Please read all instructions before installing or using this product. Retain this manual for future reference. Additional product information and descriptions may be found on the product specification sheet. Note: The SL BEAM 100 LED Luminaire is universal voltage 100 to 240 VAC (auto-ranging). 2. Included Items...
Installation & User’s Manual SL BEAM 100 LED Luminaires SL BEAM 100 LED LUMINAIRE OVERVIEW 1. SL BEAM 100 LED L u minaire Components Major Luminaire Components Top of Unit Luminaire Head High-Intensity RGBW LED Array LCD Display / Menu System...
SL BEAM 100 LED Luminaires Installation & User’s Manual LCD Display / Menu System Edit a Preset Edit a Chase Home (menu settings) DMX512 Addressing Return to Main Screen LCD Display SL BEAM 100 DOWN Arrow Button LEFT Arrow Button...
Direct connection to a AC power sour c e using an AC input cable. Connection from the AC output of another SL BEAM 100 L ED Luminaire. When using this method, it is very important not to connect any other type of equipment device.
"daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to the DMX connector on the first SL BEAM 100 LED Luminaire. Another cable runs from the other DMX connector on the first unit to a DMX connector on the next SL BEAM 100 LED Luminaire (or DMX512 device to be controlled).
(i.e.,scenery) to allow for proper airflow Simply attach hook, clamp, etc. to the SL BEAM 100 LED Luminaire mount assembly in the M13 hole. Note: Mounting hooks, clamps, etc. are sold separately or by others. For available mounting accessories refer to "Accessories"...
Installation & User’s Manual OPERATION AND PROGRAMMING 1. LCD Display and Menu System The SL BEAM 100 LED Luminaire’s LCD Display and Menu System provides local control for accessing the following fixture’s settings: Presets (Standard and User Defined) Color Filters...
Installation & User’s Manual SL BEAM 100 LED Luminaires SL BEAM 100 LED Luminaire Menu Tree Figure 8: SL BEAM 100 LED Luminaire Menu Tree Sh wline SL BEAM 100 LED Luminaire Menu Tree...
SL BEAM 100 LED Luminaires Installation & User’s Manual 3. Quick Selection Buttons When in Manual Mode, the SL BEAM 100 LED Luminaire’s features can be accessed via the on-board LCD menu system or via three quick select buttons: Edit a Preset Button...
Linear Curve DMX Value DMX Value *PL Curve follows the dimming curve of Philips Selecon PL series LED luminaries. S_Curve Square Curve DMX Value DMX Value Figure 9: SL BEAM 100 LED Luminaire Dimmer Curves Sh wline Dimming Curve Selection...
5. Master / Slave Operational Mode The Master / Slave Operational Mode allows one SL BEAM 100 LED Luminaire to act as the "Master" unit and all other connected units are controlled by this unit. When a unit is set to "Slave" mode, it will only listen to and follow any commands sent from a "Master"...
1 function and other functions follow in sequence. 1. Simple 8-bit Mode Table 2 provides DMX channel mapping of all DMX512 control values when the SL BEAM 100 LED Luminaire is in Simple 8-bit mode (as set by the luminaire’s menu system).
Installation & User’s Manual 2. Simple 8-bit Group Mode Table 3 provides DMX channel mapping of all DMX512 control values when the SL BEAM 100 LED Luminaire is in Simpe 8-bit Group mode (as set by the luminaire’s menu system).
Page 18
Installation & User’s Manual SL BEAM 100 LED Luminaires Table 4: SL BEAM 100 LED Luminaire DMX Channel Mapping (RGBW 8-bit Mode) Sh wline RGBW 8-bit Mode...
Page 19
SL BEAM 100 LED Luminaires Installation & User’s Manual Table 4: SL BEAM 100 LED Luminaire DMX Channel Mapping (RGBW 8-bit Mode) Sh wline RGBW 8-bit Mode...
Page 20
Installation & User’s Manual SL BEAM 100 LED Luminaires Table 4: SL BEAM 100 LED Luminaire DMX Channel Mapping (RGBW 8-bit Mode) Sh wline RGBW 8-bit Mode...
Installation & User’s Manual 4. RGBW 8-bit Group Mode Table 5 provides DMX channel mapping of all DMX512 control values when the SL BEAM 100 LED Luminaire is in RGBW 8-bit Group mode (as set by the luminaire’s menu system).
Page 22
Installation & User’s Manual SL BEAM 100 LED Luminaires Table 6: SL BEAM 100 LED Luminaire DMX Channel Mapping (RGBW 16-bit Mode) Sh wline GBW 16-bit Mode...
Page 23
SL BEAM 100 LED Luminaires Installation & User’s Manual Table 6: SL BEAM 100 LED Luminaire DMX Channel Mapping (RGBW 16-bit Mode) Sh wline GBW 16-bit Mode...
Page 24
Installation & User’s Manual SL BEAM 100 LED Luminaires Table 6: SL BEAM 100 LED Luminaire DMX Channel Mapping (RGBW 16-bit Mode) Zoom Focus Timing Intensity Timing Allows for timing control of colors. Channel should Color Timing default to 255 for smoothest actions using console and/or manual fades.
Installation & User’s Manual 6. RGBW 16-bit Group Mode Table 7 provides DMX channel mapping of all DMX512 control values when the SL BEAM 100 LED Luminaire is in RGBW 16-bit Group mode (as set by the luminaire’s menu system).
SL BEAM 100 LED Luminaires 7. HSIC Mode Table 8 provides DMX channel mapping of all DMX512 control values when the SL BEAM 100 LED Luminaire is in HSIC mode (as set by the luminaire’s menu system). Table 8: SL BEAM 100 LED Luminaire DMX Channel Mapping (HSIC Mode)
Installation & User’s Manual 8. HSIC Group Mode Table 9 provides DMX channel mapping of all DMX512 control values when the SL BEAM 100 LED Luminaire is in HSIC Group mode (as set by the luminaire’s menu system). Table 9: SL BEAM 100 LED Luminaire DMX Channel Mapping (HSIC Group Mode)
9. SL BEAM100 LED Luminai r e DMX Timing Channel Detail Timing channel control improves the timed moves of certain groups of parameters. The SL BEAM 100 LED Luminaire provides timing channels in 16-bit mode (one for intensity time and one for color time) and one timing channel in 8-bit (color and intensity timing combined).
SL BEAM 100 LED Luminaires 10. SL BEAM 100 LED Luminaire RDM Parameter IDs The following tables outline and describe all the RDM parameters IDs associated with SL BEAM 100 LED Luminaires. Table 11, “SL BEAM 100 LED Luminaire RDM Product Parameters IDs”...
Page 36
PRESET_PLAYBACK 0x1031 Table 14: SL BEAM 100 LED Luminaire RDM Manufacturer Status IDs Manufacturer Specific messages are in the range of 0x8000 - 0xFFDF. Each Manufacturer-specific Status ID shall have a unique meaning, which shall be consistent across all products having a given Manufacturer ID. See Table B-2, ANSI E1.20- 2010.
Page 37
SL BEAM 100 LED Luminaires Installation & User’s Manual Table 15: SL BEAM 100 LED Luminaire RDM Manufacturer Specific PIDs for Root Device Type Length Unit Prefix Default Description Allowed Allowed Parameter IDs Category - Manufacturer Defined PIDs - Range is 0x8000-0xffdf (See ANSI E1.20-2010 Standard, Table A-3) ■...
SL BEAM 100 LED Luminaire. These types of cleaners or solvents can permanently damage the optics or housings of the fixture. If you have any questions regarding the use or care of your SL BEAM 100 LED Luminaire, please contact Showline technical support or your local Authorized Dealer.
