NOTE
ADSworldwide strive to improve their products continuously, and therefore reserve the right to make
changes to drawings and technical specifications at any time without notice
CE
ADS
WORLDWIDE
(AUDIO DESIGN SERVICES LIMITED)
St David's House, Adcroft street, Higher Hillgate, Stockport, SK1 3HW
Tel: +44 (0161) 66 66 363
E-mail: sales@ads-worldwide.net Web Site: WWW.ads-worldwide.net
ISSUE: 1
8/2000
Fax: +44 (0161) 66 66 366
INSTALLATION AND OPERAT-
ING
INSTRUCTIONS
ADS -1015
MIXER AMPLIFIER
A D S
w o r l d w i d e
(AUDIO DESIGN SERVICES LIMITED)
Quality at every level
Advertisement
Table of Contents
Summary of Contents for ADSworldwid ADS -1015
- Page 1 ADSworldwide strive to improve their products continuously, and therefore reserve the right to make changes to drawings and technical specifications at any time without notice INSTALLATION AND OPERAT- INSTRUCTIONS ADS -1015 MIXER AMPLIFIER WORLDWIDE (AUDIO DESIGN SERVICES LIMITED) A D S St David’s House, Adcroft street, Higher Hillgate, Stockport, SK1 3HW...
-
Page 2: Ads - 1015 Mixer Amplifier
NOTES ADS - 1015 MIXER AMPLIFIER FRONT PANEL MASTER VOLUME TONE MIC1 PHONO / AUX CD MIC2 MICROPHONE MIC1 1/4” JACK SOCKET MIC2 1/4” JACK SOCKET MIC1 MIC2 PHONO / AUX CD TONE MASTER VOLUME MAINS POWER SWITCH PL LED... - Page 3 NOTES ADS - 1015 MIXER AMPLIFIER REAR PANEL AC FUSE HOLDER LOUDSPEAKER TERMINALS / DC TERMINALS PHONO / AUX CD SWITCH PHONO AUX CD AC / DC SWITCH...
-
Page 4: Safety Information
SPECIFICATIONS SAFETY INFORMATION WARNING : THIS APPLIANCE MUST BE EARTHED RMS Output power 15 Watts into 8 ohm at 1 kHz IMPORTANT he wires in the mains lead are coloured in accordance with the following code: Constant Voltage output 100V Constant Impedance output 4 - 16 ohm Green and yellow:... - Page 5 POSSIBLE INTERFACES Fire Dragon Loudspeaker Loading Cougar Horn Kestrel Cabinet Column Sigma Ceiling Loudspeaker Loudspeaker Loudspeaker Loudspeaker To allow sufficient transient overload margin it is suggested that the output load should not exceed approximately 70% of the rated power output DC Power The equipment may be operated from a battery power source.
-
Page 6: Microphone Connections
MICROPHONE CONNECTIONS Booster Output Microphone 1 Microphone 1 uses a standard 1/4” mono Jack plug. NOT APPLICABLE The input is unbalanced and designed for low impedance microphones. Microphone 2 Microphone 2 uses a standard 1/4” mono Jack plug. The input is unbalanced and designed for low impedance microphones. Constant Voltage Output 100V For use with loudspeakers designed for 100V line systems.
