READ BEFORE USE!
WARNING
USE LIQUEFIED PETROLEUM GAS ONLY!
-Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier form a neighbor's
phone.Follow the gas supplier's instructions.
• If you cannot reach yous gas supplier,call the fire
department.
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
WARNING:
If the information in this manual is not followed exactly
,a fire or explosion may result causing property
damage,personal injury or loss of life.
Qindao Hichanse Group Co.,Ltd
Eastern Wenhua Road, Jimo Economic Developing
Zone, Shandong Province ,China
1.888.880.4884
ASSEMBLY INSTRUCTIONS
ITEM Number: ALZ651-1
Product Name: Coronado LP Fire Pit Table
For Outdoor Use Only!
Use Liquefied Petroleum Gas (LP-Gas) Only !
Propane cylinders sold separately
DANGER
If you smell gas:
1.Shut off gas to the appliance.
2.Extinguish any open flame.
3.If odor continues,keep away from the appliance and immediately
call your gas supplier or fire department
WARNING
Improper installation, adjustment,alteration,service or
maintenance can cause injury or property damage. Read the
installation,operating and maintenance instructions thoroughly
before installing or servicing this equipment.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Turn off gas supply when the fire pit is not in use.
Battery may contain mercury. Do not deposit in fire or put in trash.
Recycle manage as hazardous waste.
If the fire pit is stored indoors, leave LP-Gas cylinder outdoors.
DANGER
1
WARNING
WARNING
WARNING
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor
Using it in an enclosed space can
kill you.
Never use this appliance in an
enclosed space such as a camper,
tent, car or home.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDQ-09 and is the answer not in the manual?

Questions and answers

Summary of Contents for Coronado HDQ-09

  • Page 1 ASSEMBLY INSTRUCTIONS Intertek 3 1 9 5 4 0 2 READ BEFORE USE! ITEM Number: ALZ651-1 Product Name: Coronado LP Fire Pit Table WARNING For Outdoor Use Only! Use Liquefied Petroleum Gas (LP-Gas) Only ! Propane cylinders sold separately DANGER If you smell gas: 1.Shut off gas to the appliance.
  • Page 2 SPECIFICATIONS Product Name Outdoor Gas Fireplace Model No. HDQ-09 Rated Heat Output 27000 btu/hr Type of Gas Propane Gas Supply...
  • Page 3 *LP Tank used must include a collar to protect the cylinder valve *Never fill the cylinder beyond 80% full *Liquefied petroleum gas is not natural gas. Only use propane for this fire pit. *The conversion or attempted use of natural gas in a liquefied petroleum gas unit or liquefied petroleum gas in a natural gas unit is dangerous.
  • Page 4 Parts/hardware List Part No. Part Description HDQ-09-01 Body HDQ-09-02 Door HDQ-09-03 Burner HDQ-09-04 Fire Bowl HDQ-09-05 Heat Insulation Board HDQ-09-06 Ignition Pin HDQ-09-07 Thermocouple HDQ-09-08 Control Valve Pulse Ignition HDQ-09-09 knob HDQ-09-10 Regulator HDQ-09-11 Guard HDQ-09-12 Grounding Wire HDQ-09-13 HDQ-09-14...
  • Page 5 STEP 3. (I) Check each part before using the product. Make sure the gas supply system is turned "OFF" before assembling. (See Figure I.) (II)Put the gas tank on the metal stand. Make sure the gas tank sits on the metal stand completely. Turn the wing screw on the outer part of metal stand clockwise to secure the gas tank tightly.
  • Page 6 TO LIGHT Before each use, inspect all hose. Replace hose if there are any signs of cutting, wear or abrasion. (1) Turn the T-handle on the gas tank counter-clockwise to open the gas supply. (2) Light the firepit as below steps: A.
