Smartenit Harmony Platinum 6005A Quick Start Manual

Technical Support
(877) 495-0144
www.smartenit.com
Harmony Platinum -
Home Automation Network Gateway

Installation

The Harmony Platinum must be installed indoors
1. With power disconnected, insert SD card properly*
2. Screw antenna (included) onto antenna port
3. Connect network cable to Ethernet port
4. Connect power supply (included)
5. Optional: If using an EZIComm for INSTEON or X10
communication, connect the EZIComm to the PLM port with a
straight-through CAT5e cable. Plug the EZIComm into a 120V AC
outlet.
* Never insert or remove SD Card when device is powered.
Note: USB port is for future expansion

Set-up

As updates are made for the best user experience, please visit our Wiki to get the most recent "how-to" instructions for using
the iSmartenit application with your Gateway.
iSmartenit Wiki - http://wiki.smartenit.com/ISmartenit

Basics

1. Install iSmartenit app - available on iTunes, Google Play, or open web app at http://harmonygateway.com
2. Create a user account to register your gateway for easy access from any iSmartenit application (optional)
3. Discover the Harmony Gateway on your local network
4. Discover your smart devices
5. Directly control and monitor your smart devices
6. Set up Wizards to automate smart device control and monitoring
2013 Compacta International, Ltd. - Rev.
Harmony Platinum and Smartenit are trademarks of Compacta International, Ltd.
ZigBee is a registered trademark of the ZigBee Alliance
Quick Start Guide
Model #6005A
4/2013

Product Brief

The Harmony Platinum offers ultimate flexibility
for home and building automation control.
The Harmony Platinum communicates with ZigBee
devices on the Home Automation (HA) profile,
WiFi devices, as well as INSTEON and X10 devices
when connected to an EZIComm PLM.
Control and monitor your home automation
network from any computer connected to the local
network or the Internet.
Reset
USB
Button
Antenna PLM
Port
For more information, please visit our Wiki
http://wiki.smartenit.com
SD Card Slot
Power
Input
Ethernet Status
LED
