HTP‐T804

H.264 4CH VIDEO SERVER

User Manual

Ver. 1.0

Table of Contents

Need help?

Do you have a question about the HTP-T804 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hunt CCTV HTP-T804

Page 1 HTP‐T804 H.264 4CH VIDEO SERVER User Manual Ver. 1.0...
Page 2 We appreciate your purchasing HTP-T804. Before installing the product, please read the following with care. Make sure to turn off the power before installing HTP-T804. Do not install under the direct sunlight or in dusty areas. Make sure to use the product within the temperature and humidity specified in the specification.
Page 3: Table Of Contents
HTP-T804 User Manual Table of Content 1. Introduction ............................3 1. About User Manual........................3 2. Feature............................3 3. Product and Accessories ......................5 4. Part Names and Description...................... 6 5. System Modes and Connections ....................7 2. Installation ............................10 1.
Page 4: Introduction
1. Introduction 1. About User Manual The User Manual is provided to advise how to use this premium network camera, HTP-T804. This manual includes how to trouble shoot in case of problems as well as installation, operation and setting up the HTP-T804.
Page 5 HTP-T804 User Manual Sensor and Alarm Support direct connections of external sensor and alarm devices. Event Alarm Connection to internal or external USB storage for remote access User Interface System status display utilizing OSD(On Screen Display) Diagnose and upgrade through dedicated program called True Manager...
Page 6: Product And Accessories
HTP-T804 User Manual 3. Product and Accessories HTP-T804 System User Manual Power adaptor and cable CMS S/W CD Screws Brackets <Picture 1> Product and Accessories...
Page 7: Part Names And Description
HTP-T804 User Manual 4. Part Names and Description Front View Parts Function LEDs Display power On/Off condition, Link, Status and data USB port for any USB device SENSOR Sensor input ALARM Relay output RS-232 Serial communication port 1 (COM1) for PTZ control or bi-...
Page 8: System Modes And Connections
AUDIO OUT Audio Output 5. System Modes and Connections The HTP-T804 system operates as Encoder and can be connected in either 1-to-1 fashion where HTP-T804 is connected one decoder or 1-to-many fashion where HTP-T804 connected to many decoders. Following chart shows possible combinations of video, audio and serial data transmission.
Page 9 HTP-T804 User Manual can be transmitted and a decoder is installed at a center location to receive and view the video images on analog monitor. Audio and serial data are transferred in either direction. 1:N Connection (Unidirection) Remote Center Site...
Page 10 HTP-T804 User Manual Site Remote Center Encoder Site Remote Center Encoder Decoder CMS (Central Monitoring System) is a Windows based remote monitoring program to access multiple encoders for real-time monitoring or control of the encoders and connected cameras. Please refer to...
Page 11: Installation
2. Installation 1. Connecting Video Encoder System Connect video output line to the encoder (HTP-T804) video input port. 2. Connecting Audio Audio is bi-directional in any configuration regardless of the system mode. If necessary, it can be configured to be in transmit-only, receive -only or bi-directional mode.
Page 12 HTP-T804 User Manual Encoder LED Display PWR STATUS LINK DATA Green Blinking Above LED status display shows that neither camera is connected nor a decoder is connected. Once the encoder is connected to a decoder, color of link LED will light in green color and the LED will blink as video or audio transmissions occur.
Page 13: System Operation
HTP-T804 User Manual 3. System Operation 1. LED Display Description of LEDs System status can be monitored with LEDs. State Description No power Power on Green blinking Normally operating System failure: Needs diagnostics Constant change of colors NTSC/PAL setting does not match with input...
Page 14 HTP-T804 User Manual Video Monitoring using Internet Explorer If HTP-T804’s IP address in entered on the Internet Explorer, the system will ask for confirmation to install Active-X control. Once authorized, the Internet Explorer will start to display video images from the encoder as shown below.
Page 15: Initialization Of Ip Address
Focus Near, Focus Far, Auto Focus Adjust the focus Sensor Input When the sensor on the HTP-T804 is connected and working, the light turns red. Alarm Output Alarm Output button can trigger an event directly from the Live View page.
Page 16 HTP-T804 User Manual - Base port : 2222 - Http port : 80 -15-...
Page 17: Remote Configuration
4. Remote Configuration 1. Remote Configuration The server can be configured using web browser. Type IP address of HTP-T804 in the address input area of Internet Explorer, then a live viewing screen will be displayed. Press Setup button located in the upper right area of the monitoring screen, then the se page for server setup will be displayed.
Page 18: System Configuration
HTP-T804 User Manual 2.1 System Configuration System ID System ID: Alphanumeric System ID to be transferred to remote software Language Language to be used for web-based configuration Firmware version Current firmware version -17-...
Page 19 HTP-T804 User Manual Board ID Network board ID of HTP-T804 recognized by system Start Time Latest system boot date and time Current Time Current date & time: Enter a new date and time and press Set Current Time button to update date &...
Page 20: Video Configuration
HTP-T804 User Manual 2.2 Video Configuration -19-...
Page 21 HTP-T804 User Manual Input Format Select channel and video input format. - ENCODE Resolution Selectable video compression resolution as below: NTSC : 720 x 480, 720x 240, 352 x 480, 352 x 240 PAL : 720 x 576, 720 x 288, 352 x 576, 352 x 288 Frame Rate Select video frame rate (the maximum number of frames of video images to compress.)
Page 22 HTP-T804 User Manual - DUAL ENCODE Use Dual Encode Select On to use dual encode Dual Encode Algorithm H.264 and MJPEG can be selected for secondary streaming. Maximum resolution is 720 x 480 and there are 8 steps of resolution. If MJPEG is selected, Preference supports only Quality mode.
Page 23 HTP-T804 User Manual Sensitivity A condition to trigger an event of motion detection. The value determines the sensitivity of the motion detection within a block: the smaller, the more sensitive. It is selectable from from 0 to 10. Information Display System ID and/or server time can be display over the video window in Web View.
Page 24: Audio Configuration
HTP-T804 User Manual 2.3 Audio Configuration Mode Select audio operation mode. Mode Status No operation TX-Only Transmit only RX-Only Receive only TX & RX Transmit and Receive Input Gain Set audio input gain. -23-...
Page 25: Network Configuration
HTP-T804 User Manual 2.4 Network Configuration -24-...
Page 26 RTSP port used for RTSP-based connection SNMP HTP-T804 can be used as an SNMP agent. It is compatible to both SNMPv1 and SNMPv2c. Vender specific MIBs for IP camera/server are defined. SNMP listen port can be set and disabled when it is 0. SNMP trap is also supported. Destination IP and port can be set. If one of these values is 0, SNMP trap will be disabled.
Page 27: Serial Port Configuration
HTP-T804 User Manual - True DNS : use True DNS service. Systems can be registered on the website for TrueDNS service: http://ns1.truecam.net. System will get a domain name of xxx.truecam.net style. Refer to the user guide document for True DNS service.
Page 28 HTP-T804 User Manual Serial Port Configuration There are two serial ports, (COM1 and COM2) in HTP-T804. While COM1 port is fixed to RS- -27-...
Page 29 The ID value range can be between 0 and 255. PTZ Port Select the serial port used for PTZ camera control. Sensor Type There are two sensor input ports on HTP-T804. Each of the sensor ports can be configured to the following. Function Operation...
Page 30: Event Configuration
HTP-T804 User Manual 2.6 Event Configuration -29-...
Page 31 HTP-T804 User Manual The event configuration configures the actions for each event type. Local section configures the actions for events from local (self) system, and configuration activates local devices and Remote sections configures the actions for events from remote(peer) system.
Page 32 HTP-T804 User Manual On Motion Configure the actions when motion is detected. Multiple actions can be set for a single event. On Disconnect Configure the actions when the link (connection) with peer system is disconnected. Multiple actions can be set for a single event.
Page 33: Preset Configuration
HTP-T804 User Manual 2.7 Preset Configuration Preset Name Move PTZ Camera to normal view Press Set Button Save Configure up to 15 preset positions. Preset function is not available on some PTZ receivers. Make sure to check if a PTZ receiver supports preset.
Page 34: User Configuration
HTP-T804 User Manual 2.8 User Configuration User can be registered and privilege level of a user can be specified. User configuration is allowed only to admin user. Max 16 users can be registered and each user can have one of f our privilege.
Page 35 HTP-T804 User Manual User ID and password need to be entered and privilege level need to be selected. User ID and password consist of alphanumeric string of max 15 characters. Delete User A user is deleted by pressing Delete button.
Page 36 HTP-T804 User Manual privilege. It is not allowed to change the privilege level of admin user. Login Policy Skip Login is provided for convenient access to the server when authentication is not required. When Skip Login is set to Enable, login step is skipped. The privilege level after login in this way is determined by the setting of Privilege Level After Login Skipped.
Page 37: Trouble Shooting
HTP-T804 User Manual 6. Trouble Shooting 1. Illegal Connect Error If an unauthorized connection has been established, the system will not function properly. Maintaining the connection, error condition will be displayed for correction. Illegal connect sing will appear in such conditions as:...
Page 38: Appendix A: Sensor And Alarm Port
HTP-T804 User Manual Appendix A: Sensor and Alarm Port 1. Sensor Port Terminal Type * Voltage Rating: 150VAC * Current Rating : 2A * Color : Red Sensor Signal Input Type * NO Contact Signals Connection to External Device 2. Alarm Port...
Page 39: Appendix B: Serial Port
HTP-T804 User Manual Connection to External Device Appendix B: Serial Port 1. RS-232 Port Port Type * 3 PIN * Pin Arrangement * Pin Description Pin NO Pin Name Description RS232 TX(Transmit) RS232 RX(Receive) Ground 2. RS-422/485 Port Port Type...
Page 40: Poe Specification
HTP-T804 User Manual * 4 PIN * Pin Diagram * Pin Description Pin No. Pin Name 설명 RS422 RX- RS422 RX+ RS422 TX- or RS485 TRX- It is selectable by S/W Setup RS422 TX+ or RS485 TRX+ It is selectable by S/W Setup 3.
Page 41 HTP-T804 User Manual Input voltage range : 36V to 57V 1500V isolation (input to output) PoE must be protected from over-voltages exceeding the 80V maximum rated surge input voltage Recommended Operating Conditions Parameter Units DC Supply Voltage DC Voltage Lockout Ta/°C...
