IES EC 12 Operator's Manual

Operator Manual
EC 12 & EC 24
dimmer pack
EC 24I 12x 2,3KW DIGITAL DIMMER UNIT
DMX 512
MAX
MIN
DEL H T U
IES EC24 & EC12 dimmer pack Operators' Manual v. 1.0
Contents:
1 Introduction ......................................................2
1.1 Product range ..........................................2
1.2 Main features of EC dimmer ....................2
2 Unpacking and installation ...............................2
2.1 Unpacking & checking .............................2
2.2 Positioning ...............................................2
2.3 Connections.............................................2
2.4 Safety ......................................................2
3 Control panel layout .........................................3
4 Function DEL H MENU ...................................4
4.1 Adjusting minimum output .......................4
4.2 Adjusting maximum output ......................4
4.3 Select Solid state function .......................4
4.4 Adjusting delay times...............................4
5 Function DEL T MENU....................................5
5.1 Select Dimmer curve ...............................5
5.2 DMX 512 Back up facility.........................5
6 Function DEL U MENU ...................................5
6.1 Serial communication ..............................5
7. Return to factory settings ................................6
8. Dimmer overview ............................................7
9. Specifications ..................................................8
10. Declaration of conformity...............................9
1
20-10-2003
