Thank you for purchasing the INADA CHAIR yUMEROBO Rotary Rocker Technology. You can enjoy various types
of massage for relieving or soothing fatigue.
We hope the INADA CHAIR yUMEROBO Rotary Rocker Technology will be a valued partner in your daily health
preservation for many years to come.
Please read this Operating Manual before use.
Keep this Operating Manual nearby so that you can refer to it anytime.
This product is designed for home use.
ENGLISH
HCP-R100D
CONTENTS
SAFETY PRECAUTIONS ·················· 1
MAIN FEATURES ······························ 4
BEFORE USE ······································ 7
POSITION ADJUSTMENT ············· 10
AFTER USE ······································· 13
PROGRAMS & SELECTION ·········· 14
STARTING A MASSAGE ················ 15
MASSAGE ADJUSTMENTS ·········· 17
TROUBLESHOOTING ···················· 19
FAQ ···················································· 21
CARE AND STORAGE ····················22
SPECIFICATIONS ····························23
Operating Manual
Warranty card provided separately
··········20
··········22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yume Robo HCP-R100D and is the answer not in the manual?

Questions and answers

Related Manuals for Inada Chair Yume Robo HCP-R100D

Summary of Contents for Inada Chair Yume Robo HCP-R100D

  • Page 1: Table Of Contents

    Thank you for purchasing the INADA CHAIR yUMEROBO Rotary Rocker Technology. You can enjoy various types of massage for relieving or soothing fatigue. We hope the INADA CHAIR yUMEROBO Rotary Rocker Technology will be a valued partner in your daily health preservation for many years to come.

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS Be sure that you have read these SAFETY PRECAUTIONS thoroughly before using your INADA CHAIR yUMEROBO Rotary Rocker Technology for the first time. The Operating Manual contains important information about how to use the chair safely and correctly, avoiding possible damage to property or injury to persons using the chair and others.
  • Page 3 Safety Precautions: Before Use Caution Do not use any other power supplies except alternating voltage 220-240V for HCP-R100D. May result in re or electric shock. Do not use with any type of transformer device. May result in damage to the chair or electric shock. Do not use the chair, if the power cord or plug is damaged, or if the wall outlet connection is loose.
  • Page 4 SAFETY PRECAUTIONS Safety Precautions: During Use Caution In an emergency, or if you nd any abnormal condition, push the EMERGENCY STOP button on the remote control to stop operation immediately. If you get acute pain or other unusual physical discomfort while using the chair, immediately discontinue the use of the chair and seek medical advice.

  • Page 5: Main Features

    Benefits As a therapeutic massage device in the general households, the INADA CHAIR yUMEROBO Rotary Rocker Technology provides the following benefits: Relaxes muscles Relieves minor muscle aches and pains...

  • Page 6: Components & Description

    COMPONENTS & DESCRIPTION Rollers Neck Massage Unit Reclining Seat Back Normally stored inside the upper part of Back Cover Back Pad the seat back. Leg Rest LED Wheels Armrest (right) Power Connector a Neck Air Cushion Armrest (left) Main POWER Switch b Seat Air Cushion Seat Cord Connector...
  • Page 7 Turns the remote control power ON and OFF. Pushing the POWER button while the chair is activated causes the rollers to return to the starting position, after which the chair turns itself off. 1 POWER Button The button lights in green while the power to the remote control is ON, lights in orange while the power is OFF, and flashes in red while the chair is stopped in...

  • Page 8: Before Use

    BEFORE USE This product is shipped with the reclining seat back in its fully reclined position. Be sure to raise the seat back to its fully upright position. Do not expose the chair to sudden bursts of heat. If the room where the chair is to be used is cold, turn the heat up slowly.
  • Page 9 How to Transport or Move the Chair Turn the main POWER switch to OFF and disconnect the plug from the wall outlet before moving the chair. To Move with the Wheels To Carry Raise the reclining seat back to its upright position, hold Fully recline the seat back and carry the chair by holding the front of the leg rest, and then move the chair on the the upper part of the seat back and the front of the leg...
  • Page 10 BEFORE USE Main Power Connection First, plug the power Set the main POWER cord into the cord switch located at the rear connector located at the right of the chair to ON. rear right of the chair. Then, plug the other end into the wall outlet.

  • Page 11: Position Adjustment

    POSITION ADJUSTMENT How to Sit When the chair is off, the rollers are normally drawn back into the left and right sides of the upper part of the seat back (storage position). For the safety, first check the position of the rollers. If they are in any position other than storage positions, turn the main POWER switch on before sitting down to allow the rollers to return to their storage position.
  • Page 12 POSITION ADJUSTMENT How to Install and Remove the Cover of the Neck Massage Unit The chair is shipped with a cover covering the neck massage unit. Remove the cover with the following procedure. Open the zipper Remove the cover from the kneading area Cover Zipper Kneading Area...
  • Page 13 How to Use the Leg Rest Vertical Adjustment To raise the leg rest: Press the top LEG REST button to raise the leg rest. To lower the leg rest: Press the bottom LEG REST button to lower the leg rest. Movement Range of Leg Rest If the leg rest is raised while the seat back is upright, it will only rise to a certain height.

  • Page 14: After Use

    POSITION ADJUSTMENT How to Use the Reclining Seat Back To raise the reclining seat back: Press the top RECLINE button to raise the reclining seat back. To lower the reclining seat back: Press the bottom RECLINE button to lower the reclining seat back. Reclining Movement Range The chair reclines up and down in conjunction with the movement of the seat back and leg rest.

  • Page 15: Programs & Selection

    PROGRAMS & SELECTION PRESET The preset programs make it easy to select a program that suits your preferences or objectives. PROGRAMS Master Shiatsu This program gives a full-body massage using expert techniques. Healthcare Programs Programs that include Stretch massages for recovering from muscle fatigue.

  • Page 16: Starting A Massage

    STARTING A MASSAGE Turn on the power Press the POWER button to turn on the power. (The POWER button lights in green.) * If no selection is made within 5 minutes, the power is automatically shut off. Select a program Preset Programs selected Manual Selection Mode selected Preset Program Massages...
  • Page 17 The program starts Preset Programs starts Manual Selection Mode starts Adjustment in Preset Programs Adjustment in Manual Selection Mode The air can be canceled or its intensity adjusted. A basic operation can be changed and the air can be canceled or its intensity adjusted. When shiatsu point locating is completed, the Complete light turns on and the program starts.

  • Page 18: Massage Adjustments

    MASSAGE ADJUSTMENTS Human Hands Each time the button is pressed, switches between Neck Shiatsu, Shoulders, and Off. Speed Width Up/Down Operation Action Adjustment Adjustment Adjustment Neck This performs shiatsu to the neck. This performs a shoulder kneading Shoulders massage. * Before selecting neck shiatsu, turn over the neck massage unit to the rear. Knead/Tap Each time the button is pressed, switches between Kneading, Tapping, Kneading &...
  • Page 19 Various Adjustments Shoulder Position Adjustment If the correct shoulder position is not set during shiatsu position search, adjust the shoulder position while the locator indicator is flashing. The rollers move up while this button is pressed. Too High The rollers move down while this button is pressed.

  • Page 20: Troubleshooting

    TROUBLESHOOTING If there is still a problem after trying the solutions given in this troubleshooting guide, stop using the chair immediately to prevent accident or injury, and unplug the power plug from the wall outlet. Contact the vendor or your nearest service center for assistance.

  • Page 21: Regular Maintenance For Safety

    These noises are a normal part of the chair’s operation and do not affect its Noise during chair operation performance in any way. The following noises are made during operation. Noises during tapping Sound of the rollers rubbing against the seat cover during kneading Sound of raising and lowering the rollers, sound of roller operations...

  • Page 22: Faq

    Can someone who is under 150 cm or over 180 cm Can I put the chair onto an electric carpet? use the chair? Do not place the chair onto an electric carpet Yes. because it could cause a fire. The chair is very heavy, so it could damage the heat Because the correct shoulder positions may not be generating parts of the electric carpet and start a found during shiatsu point locating, we recommend...

  • Page 23: Care And Storage

    CARE AND STORAGE Storage After wiping off any dust or dirt, store the product in a place that is relatively dry. If you are not going to use the product for some time, put a cover on it that will protect it from dust and dirt. Pets can sometimes chew on power cords, so try to keep pets away from the product even when it is being stored.

  • Page 24: Specifications

    SPECIFICATIONS Model Number HCP-R100D AC 220 V 50 Hz Power Supply AC 220-240 V 50-60 Hz Power Consumption 140 W Rated Time 30 minutes Kneading Speed 3 levels, from minimum 10 times/minute to maximum 32 times/minute (approx.) Tapping Speed 3 levels, from minimum 180 times/minute to maximum 500 times/minute (approx.) Roller Width 3 steps (narrow, medium and wide)
