Summary of Contents for RMTaquatics PAL
- Page 1 OWNERS MANUAL VOL 6 - ISSUE 1 A division of RehaMed International, LLC. 522 W. Mowry Drive • Homestead, FL 33030 Tel: 305-247-8300 Toll Free: 800-577-4424 http://www.grouprmt.com...
-
Page 2: Table Of Contents
Product Components – PAL Base Assembly ......– Standard to All Products ...... -
Page 3: Introduction
INTRODUCTION The purpose of this document is to provide information relating to the operation, care, and maintenance of the PAL-Portable Aquatic Lift. Our goal is to provide our customers with the most advanced and innovative designs that offer exceptional quality at affordable prices. We design and... -
Page 4: Product Overview
The PAL is completely portable, is battery powered, and is operated by a screw driven actuator. This design insures consistent operation and elimination of service problems that occur with water powered pool lifts. -
Page 5: Pal Base Assembly
Component Description The Base Assembly is made up of several components as described below: Casters. These are the wheels on which the PAL moves. The front wheels are rigid and the back wheels are swivel and locking casters to facilitate movement of unit. -
Page 6: Standard To All Products
Component Description- continued Counter Weights: The weights for your PAL lift are located in the bottom of the pallet. Remove the restraining planks with a screwdriver to gain access to the weights. The weight block is approximately 30 pounds. Use caution when lifting and be careful not to drop the weights on your fingers. - Page 7 Please call our Customer Service Department at 800-577-4424 if we can be of further assistance. Battery. The removable battery is located on top of the control box. The battery should be charged daily. Do not allow battery to fully discharge, as this would shorten the life of the battery. Battery Cover.
-
Page 8: Assembly Instructions
Contact RMT Aquatics or your dealer immediately to notify of missing or damaged parts. The PAL is shipped on a covered pallet. This pallet is VERY HEAVY. You will need to gather the following tools to begin the unpacking and assembly of your unit: •... -
Page 9: Unpacking
Unpacking Procedure for the PAL 1. Cut open the enclosure bag at the base of the unit and gently remove plastic from unit. 2. Cut internal bands and remove chair assembly and housing. 3. Remove the accessory box and counterweight plate from the plate enclosure. -
Page 10: Positioning
POSITIONING Four things to REMEMBER when positioning PAL for use. • The PAL is Heavy. It is easy to roll, but DO NOT roll too fast or it may be hard to stop. • Position the PAL in an area that allows plenty of room for transferring to and from a wheelchair. -
Page 11: Transferring
TRANSFERRING Once the unit is positioned for use, use the following procedure to transfer to the seat and into the water for desired aquatic activity: • Rotate the seat to either side of the lift that is the most comfortable position for transfer. -
Page 12: Battery Charging
BATTERY CHARGING The rechargeable battery should be connected to the charging unit when the lift is not in use. A fully charged battery will provide approximately 30 lifting cycles, depending on the weight of the users. The battery has no memory, so it is not necessary to fully discharge the battery prior to charging. -
Page 13: Standard/Optional Accessories
STANDARD ACCESSORIES/ OPTIONAL ACCESSORIES The following items are included with all Pool lift models: Console Cover: Protects battery and control unit from exposure to water. Seat Belt Assembly: Nylon, water resistant belt for added security. Battery/Charger: 24 volt rechargeable battery. Additional Accessories may be purchased for your Unit Stability Vest: Five point restraint for individuals who need higher degree of stability than provided with standard seat belt. -
Page 14: Maintenance
MAINTENANCE Minimal maintenance will prolong the life of your lift. All electronic components should be kept clean and dry. The control box and battery should be protected from exposure to water. A small waterproof cover is provided with each lift to cover the control box when in use. -
Page 15: Trouble Shooting
TROUBLE SHOOTING Be sure the battery is fully charged before troubleshooting. Unit does not rotate Does unit raise or lower? Yes. 1. Check connection to Control Box. Be sure plug is pushed in all the way. 2. Check hand control connection to Control Unit for damaged pins. 3. -
Page 16: Warranty
WARRANTY INFORMATION All RMT Aquatic Lifting Systems have a Lifetime Warranty on the frame, excluding the powder coated paint finish, which may become scratched with normal use. All electronic and motor components, with the exception of batteries, have a full two-year warranty. Within the warranty period, we will repair or replace any part found to be defective upon our examination, but will not pay shipping costs or other expenses. -
Page 17: Warranty
Batteries Batteries have a normal lifespan of between 2-3 years, depending on their use and care. Batteries should be left on the charger when not in use and should never be allowed to fully discharge. Allowing the battery to fully discharge can damage the battery. -
Page 18: Dimensions/Capacity
SPECIFICATIONS PAL/PAL-Hi-Lo 1. Dimensions/Capacity Overall Height 66 inches Base Dimensions Height. 22.5”, length. 37.5”, width 27.5” (inches) Overall Length with Footrest 106” (fully extended) Overall Length without Footrest 91” (fully extended) Overall Length in Stored position 61” (fully raised) Total Weight... -
Page 19: Range Of Motion
5. Range of Motion: Lifting: Variable to configure to each pool. 44”- 58” total travel from highest to lowest point w/ standard actuator. Seat Depth: 18-20” below water line. Rotation: 240º 6. Materials and Finish Frame: Powder Coated Stainless Steel Handle: Powder Coated Aluminum Housing:... -
Page 20: Parts List
Mast Assembly 150-1200 Actuator Arm 150-1300 Support Arm 150-1400 Seat Arm 160-1000 Seat Assembly 160-1300 Foot Rest 200-1000 PAL Main Frame 200-2000 Rigid Caster 200-3000 Swivel Caster 110-3100 Counter Weight Plates 200-5000 Housing Assembly 200-4100 Stabilizer Tube 150-2100 Hi/Lo Mast Assembly...
