Summary of Contents for HITEC S60
-
Page 2: Table Of Contents
Contents Precautions ...............7 Preface................8 Warranty ................9 Main Functions and Features ........10 List of Accessories ............13 Component Guideline ............15 Front View ..................15 Rear View ..................16 Description of Indicators ..............17 LCD Segment Display ..............18 Preparations Before Use..........19 Charging ..................19 Installing the Battery .............. - Page 3 Video Modes ..............27 • Display Time .....................36 Settings ................37 Basic Operations of Video Recording ..........27 • Warning Tone ....................37 Parameter Setting For Video Recording ........28 • Status Indicator ..................37 • Execution Mode ..................29 • On Screen Display ..................38 •...
-
Page 4: Precautions
Precautions Guide for Components ..............58 Startup ................... 60 When using the S60 video camera, adhere to the following Pairing ................... 60 precautions: Specifications ................62 1. Do not drop, knock, or shake the video camera. Precautions..................62 2. Do not place the video camera near an object that generates Accessory Application ...........64... -
Page 5: Preface
● Displays images in real time. experience. ● Performs video recording. ● Takes pictures. This manual describes how to install and use the S60 video camera. ● Displays time. It also provides information about the use, operation, installation ● Performs 4X digital zooming. -
Page 6: Main Functions And Features
Main Functions and Features ● Has a compact and stylish design. ● Provides better video effects in multiple video output modes (NTSC ● Provides 140° wide-angle f/2.7 lens. system): ● Provides a special-purpose HD lens, which supports 1080P, 960P, 1080P(1920x1080) 60 frames / second and 720P HD video recording. -
Page 7: List Of Accessories
List of Accessories ● Supports connection to an external microphone (special-purpose microphone only). ● Provides a 1/4-inch general-purpose interface for accessory use. S60 Camera TFT Display Remote Control ● Accessories create a strengthened structure with improved reliability and stability. ● A rechargeable, built-in, high capacity lithium-ion battery extends video recording time. -
Page 8: Component Guideline
Component Guideline Flat Adhesive Mount Curved Adhesive Mount Vertical-horizontal Joint Front View Extended Adjusting Moisture-proof Foam USB Data Cable Bolt Unit Waterproof Plug User Manual Hand Strap 1. Wi-Fi key 8. Power on/off key Cloth Bag CD-ROM 2. Wi-Fi status indicator 9. -
Page 9: Rear View
Rear View Description of Indicators Red indicator Green indicator Blue indicator Position Front cover(1) Front cover(1) top cover(1) top cover(1) Front cover(1) TFT display(1) TFT display(1) Status bottom side(2) Flash once and Startup then Stay on Video Flash slowly recording Audio Flash slowly recording... -
Page 10: Lcd Segment Display
To check battery power, turn the unit on. If the battery level is low, 100-088 100-0088 charge it. 2H30 1888 Use the supplied power adapter or a USB port to charge the S60: Icon Functions Video mode Photo mode 1080P-50... -
Page 11: Installing The Battery
Install TFT Display 1. Before Installing the battery, ensure that the battery "lock key" at The S60 supports an external, dedicated 2″ TFT display which the bottom of the S60 is unlocked. performs CX setup, playback, file deletion, etc. on the camera to preview or play the video back. -
Page 12: Insert And Remove The Memory Card
Insert and Remove The Memory Card Startup The S60 supports an external TF card up to 64G. Though all SD Turn the power key to "ON" to turn on the S60: cards above Class 10 can be used on the S60, a high-speed card is recommended for high-definition shooting. -
Page 13: Language
Language standby mode. Use "<" / ">" to select the item to the left / right, and use "+" / "-" 1. Press the "M" button to enter the camera setting menu. to select the item above/below the selected item. After selection, 2. -
Page 14: Start Video Recording Via G-Sensor Mode
• The system will tick once to indicate the start of video recording. The TFT display shown below is for video recording: Turn the G-Sensor key to "ON" so that the S60 will actively sense the change of gravity. The system will automatically start video recording... -
Page 15: Parameter Setting For Video Recording
Parameter Setting For Video Recording • Execution Mode Select the execution mode you want. Press "OK" to confirm. Press Perform the following steps to set the parameters for video recording: "M" again to exit the setting menu. 1. Press the "M" button to enter the setting menu. : Video recording : Video-only 2. -
Page 16: Piv(Photo In Video)
• PIV(Photo in video) • View Angle In this mode, you can shoot photos in the video recording process. Optional view angle: Broad, Medium, Narrow, Small. (The function is unavailable in 720P 100f/120f modes.) (The function is unavailable in 960P and 720P modes.) Manual photo shooting ( ): Press "Shutter"... -
Page 17: Video Content Loop
• The system will tick once to indicate audio recording. When this function is activated, an upright video file can be Working mode obtained when using the S60 to shoot video upside down. Recording time (Audio recording) (The function is unavailable in 720P 100f/120f modes.) •... -
Page 18: Photo Modes
2. Press "+" / "-" to select " "; 1. Turn on the S60 to enter recording standby mode. 3. Press "<" / ">" to move the blue cursor to the sub-menu you want 2. Aim at the subject and preview it on the display. -
Page 19: Single Shot Mode
Language When the "Shutter" button is pressed once under the recording Date/time Format standby mode, the S60 will start a countdown and take photos when the set time has elapsed. Recover factory setting The available options are 3s, 5s, 10s. -
Page 20: On Screen Display
• Auto To Standby 1. Press the "playback" button to enter the playback interface. The S60 is set to automatically enter standby mode if no operation 2. Press the "Video recording" button to select file type and press (photo shooting, video recording or button operation) is carried "OK"... -
Page 21: Delete Files
• When reviewing photos, there are various functions available to • When playing audio files, there are various functions available to you. These and their corresponding button are listed below: you. These and their corresponding button are listed below: Button Functions Button Functions... -
Page 22: Upload Audio/Video/Photo Files To Pc
Protected files cannot be deleted. However, these files can be camera has not been configured. deleted by formatting. Use an HDMI cable to connect the S60 to the TV set: Upload Audio/Video/Photo Files to PC 1. Use a USB data cable to connect the camera to a PC. -
Page 23: Wi-Fi
• Wi-Fi Starting and Connection 1. Push the Wi-Fi key to "ON" to switch on the Wi-Fi function: With an integrated Wi-Fi module, the S60 can connect to a Wi-Fi remote control, smartphone, or tablet PC to achieve remote control Wi-Fi key function. - Page 24 Display the remaining number of shots in photo shooting mode. The mobile device must be used within a distance of max. 100 meters from the S60 in an obstacle-free and horizontal angle. The real-time preview is unavailable for video recording 720P 100f/120f modes.
-
Page 25: Operating Instructions For Wi-Fi Control Interface
Operating Instructions for Wi-Fi Control Interface 2. Single shot Click the Single shot mode icon " ," it will turn blue " ". The 1. Video Recording current state icon will dispaly as " ", click it to take one picture. Click the Video recording mode icon "... - Page 26 3. Fast Shot 4. Playback Click the icon " " to enter the interface shown in Fig. 6 and view Click the Fast shot mode icon " ", it will turn blue " ". The current videos and photos remotely. state icon will dispaly as "...
-
Page 27: Download Files To Mobile Device
Download Files to Mobile Device Click on the thumbnail to view it in large preview. You could slide it left or right to select the desired file. Return to the thumbnail preview interface and click the icon " " to enter the Download interface. -
Page 28: Trim Videos
Trim Videos Click on the thumbnail to view it in large preview. You could slide left and right to select the desired file. When viewing the downloaded files on the mobile device, you can click the icon " " at the bottom of the screen to enter the video trimming interface shown in the figure below: Save and share the edited video file... -
Page 29: Change Wi-Fi Connection Name And Password
Method 1: Change the starting frame and ending frame by directly PASSWD=AEE12345". Change the content following the equal dragging the time frame panel to the desired frame. (Click the Play sign "=" to your desired password (containing at least 8 digits and key for previewing until the best location is selected). -
Page 30: Wi-Fi Based Remote
Wi-Fi Based Remote Under the video recording mode, press once to switch the current mode to the photography mode. Under photography mode, press once to take a photo. Guide for Components Long-press for about 2s to enter the mode selection state. Select your desired mode and press to enter. -
Page 31: Startup
Startup Long-hold the "Power / Record" button for 5s to start the Wi- Fi based remote control. WAIT HOST PBC After startup, the screen will display the battery icon " ." If the 4. Press the "Stop" button on the camera once and the Wi-Fi remote battery icon is empty, it indicates that the battery level is low and control screen will display the icon below: charging is needed;... -
Page 32: Specifications
Specifications or to objects that send out strong radio waves such as antenna. Strong magnetic fields may result in failure of the remote control. Description Specification 3. Do not put the remote control in a place subject to high temperature or direct sunshine. Charging time via USB 2.0 hours (max.) 4. -
Page 33: Accessory Application
Accessory Application Follow these steps to assemble the waterproof housing rear case: The S60 is suitable for handhold use or hand-free use in most locations with the help of appropriate accessories. When the S60 is fitted with water-proof housing, it can be used to record videos underwater. -
Page 34: Mount Plug Bracket Components
Mount Plug Bracket Components The plug bracket affixes the S60’s water-proof housing firmly onto the sticky seat: The plug bracket affixes the S60 firmly to the sticky seat. -
Page 35: Use Curved Adhesive And Flat Adhesive
Use Curved Adhesive and Flat Adhesive Specifications The S60 comes with curved adhesive and flat adhesive for installation Description Specifications on different surfaces. You can easily attach the camera onto a helmet, vehicle, or the Visual angle 140° surface of other devices. -
Page 36: Power Supply
Power Supply Maximum audio recording time About 3.5 hours (Max.) TFT Display 2.0" true color TFT display (16:9) The S60 video camera uses a power unit certified by the following LED Dot-matrix screen 90×64mm FSTN (lattice screen) authorities. Operating system: Windows XP SP2 / Vista Operating platform requirements or above / Mac OS;... -
Page 37: Precautions For The Waterproof Housing
(50°C) or low (-10°C) to avoid deformation. other professional device. 4. Do not expose the S60 video camera to sunshine to avoid 6. If you enable the cyclic recording function over a long period or deterioration of its waterproof performance. -
Page 38: Fcc Notices
8. When the camera is in use over a long time, the temperature of the equipment generates uses and can radiate radio frequency energy metal parts near the lens may rise. This is a normal phenomenon, and, if not installed and used in accordance with the instructions, but please do not touch the heated metal parts.
