Owner's Manual
Model:
Kawasaki Teryx 750™
Caution:
Before using this
product, read this
manual and follow all
Safety Instructions.
1
Kawasaki Teryx 750*
Roof / Windshield Kit
Safety Instructions
Kit Contents
Assembly Instructions
™
*DefenderCab
cabs and accessories are in no way affiliated
with Kawasaki Heavy Industries Ltd™. Any use of the name is only
to identify their utility vehicle as it pertains to our accessories.
Kawasaki and teryx are registered trademarks of Kawasaki heavy
industries Ltd.
Advertisement
Table of Contents
Summary of Contents for Defender Kawasaki Teryx 750
- Page 1 Owner’s Manual Model: Kawasaki Teryx 750™ Kawasaki Teryx 750* Roof / Windshield Kit Safety Instructions Kit Contents Caution: Assembly Instructions Before using this ™ *DefenderCab cabs and accessories are in no way affiliated product, read this with Kawasaki Heavy Industries Ltd™. Any use of the name is only to identify their utility vehicle as it pertains to our accessories.
-
Page 2: Safety Instructions
Warning: Failure to heed all safety and operating instructions and / or warnings regarding use of this product can result in serious bodily injury. SAFETY INSTRUCTIONS Read entire assembly instructions Dress for safety. DO NOT wear loose before beginning work. clothing, gloves, neckties or jewelry if using power tools to assemble this Install all parts indicated in assembly... - Page 3 Roof / Windshield Kit Contents Your DefenderCab™ should contain the parts listed below. Separate all parts from packing materials. Do not discard packing material until assembly is complete. Item quantities are listed in parenthesis below. Panels. (1) Plastic Roof Panel (1) Steel Windshield Panel Hardware (1) 25ft Roll, High Density Foam Gasket...
- Page 4 Kit Installation 1. Vehicle Preparation Fig.1 i) Loosely install rubberized clamps onto rollcage at approximate locations shown in (Fig.1). Ensure tabs are pointing towards the interior of the vehicle on the (6) windshield panel clamps. (Fig.2) Fig.2 Fig.3 ii) Temporarily install windshield panel onto vehicle;...
- Page 5 2. Installation iii) Adhere high density foam gasket Fig.4 to top portion of hood using marker line as centerline guide to ensure windshield panel will sit squarely onto foam after installation. If desired, install small edge trim to side edges of windshield panel and cut to suit.
- Page 6 vii) Align roof clamps front to rear Fig.7 and provide equal spacing about vehicle centerline. Transfer clamp holes to roof panel using a 3/16” drill bit. (Fig. 7) viii) Fasten roof panel to rollcage Fig.8 Screw using (4) #10-32 screws, washer and nyloc nuts.
