in4 care UP-6S86 User Manual

COMPLETE PARTS LISTING

Hearing Aid x 1
Charging Case x 1
Ear Cap (Large x 2, Medium x 1, Small x 2)
Cleaning Brush x 1
AAA Battery x 2
AC Adapter
Replacement: Ear Cap (L,M,S) x 1 / each

HEARING AID FEATURES

Hearing Aid:
Speaker
Volume Adjustment Dial
Turn the dial to adjust
the Hearing Aid volume.
Adjusting the dial to the lowest
setting will turn the Hearing Aid
OFF.
Charging Case
Night Light
Charging Status
Indicator
Ear Cap Sizes Image
Large
Medium
Small
CHARGING
INSTRUCTIONS
Ear Cap
Soft silicon ear cap. Three
interchangeable sizes are provided.
Charging Indicator and
Power Indicator are both
green
Microphone
Power
Indicator
Charging
Indicator
The Bionic Ear is
recharging normally.
Battery/AC Power
Indicator
Please note that the rechargeable battery inside the Hearing Aid should only be
removed and/or replaced by Hearing Assist, LLC. Attempting to self service any
part of the Hearing Aid or case will void the warranty.
AC Adaptor Input
• When the battery is low on the Hearing Aid, an audible sound will alert the user that
the battery is low and needs to be charged.
• A full charge takes about 7-12 hours, and will allow for up to 6-10 hours of usage.
• The rechargeable battery is designed to last for at least 500 recharge cycles.
Afterwards, the battery will need to be serviced and/or the Hearing Aid replaced. With
proper care, the battery can last for up to and beyond 1000 charge cycles.
• To extend usage life of the battery, keep the Bionic Hearing Aid in its case and charging
when not in use.
• Do not turn the volume on the Hearing Aid all the way down or off prior to recharging.
Doing so will turn the Hearing Aid off and prevent it from charging.
• The AAA batteries supplied with the charging case are not rechargeable and
can be replaced with standard AAA batteries.
To contact Hearing Assist, LLC., call 1-800-649-4434 or send your Hearing Aid to:
Hearing Assist, LLC.
P.O. Box 2259
Virginia Beach, VA 23450-2259
Please include a return address and phone number as well as a note describing in detail
the issue you are having with your hearing aid.
Prior to first use, read instructions carefully and
charge your hearing aid overnight to ensure
proper operation, care, and handling of your
rechargeable hearing aid.
Charging
LOW
1. Ensure that the volume dial on the
(OFF)
hearing aid is not in the Low/Off position
(this will keep the unit from charging).
HIGH
(ON)
2. Insert hearing aid vertically as shown,
with the charging connections facing the
night light.
3. Lay hearing aid down by gently pushing
the aid towards the charging case cover.
4. Insert batteries or plug in the AC Adaptor.
5. Ensure that the night light is on and
the hearing aid is placed into the proper
position, lying in the case. Consult the
indicator light status below to confirm
that the hearing aid is charging correctly.
Close the charging case cover to protect
the Hearing Aid from dust or damage.
Charge Status
No Indicator lamps are lit
Only Power Indicator Power Indicator is red
is green
Power
Power
Charging
Charging Power Charging
Indicator
Indicator
Indicator Indicator Indicator
Indicator
Either the charge is Input power is low. The The AAA batteries are dead
complete or the contact AAA batteries need to
or the case is not plugged in.
with the Hearing Aid is be replaced or the AC
Use the AC Adaptor or
improper and the unit Adaptor must be connected
insert two new AAA
is not recharging. to the charging case.
batteries.
Battery Information/Replacement
CARE
INSTRUCTIONS
Cleaning Instructions
Remove all debris from ear cap.
Ensure the ear cap hole is free
Before &
of any debris.
After each
use
Use the cleaning brush to
Ear Cap Nipple
clean any earwax adhered on
the hearing aid, especially in
and around the Hearing Aid
and Ear Cap Nipple.
Ear Cap Replacement
The Ear Cap is disposable.
If the Ear Cap can no longer be properly cleaned, or if it has any tears
or damage, then it is time to replace the ear cap.
Remove the old Ear Cap.
Turn up the rim of the new Ear Cap.
Insert new Ear Cap on Hearing Aid. Turn the rim of the new Ear Cap down.
Storage Notes
• Do not expose your hearing aid to extreme temperatures, humidity,
direct sunlight, dust, liquids, or corroding gases.
Lee Majors Rechargeable Bionic Hearing Aid
Distributed by:
Hearing Assist, LLC.
P.O. Box 2259
DESIGNED IN JAPAN
Virginia Beach, VA 23450-2259
ENGINEERED IN TAIWAN
www.hearingaidtv.com
MADE IN CHINA
1.4.1-2009.06
