Summary of Contents for TeleEye GX624
- Page 1 GX Series HD Video Recording Server GX624 / GX629 / GX6216 Quick Start Guide...
-
Page 2: Table Of Contents
This manual is copyrighted. All rights are reserved. This manual should not be copied, reproduced or translated in whole or part without prior consent from Signal Communications Limited. TeleEye is a trademark of Signal Communications Limited and is registered in China, European Communities, Hong Kong, US and other countries. -
Page 3: Introduction
Various actions like sending video back to a designated receiving PC, video recording, email notification, etc. can be performed upon event triggering. TeleEye GX can also keep a comprehensive operation and event log for audit trail. - Page 4 Quick Start Guide PAGE 2 Item Description Item Description Quick start guide Power adaptor Registration code sheet HDD screws HDD recommendation Straight-through Ethernet sheet cable Alarm port connector & Warranty card alarm port cover Resistors Software CD (for tamper detection) Mouse...
-
Page 5: Hardware Features
Quick Start Guide PAGE 3 1.2. Hardware Feature 1.2.1. Front View 1. Notification LEDs Description Light up when power on Light up when performing recording Blink when an event is triggered 2. Main control buttons Button Description Select camera / Enter password Quick button for recording Display next camera /... -
Page 6: Back View
Quick Start Guide PAGE 4 3. Menu control / local playback control buttons Button Description Menu mode Playback mode Pause Down Stop Left Rewind Right Fast forward Enter Play 4. Front USB port 1.2.2. Back View 1. Power switch 2. Power input (16V DC) 3. -
Page 7: Functional Features
Quick Start Guide PAGE 5 1.3. Functional Features Independent & efficient HD recording stream 720p HDTV resolution (1280 x 720 progressive scan) Video recording up to 400 fps Configurable recording frame rate Supporting up to 4 SATA HDDs USB video extraction Flexible connections: LAN, broadband &... - Page 8 Quick Start Guide PAGE 6 3. Pull off the cover. 4. Loosen the screws of the hard disk holder.
- Page 9 Quick Start Guide PAGE 7 5. Insert HDD into one of the available holders. Maximum 4 HDD can be installed. 6. Mount the HDD to holder with attached screws.
- Page 10 Quick Start Guide PAGE 8 7. Remount the hard disk holder to TeleEye GX. 8. Connect the SATA cable to the HDD.
-
Page 11: Setup For Local Monitoring & Recording
3. Connect a monitor to the VGA output of TeleEye GX 4. Plug in the power adaptors to TeleEye GX, cameras and monitor 5. Switch on the power of TeleEye GX, a startup screen will appear on the connected monitor. - Page 12 Quick Start Guide PAGE 10 6. If an installed hard disk is not in TeleEye GX recognized format, it would be formatted automatically when startup completes. 7. TeleEye GX is ready for operation. Live video should appear on the monitor. By default, manual recording will be started automatically.
- Page 13 Used to open and close the OSD menu, or navigate backward to previous menu. (Right click) 9. TeleEye GX supports 3 recording modes to suit different situations: manual recording, schedule recording and event recording. When a camera’s video is being recorded, the icon will be shown next to its name and the LED will light up.
- Page 14 Quick Start Guide PAGE 12 HDD Format/Scan: View hard disk information Format and scan disk Recording: Select the recording mode Off: Disable recording Enable recording of all cameras Schedule: Enable schedule recording Image Size: Set recording resolution 720P: 1280 x 720 Q720P: 640 x 360 Video Quality: Set video quality...
-
Page 15: Setup For Remote Monitoring & Recording
Quick Start Guide PAGE 13 3. Setup for Remote Monitoring & Recording Equipment: TeleEye GX HD video recording server and its power adaptor Cameras and their power adaptors CAT-5 cable Network switch or router PC Requirements: CPU: Intel ® Core i3 Processor... - Page 16 4. Connect TeleEye GX to the network switch. 5. Switch on the power switch of TeleEye GX. 6. If all installed hard disks are not in TeleEye GX recognized format, they would be formatted automatically when startup completes. Setup Procedures on PC Side: 1.
- Page 17 Note: The DNS setting is used for sureLINK, time synchronization and e-mail notification. 6. Reconnect the video recording server to the Internet network. 7. Configure other network settings for TeleEye GX and the PC if necessary, such as router port mapping, firewall, etc. Please refer to the manual of the router.
- Page 18 Quick Start Guide PAGE 16 10. Use screen mode selection panel and camera selection panel (circled in red color in below figure) to view video. Note: If a cross sign is shown at the top left corner of the web page, it implies that Java JVM is not installed in the computer.
- Page 19 2. Enter the user name and password if login is required. Please refer to the setup manual of router. 3. Enter the IP address and port number of TeleEye GX in the NAT / port forward table of the router. Note that the naming for port forwarding may be different for different routers.
-
Page 20: Reference
Quick Start Guide PAGE 18 4. Reference For advanced operations, please refer to the TeleEye GX full user guide in the software CD.
