IPod/iPhone/iPad……………………………………………………………………………………..….6 Bluetooth /. MP3………………………………………………………………………………………….…6 Wired Mic/Instrument……………………………………………………………………………………...7 Line-IN……………………………………………………………………………………………………..7 Output……………………………………………………………………………………………….….…….7 Remote Control…………………………………………………………………………………….……….8 NOTES ON BATTERY......................……….9 CONNECTION……………………….......…………............9 SPECIFICATIONS..........................10... -
Page 4: Function Description
FUNCTION DESCRIPTION 1.Intelligent iPod/iPad docking 7.Battery Compartment 2.CD Player 8.Easy GripHandle 3.Wireless Microphones Section 9.iPod/iPhone/iPad section 4.CD Section 10.USB/Bluetooth section 5.Mic/Instrument input Section 11.Line-In Section 6 Heatsink 12.AC Power Input (100~240V 50/60Hz) -
Page 5: Operation
Please turn CD player to OFF when the CD player is not in use in order to save power (NOTE: This button is NOT main ON/OFF of iVisa 500 BT, only for the CD player) 8. Repeat/Shuffle/Enter During Playback, you can press this button to select playback mode (repeat /... -
Page 6: Wireless Mic
OPERATION 1. Microphone 1 LED This LED indicates the connection of wireless Microphone 1. When Microphone 1 is connected, this LED and the LED in the font panel will be ON. 2. SIGNAL LED This LED will be turned ON when there is signal on wireless MIC1 or MIC2. 3. -
Page 7: Wired Mic/Instrument
This output is taken from the signal of master output but independent of master volume level. You may connect the other iVisa 500 BT or another active PA speaker to link them up. Or you may also connect a external recorder 8. -
Page 8: Remote Control
OPERATION Remote Control The iVisa 500 BT includes a wireless IR remote and you can make use of the remote to access the docked iPod/iPhone/iPad with the easy simple remote button: 1. Wireless Microphones LED This LEDs indicate the connection of wireless Microphone 1 or 2. When... -
Page 9: Notes On Battery
Low-Battery Protection Power will be cut automatically when battery is too low to operate. User has to connect iVisa 500 BT to AC source in order to charge and operate. Please do not leave the unit unused with a discharged battery inside. -
Page 10: Specifications
SPECIFICATIONS Speaker Unit..............................Woofer 8 8 ..............................Tweeter 1 8 Maximum Power Output Storage battery and power supplied cell....................32W THD=1% Rated Output Power ..........................50W THD= 1% Distortion................................... 0.5% S/N Ratio................................... 80dB Frequency Response............................30Hz 20KHz Input Sensitivity LINE....................................-3dB MP3 Player................................... 0dB Blue tooth..................................0dB iPod, iPhone,iPad.................................0dB CD Player..................................0dB Talkover................................0dB -20 dB...
