chinavasion CVJI-E65 DMP10 User Manual

Full-hd hdmi media player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Full-HD HDMI Media Player
USER'S MANUAL
Please read this User's Manual carefully before using this product
and keep this manual for future reference.
DMP10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVJI-E65 DMP10 and is the answer not in the manual?

Questions and answers

Related Manuals for chinavasion CVJI-E65 DMP10

Summary of Contents for chinavasion CVJI-E65 DMP10

  • Page 1 Full-HD HDMI Media Player USER’S MANUAL Please read this User’s Manual carefully before using this product and keep this manual for future reference. DMP10...

  • Page 2: Table Of Contents

    Table of Content Getting Started.....................1 The Remote Controller..................1 Menu Introduce ....................4 Start-up Screen ..................... 4 DVD player Menu....................4 Media Center Menu....................4 File Copy Menu ..................... 4 File Browser Menu ....................4 Setup Menu......................5 DVD Player Menu ....................6 Open/Close ......................

  • Page 3: Getting Started

    Chapter 1 Getting Started The Remote Controller All procedures in this manual can be carried out using the remote controller buttons. Certain functions can also be carried out using the front panel. See the following for details on each button and its function: Button Function POWER button:...
  • Page 4 Navigational buttons: Press the arrow buttons to navigate the menus. During video playback, press these keys to adjust the position and size of external subtitle. ， On the photo zoom status press these keys to select different position to show. INFO button: During video playback, press to show the file’s detail...
  • Page 5 Press to pause current playback Press again to step to the next frame. Press to resume playback. SLOW button: Press to play back in slow motion. Three motion settings are available Five slow motion levels (3/4, 1/2, 1/4, 1/8, 1/16x) are available.

  • Page 6: Menu Introduce

    Chapter 2 Menu Introduce Start-up Screen Power on the player, you can see the start up page. DVD player Menu After a few second, the system will enter a DVD player menu. To enter this menu, press on the remote controller too. The DVD player Menu is the default page, on the menu, all DVD like operation can be done.

  • Page 7: Setup Menu

    Setup Menu The Setup Menu allows you to configure audio, video, network, photo and system settings. To enter the menu, select Setup from the Media Center menu or on the remote controller.

  • Page 8: Dvd Player Menu

    Chapter 3 DVD Player Menu ， This player has two playback modes: Dvd Player mode and Media center mode. DVD player mode: All kinds of the DVD functions can be done on this mode. Media center mode: In this mode the player can be named as HDD media player, which can browser the file on HDD, USB, network, UPNP etc.

  • Page 9: Media Center Menu

    Media Center Menu Media center Menu allows you to enter the file browser menu, file copy menu and setup menu. Press the on the remote controller to enter this menu, MOVIE Press this button to enter the file browser menu, which located at music tab. MUSIC Press this button to enter the file browser menu, which located at music tab.

  • Page 10: Setup Menu

    Chapter 5 Setup Menu The Setup Menu allows you to configure audio, video, network, photo and system settings. Select Setup from the Media Center menu or on the remote controller to enter the menu, Changing Audio Settings Press on the remote controller to select the Audio tab from the menu bar. Select to toggle Night Mode on and off.

  • Page 11: Changing Video Settings

    quality. LPCM is the default setting, and provides 2 channels audio output. Changing Video Settings Press on the remote controller to select the Video tab from the menu bar. Select to set aspect ratio Aspect Ratio Press to select from Pan Scan 4:3, Letter Box 4:3, or 16:9.
  • Page 12 Brightness Select to set brightness levels Press to adjust brightness. The new setting is previewed onscreen. Press to confirm. Contrast Select to set contrast levels ress to adjust contrast. The new setting is previewed onscreen. Press to confirm Select to adjust DNR. Press to set.

  • Page 13: Changing Network Settings

    1080P 24HZ Select to open 1080P 24HZ On: If the Content is 24fps mode, player will change to 1080P/24Hz mode automatically before playback start. Off: Do nothing. Changing Network Settings Press on the remote controller to select the Network tab from the menu Wired Lan Setup Select to set the Network Setting.
  • Page 14 DHCP DNS(AUTO) Set the DNS server IP address by auto Press to confirm. FIX IP (MANUAL) Using Fixed IP, it is required to enter followings. IP address, Subnet Mask, Default Gateway. For further assistant to above settings, please contact to the network administrator.
  • Page 15 Before configuring the WLAN settings, please check the following Wireless Setup Make sure the WLAN USB Adapter is connected to the USB HOST port Make sure there is a wireless router or an AP (Access Point) on the network, or your PC is equipped with a wireless network adapter/card; Make sure your player is in the effective range of the WLAN Select a Profile Name Press...
  • Page 16 Infrastructure (AP) Infrastructure mode is used to connect computers with wireless network adapters, also known as wireless clients, which connect to an existing wired network with the help of wireless router or access point Get SSID Name System will search for an existing SSID (Service Set Identifier) auto. And select the access point you wish to access from the SSID list.
  • Page 17 Peer to Peer (Ad Hoc) Peer to Peer mode, which is also called Ad Hoc mode or computer-to-computer mode, is used to connect wireless clients directly together, without the need for a wireless router or access point. Ad Hoc Setup Set the Wireless SSID, Wireless Security, and Host IP for the Ad Hoc connection.

  • Page 18: Changing System Settings

    Changing System Settings Press on the remote controller to select the System tab from the menu. Select to choose the OSD (On Screen Display) language. Menu Language Press to select the language. Press to confirm. Select to choose the text encoding language. Text Encoding Press to select the text encoding language.

  • Page 19: Misc

    Select to set the system time. Time Press to select from Manual and Auto(via TV). Press to confirm. Select to toggle the Auto Play function on or off. BD/DVD Auto-Play Auto Play begins playing a DVD immediately when you insert it into the DVD drive.
  • Page 20 Resume playback Resume playback Press to select. Press to confirm. Slide Show Time Select to set slide show time. Press to select the interval that you require. Press to confirm. Transition Effect Select to set the transition effect of photos. Press to select the transition of photo you require Press to confirm.

  • Page 21: Background Music

    Select to play the music file under the same folder. Background Music Press to select the position of the background music. Select “off” to close the function. Press to confirm. Select to play the music file under the same folder. Screen Saver Press to select.

  • Page 22: File Browser Menu

    Chapter 6 File Browser Menu The Browser menu allows you browse and play music, photo and movie files stored on a HDD or an external USB device and Card reader, Network, UPNP,DVD disc, etc. To enter the menu, select Browser from the Guide menu.

  • Page 23: Browsing Photos

    Press to select the folder containing your audio files. A thumbnail strip appears at the bottom of the screen, shows song information. Press to select the file that you want, to play and press ： ： ： ： Note While listening to audio files, you can browse the photos at the same time Browsing Photos Use the left and right navigation arrows to select the Photos tab.

  • Page 24: Browsing Network

    Press to select the folders. Press to select the movie you want to view and press . The movie will be played in full screen mode. ， 1) During playback press to zoom video ,there is six zoom modes; ， 2) During playback press to do seek operation;...

  • Page 25: Browsing Through 'My_Shortcuts

    Note: 1. While browsing high definition video files (resolution up to 720p / 1080i / 1080p) via Ethernet or WLAN, the video might be buffering. It is normal due to the limit of network speed or signal strength. 2. Due to different network conditions, sometimes the workgroup might not be accessed or shown in the list. And then you need to use ‘My Shortcuts’...

  • Page 26: File Edit Menu

    Select OK and press the button to confirm all changes. Select Net Password and the entry screen will appear. See above. Select Specific File Server IP, and use Navigational and Numeric buttons to enter IP address. You can also select Detail to set the Label, Domain, and Host Name of the shortcut.
  • Page 27 Return Select to return to the main screen Rename To rename a file, do the following: 1. Press on the remote controller to select the Rename tab from the menu bar. 2. Press on the remote controller. The name entry screen will appear. 3.

  • Page 28: File Copy Menu

    Chapter 7 File Copy Menu The file copy menu allows you to copy file at NET, USB, and HDD. To enter the menu, select File Copy from the Media Center menu. Step 1. Select Source Device When you enter the File copy interface, press to select the device which your want to copy first.

  • Page 29: Step 4. Select The Folders Of Destination

    Step 4. Select the folders of Destination At Destination coloum, press to select the folders of destination. Then press to next step, and press to return. Step 5. Copy Status At Popup menu, select Copy to copy, select Move to move, select CANCEL to cancel. Press OK into copy status.

  • Page 30: System Upgrade

    Chapter 8 System Upgrade How to get the new firmware To get the latest firmware, pls. visit our website: Normal upgrade mode 1) Get the downloaded upgrade file named install.img. 2) Copy the install.img to the USB root directory. Insert the USB disk, then power on the player. 3) After boot up, press to enter the setup page.
  • Page 31 1) Get the downloaded upgrade file named install.img. 2) Copy the install.img to the USB root directory. Insert the USB disk, then power on the player; 3) Press the two front panel key at the same time, NEXT and PREV; 4) Power on the box (release the key in 5 minutes);...
