A
B
C
借 ( 通 ) 用件登记
描
图
描
校
旧底图总号
底图总号
处数
标记
设 计
签
字
审 核
工 艺
日
期
标准化
1
技术要求：
所有内容的印刷颜色均为
1.
规格为：
2.
如供应商的排版需要加空白页，请加在后面
3.
签 名
更改文件号
校 对
审 定
批 准
日 期
1
PANTONE Black C
A4
英文用户手册
TRD-WQP8-9239H S/S
TRIESTE
日 期
阶 段 标 记
00
REV.
数
量
1
1
张
共
2
(9239H)
新西兰
比 例
重
量
广东美的集团股份有限公司
美的洗涤电器制造有限公司
1
张
第
2
A
B
C
6710004578
D
D
80G双胶
Advertisement
Table of Contents
Related Manuals for Trieste TRD-WQP8-9239H S/S
Summary of Contents for Trieste TRD-WQP8-9239H S/S
- Page 1 技术要求： 所有内容的印刷颜色均为 PANTONE Black C 规格为： 如供应商的排版需要加空白页，请加在后面 借 ( 通 ) 用件登记 描 图 描 校 英文用户手册 旧底图总号 TRD-WQP8-9239H S/S 6710004578 (9239H) 新西兰 TRIESTE 底图总号 处数 标记 签 名 日 期 阶 段 标 记 比 例 更改文件号 80G双胶 REV.
- Page 2 TRD-WQP8-9239H S/S...
- Page 3 For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. With each wash cycle. Compartment Fill the detergent dispenser For programmes with pre-wash only. (Follow the user instructions!) Check the rinse aid level Electric indicator on control panel (if provided).
- Page 4 Dear Customer, Please carefully read this manual bef ore using the dishwasher, it will help you to use and maintain the Control Panel...........2 dishwasher properly. Dishwasher Features........2 Keep it to refer to it at a later date. Pass it on to any subsequent owner of the appliance. 、...
- Page 5 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of anelectric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
- Page 6 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Power in dica tor light and switch: To turn on/off Progra m in dicator lights and bu tton: To select and show the power supp ly. one of the three and show the washing p rogram.
-
Page 7: Adjusting Salt Consumption
Before using your dishwasher for the first time: Set the water softener ／ Pour 1 2 litre of water inside the salt container and then fill with d ishwash er salt Fill the rinse aid dispenser Fill in detergent The water softener must be set manually, using the water hardness dial. The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. -
Page 8: Rinse Aid Dispenser
Always use the salt intended for use with dishwasher. The salt contain er is located beneath the lower basket and should be fill ed as explained in t he foll owing: Attention! Only use salt spe cif ically desi gne d for t he use i n dishwashers! Every other type of salt not speci fically de sig ned fo r the u se in a d ishwasher, espe cially table salt, will damage the w ater sof tener. -
Page 9: When To Refill The Rinse Aid Dispenser
When to Refill the Rinse Aid Dispenser If there is no rinse-aid warning light in the control panel, you can estimate the amount from the colour " " of the optical level indicator C located next to the cap. When th e rinse-aid c ontainer is full, the whole indicator will be dark .As the rinse -aid diminishes, the size of the dark dot decreases. -
Page 10: Concentrated Detergent
Normally new pulverised detergent is with out phosphate. Thus the water softener function of phosphate is not given. In this case we recommend to fill salt in the salt con taine r even when ° the hardness of water is only 6 dH. If dete rgents witho ut phosphate are used in the case of hard water often white spots appear on d ishes and glasses. -
Page 11: Fill In Detergent
Fill in Detergent Fill the detergent dispenser with detergent. The marking indicate s the dosing levels , as illustrate d on the righ t: The place of main wash cycle deterg ent placed , “ ” MIN me ans approximately 20g of detergent. The place of pre-wash cycle deterge nt placed , approximately 5g o f detergent Plea se o bserve the manufacturers dosing and storage... - Page 12 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, take glass and cutlery out of the dis hwa sher as soon as possible after the program has ended.
-
Page 14: Adjusting The Upper Basket
Adjusting the Upper Basket The height of the upper basket can be adjusted in order to create more space for large utensils both for the upper/lower basket. The height of the upper basket can be adjusted by placing the wheels on different h eight of the rails. Long items, serving cutlery, salad servers and knives should be placed on the shelf so that they do not obstruct the rotation of the spray arms. -
Page 16: Switch Off The Dishwasher
Premise: A cycle that is underway can on ly be modified if it has on ly been running fo r a short time. Otherwise, the d etergent may have already b een released, and the a ppliance may have alread y drained the wash water. If this is the case, the detergen t dispenser must be refilled (see the section entitled "... -
Page 17: Filter Assembly
The filter prevents larger remnants of food or other objects from getting inside the pum. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Fo od and soil particles trap ped in this filter are pulverized by a specia l jet on the lower spray arm and washed down to drain. -
Page 18: Cleaning The Filter
Remarks: - Inspect the filters for blo cking a fter e very time the dishwa sher has been used. - By unscrewing the coarse filter, you can remove the filter system. Re move any foo d remna nts and clean the filters under running water. The entire filter assembly should be cleaned once a week. - Page 19 When not in Use for a LongTime After Every Wash It is recommend that you run a was h cy cle with the After every wash, turn off the water supply to the dishwasher empty an d the n remove the plug from the appliance and leave the door slightly open so that socket, turn off the wa ter supply and leave the door of moisture and odours are not trapped inside.
- Page 20 Improper connection of the equipment earthing conductor can result in the risk of an for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.
-
Page 21: Water Outlet
How to Drain Excess Water From Hoses If the sink is 1000 higher from the floor, the excess water in hoses cann ot be drained dire ctly into the sink. It will be necessary to drain excess water from hoses into a bo wl o r suitable container that is held outside and lower th an the sink. - Page 22 Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on closed securely.
- Page 23 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
- Page 24 Height : 850mm Width : 445mm Depth : 580mm Water pressure: 0.04-1.0MPa max 60 ℃ Hot water connection : Power supply: see rating label Capacity: 8 place settings...
