elive 01001 Quick Setup Manual

Betta Bowl & Planter
QUI CK SE TUP G UI D E
Item #s 01001, 01002
PA R TS
A – Glass bowl
B – LED base
C – Water collection cup
D – Planter
E – Desktop organizer
1
ASS E M B LY
Check to make sure none of the kit components are
damaged before setup. If damaged parts are discovered
call 1-855-ELIVE18 or email elivesupport@elivepet.com
for customer support. Do not return the product directly
to the retail store.
Install 3 AA batteries to power
the LED light See Figure 1.
Alternatively, there is a mini-USB plug in the base that
can power the unit using the appropriate 5V adaptor
cable. When using an adaptor cable, always use a drip
loop for safety. See Figure 2.
2
PR E PA RI NG T HE
.
PL A N T E R
The planter may be used for live or artificial plants,
or it can be used as a desktop organizer by installing
Part E onto the top of the planter.
Select your plant and
planting media
See Plant Suggestions for recommended species.
Place the plant in the planter
Cover the roots with planting media. The planting
media may depend on the type of plant, but aquariuim
gravel, decorative marbles, or organic potting soils are
suggested. See Figure 3.
When using soil
An added thin layer of gravel to the bottom
of the planter is recommended to aid in drainage.
A
3
PR EPA R IN G
.
T HE F IS H BOWL
Decorate the fish bowl
Rinse aquarium gravel, marbles, and any other décor
with cold water before adding to the fish bowl.
Fill the fish bowl
with dechlorinated,
room temperature water
Do not fill the bowl all the way. Leave at least
a 1/2 inch gap between the water's surface and
the top of the bowl. See Figure 4.
The LED light includes
a built-in 4 hour timer
Press the power button once to turn the LEDs on
and they will stay on for 4 hours before turning off.
This feature helps to conserve battery life and can
be used as a nightlight.
The setup is now complete
Add one betta fish to the bowl. The Betta Bowl
and Planter is intended for one betta fish.
E
C
D
B
Fig. 1
Fig. 2
Fig. 3
Fig. 4
