Specification
SPY-BULLETW
Model
Pick up Element
1/3" SONY Super HAD CCD
Effective Picture Elements
NTSC:976(H)×494(V),PAL:976(H)x582(V)
(H×V)
700 TV Line
Horizontal Resolution
0.001 Lux/F1.2
Minimum Illumination
More than 52dB
S/N Ratio
2:1 interface
Scanning System
Internal, Negative sync.
Synchronous System
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Auto Electronic Shutter
0.45
Gama Characteristic
40 Meters (with ￠5X42PCS Infrared LED)
IR Distance
1Vpp, 75Ω
Video Output
Auto
Auto Gain Control
DC12V(+/-10%)/500mA
Power/Current
2.8-12mm Manual Zoom Lens
Lens
200(W)x171(H)x83(D)
Dimension (mm)
1400
Weight (g)
-30~+60℃ RH95% MAX
Storage Temperature
-10~+50℃ RH95% MAX
Operating Temperature
Packing List
No
Name
1.
Weatherproof IR Color Camera
SPY-BULLETW
2.
SPY-BULLETW
User Guide
II
Model
Number
1
1
SPY-BULLETW
Weatherproof IR Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Advertisement
Summary of Contents for Spyclops SPY-BULLETW
- Page 1 Specification SPY-BULLETW Model SPY-BULLETW Pick up Element 1/3" SONY Super HAD CCD Effective Picture Elements NTSC:976(H)×494(V),PAL:976(H)x582(V) (H×V) 700 TV Line Horizontal Resolution 0.001 Lux/F1.2 Minimum Illumination More than 52dB S/N Ratio Weatherproof IR Color Camera 2:1 interface Scanning System Internal, Negative sync.
- Page 2 INTRODUCTION CONNECTING Congratulations on your purchase of this product. * Sensor (CCD) This User Guide suits SPY-BULLETW product. We adopt Adopt SONY 1/3" CCD Sensor. the latest SONY technical of sensor and driver. The most * Auto Gain Control (AGC)
