Summary of Contents for CONIA CL1901HDVDR
- Page 1 CONIA CL1901HDVDR 19 LCD TV...
-
Page 3: Table Of Contents
Contents Contents Caution Safety Information Accessories Technical Specification Product Introduction Front View Rear View Connections Remote Control Basic Operation OSD Menu 9-15 1. CHANNEL menu 2. PICTURE menu 3. SOUND menu 4. TIME menu 5. OPTION menu 6. LOCK menu 16-18 Multimedia Operation Recording Operation... -
Page 4: Caution
Caution Caution The lightening flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 5: Safety Information
Safety Information Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below . Electrical safety • The TV set should only be connected to a mains supply which matches that stated on the label on the mains adaptor. -
Page 6: Accessories
Accessories & Technical Specification Accessories REC LIST CH/LIST SUBTITLE PVR/DVD TV/AV DISPLAY PICTURE NICAM/A2 SOUND SLEEP SCREEN TV/TXT CANCEL REVEAL SETUP D-MENU TITLE HOLD SIZE SUBPAGE INDEX GOTO SLOW User’s Manual Remote control Mains adaptor Mains cable Batteries * Note: The configuration of the components may look different from the following illustration Technical Specification - TV System PAL BG/DK/I SECAM BG/DK... -
Page 7: Product Introduction
Product Introduction Product Introduction Front View Insert a 12cm disc according to the silk. MENU VOL- VOL+ TV/AV PLAY EJECT MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. TV/AV: Display the input source menu. EJECT: Press the key to eject the disc. PLAY: Press the key to play/pause the DVD. -
Page 8: Connections
Connections Connections HDMI POWER: Connect to the mains adaptor. USB for PVR and media play . USB: HDMI: Connect it to the HDMI of DVD or other equipment. VGA: For PC display.Connect it to the D-Sub 15 pins analog output connector of the PC. PC-IN: Connect it to the audio output terminal of PC. -
Page 9: Remote Control
Remote Control Remote Control The remote control is using Infra-Red(IR). Point it towards the front of the LCD TV. The remote control may not work correctly if it is operated out of range or out of angle. POWER: Turn the TV on/standby. POWER MUTE MUTE: Press to mute the sound, press again or press... - Page 10 Remote Control Remote Control POWER MUTE REC LIST CH/LIST SUBTITLE PVR/DVD TV/AV DISPLAY CH / : Scan through channels. VOL / : Adjust the volume. PICTURE: Select the picture mode. NICAM/A2: TV Nicam/A2 select. SOUND: Select the sound mode. SLEEP: Standby timer. SCREEN: Turn on/off the screen.
-
Page 11: Basic Operation
Basic Operation Basic Operation Power on/off 1. Connect to the power supply with the power cord and an adaptor. 2. -To turn on the TV Press POWER button on the TV or remote control. -To turn off the TV Input Source Press POWER button on the TV or remote control. -
Page 12: Osd Menu
OSD Menu OSD Menu 1. CHANNEL menu Software Update(USB) Description Auto Scan Press OK button to enter the hint menu, and select Australia the Country and Tune Type mode for the TV, then press OK button to start auto tuning. DTV Manual Tuning Press OK button to enter the DTV Manual Tuning menu, select a DTV channel, and press OK button to start searching. - Page 13 OSD Menu OSD Menu Programme Edit Press OK button to enter the Program Edit menu as the following picture. Rename Delete: Select a channel and press RED button, “Delete” will appear on the right of the program edit menu next to the channel you have chosen, then press RED button again, the program will be deleted.
-
Page 14: Picture Menu
OSD Menu OSD Menu 2. PICTURE menu Description Picture Mode: Choose from Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Color and sharpness are only available and can be adjusted in the User mode option in the Picture Mode Settings. Contrast: Controls the difference between the brightest and darkest regions of the picture. -
Page 15: Sound Menu
OSD Menu OSD Menu 3. SOUND menu SPDIF MODE Description Sound Mode: Allows you to select among: Standard, Music, Movie, Sports and User. Treble(Could be adjusted when the sound mode is User): Controls the relative intensity of higher pitched sounds. Bass (Can be adjusted when the sound mode is set to User): Controls the relative intensity of lower pitched sounds. -
Page 16: Time Menu
OSD Menu OSD Menu 4. TIME menu Description Clock: Use the buttons to select the position, and use the buttons to set the time. Note: User can not change time manually during DTV mode, for time is from signal source directly. -
Page 17: Option Menu
OSD Menu OSD Menu 5. OPTION menu Australia Description OSD Language: Allows you to select menu language. Audio Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second audio language. Subtitle Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second subtitle language. -
Page 18: Lock Menu
OSD Menu OSD Menu 6. LOCK menu No Lock Description Lock System: Turn on/off the Lock System function. Note: You should enter the code to operate the menu.(original code is 0000) Set Password: Set pin code. If the Pin code has been changed you must enter the present code. -
Page 19: Multimedia Operation
Multimedia Operation Multimedia Operation Basic Operation 1). Press the TV/AV button on the remote control to display the input source menu, select USB source by the buttons, and press OK button to enter the Multimedia menu seen below. Input Source YPBPR HDMI Select... - Page 20 Multimedia Operation Multimedia Operation 1. Photo Play the photo Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Music: Play/pause the music program (you can only play or pause the music you have programed). Playlist: Display the playlist on the screen, and you can select the photo by button, and press OK button to program.
- Page 21 Multimedia Operation Multimedia Operation 3. Movie The maximum bit rate:6Mbps MPEG4 The maximum display resolution is DIVX4,DIVX5,XVID 720*576p MOVIE MPEG1/2 The maximum bit rate:9.8Mbps Play the movie Goto Timer Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
-
Page 22: Recording Operation
Recording Operation Recording Operation PVR function can only record digital TV channels, analogue channels can not be recorded via USB through PVR function. The USB port for PVR function supports most of USB 2.0 Flash Memory Stick Drive and USB 2.0 External Hard Disk Drive up to 400GB storage space. - Page 23 Recording Operation Recording Operation 3). Schedule List Display the recorder shedule Note: a. Could’t add shedules which have existent on the list; b. Could’t add shedules when the list is full, you have to delete some schedules; c. You could delete a schedules by RED button on the remote control. 4).
-
Page 24: Recording Operation
Recording Operation Recording Operation 5) Record Start When you finish the settings above, you could start recording by select Start Recording in the menu and press OK button in DTV mode. (You can also start recording by press the REC button on the remote control) Record buttons... -
Page 25: Dvd Operation
DVD Operation DVD Operation DVD Basic Operation Turn on your TV then use the TV/AV button on the remote control or on the TV to select DVD mode. Place a disc Insert a disc according to the silk. Do not touch the playing surface. automatically draw the disc into the player. -
Page 26: Disc Care
DVD Operation DVD Operation Subtitles 1. Compatible with DVD, SVCD discs. 2. Press the Subtitle button on the remote once, and the subtitle info banner appears 3. When a DVD or SVCD is recorded with subtitles, you can use the Subtitle feature to view the subtitles on-screen. -
Page 27: Dvd System Setup
DVD Operation DVD Operation DVD System Setup change them again. General Steps of Setup Menu 1. Pause or Stop the player. Press SETUP on the remote control. The main menu will be shown as below. 2. Press the button to select the Icon of the desired section, e.g. “TV System" and press button to open that section. - Page 28 DVD Operation DVD Operation "0000". Using the button, move the highlight to "PASSWORD", press the button and enter "0000". You will see the padlock symbol open. You may now change the RATING or put in a new password number. If the Lock symbol is BLUE you must press the button to enter the Please remember or write down the new Password and keep safe.
-
Page 29: Simple Troubleshooting
Simple Troubleshooting Simple Troubleshooting If the display fails or performance dramatically deteriorates check the Display in accordance with the following instructions.Remember to check the peripherals topinpiont the source of the failure. If the display still fails to perform as expected,connect your helpline for assistance. No power - Check all connections to the TV. -
Page 30: Important Notice
IMPORTANT NOTICE IMPORTANT NOTICE or 2 CONIA AUSTRALIA PTY LTD...
