O.K.I. usa WDS-HDR1527DN Operating Manual

Wide dynamic series, hyper dynamic series day & night olpf removable digital color video camera
Hide thumbs

Advertisement

Quick Links

Download this manual
OPERATING MANUAL
Before attempting to connect or operate this product, please read these instructions
completely
Hyper Dynamic Range
ON-SCREEN-DISPLAY, HIGH RESOLUTION, 12V DC / 24V AC
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
AND DO NOT REMOVE COVER OR BACK.
CAUTION
1. CONNECT 24V AC UL LISTED CLASS 2 POWER SUPPLY.
2. INSTALL CAMERA UNDER UNSTABLE LIGHT SOURCE MAY
3. ONLY USE CAMERA UNDER CONDITIONS WHERE
ATTENTION:
INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE
PERSON AND SHOULD CONFORM TO ALL LOCAL CODES
WDS-HDR1527DN
WDS-HDR1527DNP
Day & Night OLPF Removable
DIGITAL COLOR VIDEO CAMERA
:
:
CAUSE ABNORMAL FUNCTION.
TEMPERATURES ARE BETWEEN
-10°C to 50°C.

Advertisement

loading
Need help?

Need help?

Do you have a question about the WDS-HDR1527DN and is the answer not in the manual?

Questions and answers

Summary of Contents for O.K.I. usa WDS-HDR1527DN

  • Page 1 OPERATING MANUAL Before attempting to connect or operate this product, please read these instructions completely Hyper Dynamic Range WDS-HDR1527DN WDS-HDR1527DNP Day & Night OLPF Removable DIGITAL COLOR VIDEO CAMERA ON-SCREEN-DISPLAY, HIGH RESOLUTION, 12V DC / 24V AC WARNING TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND DO NOT REMOVE COVER OR BACK.
  • Page 2 1. General This color CCD video camera employs a solid-state imaging device with 470 / 410K or 310 / 270K picture elements. This unit is equipped with a newly developed DSP (Digital Signal Processor) for processing the video signal. This camera has dynamic range 400:1, surveillance under various critical backlighting environments are always possible.
  • Page 3 3. Name of Parts and Functions 12V DC / 24V AC MODEL A. C (CS) mount adapter if a CS mount lens is to be used, remove the C mount ring B. Holder screw hole Standard photographic pan-head screw size (1/4” – 20) Flange focal lock screw C.

  • Page 4: User Osd Setting

    1.Red --- power 3.White --- video 2.NC 4.Black --- shielded Auto iris lens without EE amp. (DC Type) Set the lens selector to “DD” position. Connector cable leads 1. Damping coil (-) 3. Driving coil (+) 2. Damping coil (+) 4.

  • Page 5: Setting Menu And Functions

    RS-232 Connection Please refer to the Setup option In the program window (com2 default) RX pin----SD (D-sub 9) pin 3 from PC TX pin----RD (D-sub 9) pin 2 from PC GND------GND (D-sub9) pin 5 1/O port The port can send or received signal by external device. Select option mode by OSD D/N function The camera can switch day or night by external device when it select External mode.
  • Page 6 6. Setting Procedure 6.1 Camera Identification Setting (CAMERA ID) Move cursor to CAMERA ID then press ENTER key to enter ID sub menu CAMERA ID Blinking 0 1 2 3 4 5 6 7 8 9 : Character Area A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g Editing Data Area...
  • Page 7 6.3 Light Control Move cursor to LIGHT CNTL then press ENTER key to enter sub menu SETUP MENU WD MENU CAMERA ID MODE INDOOR1 SENSE UP FLICKERLESS OFF Press LIGHT CNTL WD MODE ENTER to WHITE BAL sub menu PICTURE VIDEO RETURN MISC...
  • Page 8 6.3.2.1 NORMAL mode sub menu NORMAL MENU TYPE • Type Move cursor to TYPE and press LEFT or RIGHT to change Auto Exposure TYPE E-ZOOM • Mode sequence: RETURN AUTO IRIS Shutter speed of each mode: mode: 1/50(1/60) to 1/100,000 sec. AUTO IRIS mode: 1/50(1/60) sec mode: 1/50(1/60) to 1/100,00 sec.
  • Page 9 6.3.2.1.2 E-ZOOM sub menu Press LEFT or RIGHT key to change 3 types E-ZOOM, press ENTER key back to previous menu. E-ZOOM 01 ← → 6.4 WHITE BALANCE SETUP MENU Move cursor to WHITE BAL then press ENTER key to enter CAMERA ID SENSE UP sub menu...
  • Page 10 6.5 PICTURE CONTROL Menu item: VIDEO → GAMMA → APERTURE→ VIDEO • Video Menu VIDEO MENU 1. Brightness level setting BRIGHT PEDESTAL 1.0 IRE Move cursor to BRIGHT position, while observing the color video monitor or waveform monitor / oscilloscope, press RETURN LEFT or RIGHT key to adjust the brightness level.
  • Page 11 DELAY TIME- Sets the detecting time. The color/ monochrome mode switches if the brightness level change specified. You can select 10 sec, 30sec or 60sec LUX/ DELAY MUNE 2. SCHEDULE (D.N SWITCH TIME) LUX LEVEL This function can set the time to change the Day/ Night DELAY TIME 10 SEC mode.
  • Page 12 6.8 MISC This function is to adjust the camera’s synchronization and lens applications. Move cursor to MISC and press ENTER. MISC MENU EXT SYNC AUTO IRIS DC LENS H/V MIRROR MASK SYSTEM HOUR: MIN: SYSTEM TIME: DISPLAY RETURN 1. EXTSYNC Press LEFT or RIGHT key to select the type of camera’s synchronization, then press ENTER key to enter external sync phase adjusting menu.

  • Page 13: Specifications

    7. SPECIFICATIONS Model WDS-HDR1527DN WDS-HDR1527DNP TV System NTSC Image Device 1/3" Sony Wide Dynamic Double Speed CCD Picture Elements 811(H) x 508(V) 795(H) x 596(V) Scanning System 525 lines 625 lines Sync System DC Internal / AC Line Lock Sync...
  • Page 14 - 14 -...

This manual is also suitable for:

Wds-hdr1527dnp
