Elmo TNC4604X Instruction Manual

Ccd color video camera

Advertisement

Quick Links

I N S T R U C T I O N M A N U A L
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
Do not use any power supply other than
specified.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
* The CAUTION label is attached on the
bottom of camera.
T N C 4 6 0 4 X
INFORMATION
This equipment has been tested and found
to comply with the limits for Class A digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment
is operated in a commercial environment.
This equipment generates, use, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a
residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his
own expense.
USER-INSTALLER CAUTION:
authority to operate this FCC verified
equipment could be voided if you make
changes or modifications not expressly
approved by the party responsible for
compliance to Part of the FCC Rules.
Your

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TNC4604X and is the answer not in the manual?

Questions and answers

Summary of Contents for Elmo TNC4604X

  • Page 1 T N C 4 6 0 4 X I N S T R U C T I O N M A N U A L INFORMATION CAUTION RISK OF ELECTRIC SHOCK This equipment has been tested and found DO NOT OPEN to comply with the limits for Class A digital CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS 1. Read Instructions 12. Lightning All the Safety and operating instructions should be For added protection for this video product during a read before the appliance is operated. lightning storm, or when it is left unattended and 2. Retain Instructions unused for long periods of time, unplug it from the The safety instructions and instruction manual wall outlet and disconnect the power supply and...
  • Page 3: Part Names And Functions

    PART NAMES AND FUNCTIONS All dimensions in mm (inch) Lens mount DC12V Mount a CS-mount lens. Camera mount For mounting a camera on bracket, housing, AC24V etc. (1/4"-20UNC thread) Focusing dial Refer to "HOW TO USE" on page 3 for adjustment of the lens back-focus.
  • Page 4: How To Use

    HOW TO USE 1. Adjust the iris and focus of the lens so that optimum image CS-mount CS-mount may be obtained. Lens Lens * Usable lenses 4mm or less 4mm or less CS-mount lenses, whose length "L" (in the illustration) from the bearing surface of the mount is 4mm or less if protruded, should be used.
  • Page 5: Camera Controls

    CAMERA CONTROLS FLICKERLESS switch(Set at OFF position from the factory) When this switch is turned ON, the shutter speed is set to 1/100 second. It is effective in reducing the light intensity. Caution: When this switch is turned ON, AES does not operate. SENS-UP switch(Set at OFF position from the factory) Turn ON this switch to raise the sensitivity.
  • Page 6 White balance selector Manual or Automatic white balance modes are selectable. With the setting at AUTO position, the camera automatically adjusts to the color temperature and adjusts the white balance. The camera is factory-set at AUTO position. For manual adjustment, set to MANU position and set the white balance switches as follows.
  • Page 7: Specification

    SPECIFICATION Model TNC4604X Power source DC12V (DC11V-35V) AC24V (AC15V-27V) 60Hz 0.5Hz Power consumption Approx.4.5W Approx.4.0W Pick-up device 1/3"Color interline-transfer CCD Effective picture element 768 (H) x 494 (V) Scanning area 4.9mm (H) x 3.7mm (V) Scanning system 2:1 interlaced Scanning frequency (H) (V) Int : 15.734kHz 59.94Hz, LL : 15.75kHz 60Hz...
  • Page 8 Should it gets wet, turn off the power * The socket-outlet should be installed near the immediately and contact your dealer. equipment and should be easily accessible. are registered trademarks of ELMO COMPANY, LIMITED. ELMO CO., LTD. 6-14, Meizen-cho, Mizuho-ku, Nagoya, 467-8567 Japan OVERSEAS SUBSIDIARY COMPANIES ELMO Mfg.
