Summary of Contents for Evolio Evotab 4
- Page 1 EVOTAB 4 TABLET USER MANUAL...
-
Page 2: Safety Precautions
EVOTAB 4 Safety Precautions On Battery Charge the battery only in temperature that ranges from 0℃ to 35 ℃. Do not charge Tablet PC if the battery is found damaged or leaking. On Operation Never subject Tablet PC to extremes of light, temperature, moisture or vibration. -
Page 3: Table Of Contents
EVOTAB 4 Contents SAFETY PRECAUTIONS ............ I ................II ONTENTS ..............1 HAPTER ASICS ............1 ARTS AND ONTROL ............2 ACKET ONTENTS ........2 OWER N AND FF THE DEVICE ............2 HARGING THE DEVICE ..........3 RANSFERRING ONTENTS .......... - Page 4 EVOTAB 4 ............32 HAPTER SETTINGS ................33 LARMS & ........... 35 IRELESS NETWORKS ................37 OUND ................37 ISPLAY ................37 TORAGE ................37 ATTERY ................. 37 & ............37 CCOUNTS SYNC ............37 OCATION SERVICE ................. 38 ECURITY &...
-
Page 5: Chapter 1 Basics
Chapter 1 Basics EVOTAB 4 is a Tablet with touch screen. It supports Wi-Fi. camera function and third party software, Users can get access to over 450,000 apps and enjoy TV shows, movies, music and much more. Parts and Control 1．... -
Page 6: Packet Contents
Chapter 1 Basics Packet Contents 1x Tablet PC 1x USB cable 1x User Manual Power On and Off the device Press and hold the Power button for 3 seconds to turn the device on. It may take a moment for the device to turn on and load. -
Page 7: Transferring Contents
PC via the supplied USB cable. Upon successful connection to PC, turn to the EVOTAB 4, on the status bar, flick upwards to display an ongoing list. Select “USB connected”, then tap on “Turn on USB storage”... -
Page 8: Evotab
Chapter 1 Basics From memory card This unit supports Micro SD card up to 32 GB To insert a Memory card Insert the card correctly with the contact pin facing downwards as illustrated below. Pushing the card into Memory card slot, then you should hear a click when the card is seated correctly. -
Page 9: Stand By /Wake Up Mode
(not included). Insert a USB storage device or memery card into the USB dongle, then connect the dongle to EVOTAB 4 via the USB cable. USB dongle and USB cable Stand by /Wake up mode Press Power button to enter Stand by mode, then the device locks automatically. -
Page 10: Home Screen
Chapter 1 Basics Home screen When the device is turned on, it will enter into the Home screen. Menu bar Search bar for web browser Main menu button Widget & Shortcut button Return button Home button Running application 7. Volume - button 8.Volume + button 9. -
Page 11: Customizing Home Screen
Chapter 1 Basics Status bar 10. USB connection 11. USB debugging 12. Memory card indication 13. Time Display 14. Wi-Fi connection 15. Battery indicator Flick upwards at the status bar to display an ongoing list, tap to display more status information. Customizing Home screen Adding icons on homescreen You can add shortcuts, widgets or folders to home... -
Page 12: Main Menu
Chapter 1 Basics “X”, when the icon turns red, release it to remove. Setting wallpaper for homescreen Wallpaper, select the desired picture as wallpaper. About the additional home screen You can use up to five screens. Flick left or right to go to other home screen. -
Page 13: Touch Screen Or Buttons
Chapter 1 Basics Touch screen or buttons Tap an icon to open an application. Tap at the bottom of the screen to display the menu bar. At the Menu bar, tap anytime to return to previous screen, press and hold to return to Home screen. -
Page 14: Onscreen Keyboard
Chapter 1 Basics Flick to scroll quickly. On webpage, drag up and down to scroll around the page（be care for so as not to click the link）. Tap or touch anywhere on the screen to stop it immediately. -
Page 15: Switching Screen Orientation
Insert a 3G mobile data card into the 3G dongle(not included), and connect the 3G dongle to EVOTAB 4 via the USB cable, then turn EVOTAB 4 tablet on, to enable data access over mobile network, from Main menu choose Settings Wireless&networks ... - Page 16 Chapter 1 Basics via the built-in G sensor. From Main menu, tap Settings Display, select Auto-rotate screen. Rotate the unit and the screen rotates too, automatically adjusting to fit the screen.
-
Page 17: Chapter 2 Getting Started
Chapter 2 Getting Started Web browser Voice search Voice search enables you to speak instead of typing for the web searching. From Main menu or Home screen, tap on display voice search box. Say your search term when it appear “speak now”(If not, on the top right), it will automatically... - Page 18 Chapter 2 Getting Started Tap the link on the webpage to open a new webpage. Drag up and down to scroll around the webpage. Double tap or pinch on the webpage to zoom in or zoom out. ...
- Page 19 Chapter 2 Getting Started Access to view history lists. To remove these lists, , then select Clear history. Settings to use more available function, including Privacy & security, Accessibility and so on. Refresh/Stop to refresh on the current page, tap X to stop loading the current page.
-
Page 20: Watching Videos
Chapter 2 Getting Started Watching Videos Playing videos On the Home screen or Main menu, tap Super-HD PlayerVideo folder to open video player. Drag up and down to scroll through the file list. Tap to select a video file for playback. ... - Page 21 Chapter 2 Getting Started Adjust the volume level. use the buttons on the side of EVOTAB 4. Display video menu Return to the video browser screen ： Notices If a bookmark is added, it allows you to continue playing from the bookmark when you open the video file next time.
-
Page 22: Playing Music
Chapter 2 Getting Started Playing Music About music library From Main menu, tap Music to enter into music library. Sorting by artist Sorting by album All songs Sorting by Playlist Return to Now playing screen Playing songs 1. From Home screen or Main menu, tap Music to enter music library. - Page 23 Chapter 2 Getting Started Controlling Song Playback Pause play songs. Play previous next song. Fast rewind or fast Touch hold forward Skip to any point in Tap anywhere or Drag a song the playhead on the progress bar. Adjust the volume level.
- Page 24 Chapter 2 Getting Started Display the current song list Set shuffle mode Set Repeat mode Display the music playback menu current Add to playing song playlist. playlist Delete the current Delete. song To return to the Media Library Using the playlist Use the playlist to manage the songs in the library Creating a new playlist...
-
Page 25: Viewing Photos
Chapter 2 Getting Started Tap on a desired playlist, then the current song has been added into the selected playlist. Viewing photos On the Home screen or Main menu, tap Super-HD PlayerPhoto folder to view photo. Thumbnail View Thumbnail view displays the catalog as a table of thumbnail images in adjustable sizes. - Page 26 Chapter 2 Getting Started In full screen mode, tap to return to thumbnail view mode. Start to view photo Tap on the screen to show / hide the control bar. View the previous / Flick Left/Right on the next photo. screen.
-
Page 27: Using Camera
Chapter 2 Getting Started Return to thumbnail mode. Notes: In zoom in /out mode, drag your finger up, down, left or right to move photo. Rotate the unit to switch screen orientation. Using Camera From Main menu, tap Camera to enter camera mode. ... -
Page 28: Sound Recording
Chapter 2 Getting Started mode. Camera settings to set White balance. to set Exposure. to set Store location/ Picture size. Camcorder settings to set White balance. to set Time lapse interval. to set Store location. Sound Recording From Main menu, tap Sound Recorder to enter sound recording mode. - Page 29 Chapter 2 Getting Started Recording a voice file Press to start recording a voice file. Press to stop recording. Press to play back the current recorded voice file. It will display a message window to choose “Done”...
-
Page 30: Gmail
Chapter 2 Getting Started The record is saved in Record folder, open “Explore”，then open Record folder, tap on the desired recorded file to be played . Gmail Setting up Gmail Accounts Prior to the use of e-mail, you need to set up the mailbox account. -
Page 31: File Manager
Chapter 2 Getting Started Use the option menu, the available options are: Read, Archive, Mute, Mark read, Delete, Add bar,Change labels. About the Mail menu In the mail list, tap to display a mail menu Refresh：Refresh Mail ... - Page 32 Chapter 2 Getting Started From Main menu, tap File Manager. Tap to select Internal / Micro SD card memory/USB at the top bar to enter. Drag up and down to scroll through the file list to select the desired folder or file. ...
- Page 33 Chapter 2 Getting Started File Edit menu Folder Edit menu Select multiple files or folders You can select multiple files or folders at the same time. 1. On the Tool bar, tap 2. Tap the desired files/folders to be selected, then they will be marked with a “√”.
- Page 34 Chapter 2 Getting Started From the file list, tap to select the desired files/folders to be copied or moved, then select Move or Copy. Go to the target folder that you want to put the selected file or folder, touch and hold to show the folder Edit menu.
- Page 35 Chapter 2 Getting Started Note: if only copy/move/delete one file/folder, you can touch and hold the desired file or folder to show the Edit Menu, then follow the above steps to do. Attach file/folder via email From the file list, tap to select the desired files/folders to be copied or moved, then they will be marked with a “√”.
-
Page 36: Managing Third Party Applications
2. Copy the downloaded applications to the unit (you can also download the desired applications from the brower in your EVOTAB 4 Tablet.). 3. Disconnect this unit from the computer. Note: The system only supports XXX.apk format applications to be installed. -
Page 37: Alarms
Chapter 2 Getting Started Uninstall application 1. From the Main menu, then tap SettingsApps. 2. Select the application you desire to uninstall, then tap Uninstall. Note: The default applications can’t be uninstalled from the unit. Alarms From Main menu, tap Clock Set alarm to start clock alarm setting. - Page 38 Chapter 2 Getting Started If at least one alarm is set and turned on, it will appear “Alarm set:Time” on home clock screen. Turn an alarm on or off: tap the next to the desired alarm to turn the alarm on or off. If an alarm is set to sound only once, it turns off automatically after it sounds.
-
Page 39: Networks
If more than one previously used network is in range, EVOTAB 4 joins the one last used. When EVOTAB 4 is connected to a Wi-Fi network, the Wi-Fi icon at the top of the screen shows connection strength. - Page 40 Using a mobile data connection Insert a 3G mobile data card into the 3G USB dongle(not included), and connect the 3G USB dongle to EVOTAB 4 via the USB cable, then turn EVOTAB 4 tablet on, to enable data access over mobile network,...
-
Page 41: Sound
Storage View the memory status of Micro SD card and internal storage, format internal storage. Battery View the battery status of EVOTAB 4. Apps Allows you to manage the applications sorted by Download, On SD card, Running and All. Accounts & sync Allows you to add new account and sync all the accounts. -
Page 42: Security
Backup & reset Allows you to backup account, app data, Wi-Fi passwords, and other settings to Google servers. Additionally, you can erase all data on EVOTAB 4 and reboot into the system in Recovery mode. Date& Time Set date, time, time zone and display format. -
Page 43: Ppendix
Chapter 4 Troubleshooting If the device does not function as it is expected, please try the following steps. The device is not responding or can’t be turned Reset the device by pressing the Power button for 6 seconds. The device will be forced shutdown if it is on and you are required to restart the device again. -
Page 44: Maintenance
Chapter 5 Appendix Maintenance If Tablet PC does get wet, turn off Tablet PC immediately. Wait for Tablet PC to dry completely before turning on again. Clean the screen with a soft cloth; be careful not to wipe it with anything abrasive. When carrying your Tablet PC in bag, keep Tablet PC in the protecting case supplied to avoid scratches. -
Page 45: Chapter 5 Appendix
Chapter 5 Appendix Storage memory Built in memory: 4 GBGB Supports Micro SD card up to 32GB. Media File Format supported Audio: MP3, WMA, APE, FLAC, AAC, WAV, OGG Photo: JPG, PNG, BMP, GIF, TIF Video: Support up to HD2160P: AVI, MPG, MKV, RM, RMVB, MP4, MOV, VOB, DAT, FLV, TS, 3GP, WEBM (VP8) etc. -
Page 46: Certification Information
Chapter 5 Appendix Charging Power: DC 5.0V, 1.5A Duration: 4 hours (approx) Physical properties Dimension: 182.4*121.8*11.2mm Weight: 299g (approx) ※ Design and specifications are subject to change without prior notice Certification information On FCC This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. -
Page 47: Copyrights Andt
Chapter 5 Appendix Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. WARNING: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THE DEVICE. -
Page 48: Disposal Andr
Chapter 5 Appendix Disposal and Recycling Information Your Tablet PC must be disposed of properly according to local laws and regulations. Because this product contains a battery, the product must be disposed of separately from household waste. When your Tablet PC reaches its end of life, contact your local authorities to learn about recycling options.
