EL
WALL – MOUNT
INSTALLATION AND OPERATING
INSTRUCTIONS
Twitoplast Company thanks you for purchasing the Opal
El –Electrical Operation.The Opal EL device enables
zone/room temperature control, by means of adjusting
the airflow through the damper. The Opal EL device
was designed for optimal use to insure both quick
installation and comfortable & perfect air condition
temperature.
System Configurations
1. Stand Alone:
3
The Opal EL controls one
Damper.
5
1 OPAL EL
2 Transformer 12 vac only
1
3 C508 Motor
4 RJ-11 cable
5 Motor cable±
2. As an Integral part of
ZC-107 system.
The Opal EL controls one Damper, but has also an
affect on the A/C operation it self through the Zone
Control System ZC207
®
http/www.twitoplast.co.il
2
2
Containing :
• Opal EL – Dimmer.
• RJ-11 Cable.
• Red & Black ±Cable.
• Electrical Motor C508-TW .
• Installation & Operating
Instructions.
Please Note: 12 VAC Only
Transformer not included.
Can be purchased separately.
®
9 Drezner St. Segula Industrial Zone,
Petach Tikva 49277, ISRAEL
Tel: 972-3-9345888
e-mail:export@twitoplast.co.il
NEW
Fax: 972-3-9042729
®
ELECTRICAL OPERATION
(FOR DAMPER)
INSTALLATION AND OPERATING
INSTRUCTIONS
WALL
MOUNT
EL
