Summary of Contents for Contronics LP-10
- Page 1 R.O. SYSTEMS LP-10/10BP/20BP/30BP/60BP/100BP USER MANUAL 25-06-2015 version 2.5...
- Page 2 LP-10/10BP/20BP/30BP/60BP/100BP Contronics Engineering B.V., Ambachtsweg 8, 5492 NJ Sint-Oedenrode, The Netherlands, hereby declares that products LP-10BP, LP-20BP, LP-30BP, LP-60BP and LP-100BP, produced and delivered by Contronics Engineering B.V., are in accordance with the following CE directives: EMC-Directive : 2004/108/EG Directive for low-voltage...
-
Page 3: Table Of Contents
LP-10/10BP/20BP/30BP/60BP/100BP Table of contents 1. INTRODUCTION ................... 4 2. KNOW YOUR REVERSE OSMOSIS (R.O.) SYSTEM ......5 3. AVAILABLE SYSTEMS ................. 7 4. CONTENT OF THE DELIVERY ............. 8 5. INSTALLATION PROCEDURE .............. 9 6. WATER DETECTION CIRCUIT (LP-30BP/60BP/100BP) ....10 7. -
Page 4: Introduction
LP-10/10BP/20BP/30BP/60BP/100BP 1. INTRODUCTION The use of demineralised water is recommended with Contronics humidifiers for the following reasons: Any minerals, salts and bacteria that enter the humidifier will cause the water reservoir to become polluted. The integrated flushing programme will delay this process but will not prevent it entirely. -
Page 5: Know Your Reverse Osmosis (R.o.) System
Shut-off valve Restrictor in the coupling Reverse osmosis membrane Demineralised water Drainage hose Carbon pre-filter Sediment pre-filter 3/8” water supply connection Figure 1. LP-10 Demineralised water Pressure switch Non-return valve Fuse Shut-off valve Reverse osmosis membrane Booster pump 3/8” water supply connection... - Page 6 LP-10/10BP/20BP/30BP/60BP/100BP Non-return valve Reverse osmosis membrane Demineralised water Booster pump Pressure switch Shut-off valve 3/8” water supply connection Carbon pre-filter Fuse Sediment pre-filter Figure 2. LP-10BP Figure 3. LP-20BP Booster pump Restrictor Alarm LED Reverse osmosis Low water-pressure LED membrane (x 2) Reset button 3/4”...
-
Page 7: Available Systems
LP-10/10BP/20BP/30BP/60BP/100BP Booster pump Restrictor Alarm LED Reverse osmosis Low water-pressure LED membrane (x 4) Reset button 3/4” water supply connection Carbon pre-filter Demineralised water Sediment pre-filter (x 2) Water detection sensor Figure 5. LP-60BP – LP-100BP Drainage hose 3. AVAILABLE SYSTEMS... -
Page 8: Content Of The Delivery
LP-10/10BP/20BP/30BP/60BP/100BP LP-20BP Reverse osmosis filter with booster pump and a maximum capacity of 750 kg/day (31.2 kg/hr) at a minimum water pressure of 1 bar (15 PSI) and a water temperature of 25 °C. Under normal operating conditions (10 °C), 480 kg/day, suitable... -
Page 9: Installation Procedure
T-piece Buffer tank to drain to HU Figure 6 LP-10 with pressure tank and connections 5. INSTALLATION PROCEDURE Place the device in a suitable location. Place the pre-filter (for LP-30BP/60BP/100BP 2 x) in the left-hand holder. Place the carbon filter in the right-hand holder (remove the cellophane). -
Page 10: Water Detection Circuit (Lp-30Bp/60Bp/100Bp)
LP-10/10BP/20BP/30BP/60BP/100BP Check that the supply pressure is at least 2 bar. Where the inlet pressure < 2 bar it is recommended to install a device incorporating a booster pump (BP). For maximum performance, the inlet pressure must be a minimum of 4 bar for the LP-10. -
Page 11: Temperature Protection (Lp-30Bp/60Bp/100Bp)
LP-10/10BP/20BP/30BP/60BP/100BP 7. TEMPERATURE PROTECTION (LP-30BP/60BP/100BP) The LP-30BP/60BP/100BP are fitted with a temperature cut-out device that will temporarily interrupt the power supply if the pump motor becomes overheated. 8. LOW-PRESSURE PROTECTION (LP-30BP/60BP/100BP) The LP-30BP/60BP/100BP are fitted with a low-pressure protection device to protect the pump. -
Page 12: Checking The Demineralised Water
LP-10/10BP/20BP/30BP/60BP/100BP Before re-installing the filters, the O-ring must be checked for damage and correct seating. The holders can be cleaned with soap and water or with chlorine, if necessary. Rinse thoroughly afterwards. After re-installing, screw the holders back into place (hand-tight!). -
Page 13: Storing The System
LP-10/10BP/20BP/30BP/60BP/100BP 13. STORING THE SYSTEM Always store the system in a frost-free area, but with a temperature that is as low as possible. If the storage period is to exceed 3 months, remove the membrane and store it fully immersed in disinfected water in order to prevent desiccation and/or bacterial... -
Page 14: Malfunctions
LP-10/10BP/20BP/30BP/60BP/100BP 14. MALFUNCTIONS... -
Page 15: Specifications
LP-10/10BP/20BP/30BP/60BP/100BP 15. SPECIFICATIONS LP-10 LP-10BP LP-20BP LP-30BP LP-60BP LP-100BP Maximum production in 1125 2250 3600 kg/day at 25 °C water temperature Maximum production in 1440 2310 kg/day at 10 °C water temperature Retention of salts and minerals (%) Yield compared to sup-... -
Page 16: Options Lp-10Ws, Lp-10Wsg En Lp-10Wswsg
16. OPTIONS LP-10WS, LP-10WSG en LP-10WSWSG This extra user manual provides specific operating, installation and maintenance instructions for the LP-10WS, LP-10WSG and LP-10WSWSG options. LP-10WS is an LP-10 combined with a permeate pump. The pump, which is powered by water, ensures that the rinsing water is used more efficiently. -
Page 17: Installation Procedure
LP-10/10BP/20BP/30BP/60BP/100BP 17. INSTALLATION PROCEDURE Ditto LP-10. See page 9. The only difference being putting the plug for the LP-10WSG and the10WSWSG in the socket. 18. STARTPROCEDURE See page 11. The green or green/yellow LED lights up when LP-10WSG and LP-10WSWSG has been installed. After a few minutes, and with a good supply of water, the green LED is the only one lit up. -
Page 18: Specifications
LP-10/10BP/20BP/30BP/60BP/100BP 21. SPECIFICATIONS LP-10WS LP-10WSG LP-10WSWSG Electricity consumption (W) Mains voltage (V) Maximum switching capacity (W) Yield in respect to added water (%) 1 : 2 1 : 3 1 : 2 Water yield per hour (L) (3.5 bar) Dimensions LxBxH (cm) - Page 19 City water pressure (bar) DISCLAIMER Contronics works continuously on the further development of its R.O. systems. We therefore reserve the right to modify the design, construction and technology of the product at any time. For this reason, no claims can be made based on the data, illustrations and description in this user manual.
- Page 20 LP-10/10BP/20BP/30BP/60BP/100BP P.O. Box 144 5490 AC Sint-Oedenrode The Netherlands Telephone: +31(0)413-487000 Telefax: +31(0)413-473903 Website: www.contronics.nl E-mail: info@contronics.nl...
