- Page 1 NiteDevil HD-SDI Cameras Stunning 1080p HD-SDI cameras with built NiteDevil ™ technology. Anti-Vandal Traditional Covert Mini Bullet All-In-On IR CAM320 CAM341-344 CAM350-351 CAM360-362 CAM380 Handbook & Instructions Manual Ref: XND-HD-02...
-
Page 2: Introduction
Introduction The ever impressive NiteDevil technology is now built into a wide range of our HD-SDI cameras. Our incredible 2.1 megapixel HD-SDI cameras record 1080p broadcast quality images at 25fps, that’s 20x the quality of the average analogue alternative. Connect these cameras to one of our HD-SDI DVRs and you’ll have an unrivalled CCTV system. -
Page 3: Table Of Contents
Contents Introduction CAM320 - Anti Vandal HD-SDI Dome CAM341-344 - Traditional HD-SDI Camera CAM350/351 - Covert HD-SDI Modules CAM360/362 - Mini HD-SDI Bullets CAM380 - External HD-SDI All-In-One IR Camera OSD Menus Tips Accessories For more info, tips and advice visit nitedevil.com... -
Page 4: Cam320 - Anti Vandal Hd-Sdi Dome
CAM320 - Anti Vandal HD-SDI Dome Features • 1080p at 25fps • Low light 0.02 Lux (Sens-up) • Dual Voltage, 12V DC, 24V AC • Digital 64x Zoom • Privacy Masking Maximum IR Sensitivity • Wide Dynamic Range • Internal Wiring With its 1080p high-res image quality, this camera outputs the same stunning images as you would get from an HD TV programme. - Page 5 CAM320 - Inside The Camera Zoom Adjustment Adjust the zoom in/out of the camera by unlocking this screw. Tilt Axis Tilt Axis Focus Adjustment Unlock the side screws to tilt Unlock the side screws to tilt Adjust the focus after adjusting the the camera up and down.
- Page 6 CAM320 - Connecting The Camera Using RG59+4 ( PTZ Combo Cable ) The power connection terminals (marked in red) are polarity sensitive, therefore the power can be connected either way round. However, the RS485 connections polarity sensitive and must be connected as shown in the diagram above.
- Page 7 CAM320 - Mounting The Camera The camera can be mounted on a wall, ceiling or attached to To ensure that the camera is weatherproof, a rubber grommet To ensure that the camera is weatherproof, a rubber grommet an optional wall bracket. is provided through which the cable enters the camera.
-
Page 8: Cam341-344 - Traditional Hd-Sdi Camera
CAM341-344 - Traditional HD-SDI Camera Features • 1080p at 25fps • True Day-Night • Wide Dynamic Range • Choice of 12V, Dual Voltage or 240V • 0.02 Lux (Sens-up) • Mirror / Privacy Function • Motion Detection Maximum IR A stylish high performance NiteDevil camera in a traditional Sensitivity style features Wide Dynamic Range and OSD Menu for mirror, privacy &... - Page 9 CAM341-344 - Connecting The Camera CAM341 12V DC & CAM343 Dual Voltage CAM345 - 240V AC CAM345 - 240V AC Power LED - Red High quality HD-SDI CVBS - Extra video OSD menu when powered up Power LED - Red out (BNC) output for set up selection joystick...
- Page 10 CAM341-344 - Fitting The Camera Lens Auto-Iris Direct Drive Connections C Or CS Mount Lenses Auto Iris type lenses require the 4-pin connector to be attached Most lenses are available in 2 different mounting options - C mount to the camera. In most instances your lens will be pre-wired with and CS mount.
- Page 11 CAM341-344 - Fitting The Camera Lens Adjusting The Inner Focus Ring To adjust the inner focus ring you will need to fi rst remove the lens. Next loosen the small cross-head screw which in Once you have fi tted the lens, if you have a picture on the turn loosens the inner focus ring as shown.
-
Page 12: Cam350/351 - Covert Hd-Sdi Modules
CAM350/351 - Covert HD-SDI Modules Features • 1080p at 25fps CAM350 • Low light 0.02 Lux (Sens-up) Board Lens Camera • Motion Detect • Privacy Masking • Just 35.5mm Wide • Wide Dynamic Range • Mounting Bracket Included NiteDevil HD-SDI covert camera module with on screen display for mirror, privacy &... - Page 13 CAM350/351 - Connecting & Mounting The CAM350/351 is supplied with a free mounting The CAM350/351 is supplied with a free mounting CVBS Test Output bracket that can be easily fi xed to virtually any surface. bracket that can be easily fi xed to virtually any surface. 2.1mm 12V HD-SDI DC Socket...
-
Page 14: Cam360/362 - Mini Hd-Sdi Bullets
CAM360/362 - Mini HD-SDI Bullets Features • 1080p at 25fps • Low light 0.02 Lux (Sens-up) • Digital 64x Zoom • Choice Of Lenses • Privacy Masking • Wide Dynamic Range CAM360 • Removable Sun Shield External Bullet With • Anti Vandal 3.7mm Board Lens CAM362... - Page 15 CAM360/362 - Connecting & Mounting The CAM360/362 is supplied with a free mounting The CAM360/362 is supplied with a free mounting bracket. A fi xing hole diagram is shown below to help bracket. A fi xing hole diagram is shown below to help when fi tting the camera bracket.
-
Page 16: Cam380 - External Hd-Sdi All-In-One Ir Camera
CAM380 - External HD-SDI All-In-One IR Camera Features CAM380W Polar White • 1080p at 25fps • 2.8 - 11mm Vari-focal Lens • Built-In IR LEDs • True Day Night • True Wide Dynamic Range • 62 x Digital Zoom PIP •... - Page 17 CAM380 - Connecting & Mounting The CAM380 comes fi tted with an adjustable cable The CAM380 comes fi tted with an adjustable cable managed bracket. Below is a diagram to help when managed bracket. Below is a diagram to help when mounting the camera.
- Page 18 CAM380 - Connecting The Camera Using RG59+4 ( PTZ Combo Cable ) CON370 ZULUG DC Plug with Terminal Strip adaptor 12V DC PSU From Camera Terminal To DVR or Block Monitor RS485 Keyboard or Test Monitor HD-SDI to control OSD Manual ref: XND-HD-01...
- Page 19 CAM380 - Camera Adjustments The CAM380’s menu controls, zoom and focus adjustments Once the front end of the camera has been removed you Once the front end of the camera has been removed you and CVBS test output are all cleverly hidden away inside the are then able to adjust the camera’s lens and menu settings.
-
Page 20: Osd Menus
Accessing The Menus Accessing The Menus RS485 To make life easier, all the HD-SDI cameras covered in To make life easier, all the HD-SDI cameras covered in this book have virtually the same simple menu system. this book have virtually the same simple menu system. The CAM320 and the CAM341-344 range also has traditional You can access the menus in the camera in two ways: You can access the menus in the camera in two ways:... -
Page 21: Main Menu
Main Menu Menu Structure CAM350/351 & CAM380 The following table shows the menu structure of the HD-SDI The menu structure for theses models differs slightly cameras covered in this book. Although all the cameras have from the other cameras covered in this book. Menu an almost identical menu system, a few options may not be options unique to these cameras will be identified available on every camera. - Page 22 Main Menu Continued - Options with this icon relate to the CAM350/351 & CAM380 Only MAIN MENU SUB MENU OPTION EXPOSURE DEFOG ON / OFF (CONTINUED) 3. DEFAULT 1. POS / SIZE: POSITION SIZE RET / AGAIN 4. RETURN: RET / END 2.
- Page 23 Main Menu Continued - Options with this icon relate to the CAM350/351 & CAM380 Only MAIN MENU SUB MENU OPTION DAY & NIGHT B&W: 1. BURST: ON / OFF 3. IR LED: ON / OFF (CONTINUED) 2. IR SMART: ON / OFF 4.
- Page 24 Main Menu Continued - Options with this icon relate to the CAM350/351 & CAM380 Only MAIN MENU SUB MENU OPTION ADJUST MONITOR LCD / CRT (CONTINUED) LCD: 1. GAMMA: AUTO / USER1 / USER2 / 0.45 ~ 1 3. RED GAIN: 0 ~ 100 2.
- Page 25 Special Menu Special Sub Menu CAM350/351 & CAM380 The following table shows the ‘Special’ sub menu structure. The menu structure for theses models differs slightly Although all the cameras have an almost identical menu system, from the other cameras covered in this book. Menu a few options may not be available on every camera.
- Page 26 Special Menu Continued - Options with this icon relate to the CAM350/351 & CAM380 Only SPECIAL MENU SUB MENU OPTION MOTION ON / OFF 1. SELECT: AREA1 ~ 3 4. MOTION VIEW: ON / OFF 2. DISPLAY: POSITION SIZE 5.
- Page 27 Special Menu Continued - Options with this icon relate to the CAM350/351 & CAM380 Only SPECIAL MENU SUB MENU OPTION DEFECT 1. LIVE DPC: ON / OFF / AUTO 5. LEVEL: 0 ~ 60 2. LEVEL: 0 ~ 60 6. SENS-UP: x2 ~ x60 3.
-
Page 28: Tips
Getting The Most Out Of The NiteDevil HD-SDI Range What the menu options do the level of amplitude however setting it too high could produce The NiteDevil HD-SDI range has a comprehensive menu a noisy image in low light conditions. system that allows you to set up the camera to get the most out of it in different demanding situations, below is a guide to some of the key functions:... -
Page 29: White Balance
Getting The Most Out Of The NiteDevil HD-SDI Range What the menu options do expose a subject in the foreground when a bright light source, such as a window, is situated behind it. Automatically sets the white balance by holding a white object You can choose the level of compensation for a bright such as a piece of paper or card in-front of the camera and background between Low, Middle and High as well... - Page 30 Getting The Most Out Of The NiteDevil HD-SDI Range What the menu options do switching to a black & white image could produce a better This is only recommended in areas where the light levels are quality image. always extremely low. There are various settings to ensure the camera produces the Auto best B &...
- Page 31 Getting The Most Out Of The NiteDevil HD-SDI Range What the menu options do D-Zoom NR (Noise Reduction) Enables the user to digitally zoom in on an area of the image if Noise reduction is the process of applying a filter to the image the optical lens is not quite enough.
- Page 32 Fault Finding Every NiteDevil camera is built to the highest standards and is fully See online for the ‘Dos And Don’ts Of Tip 259 tested prior to packing so if you experience an installation problem Supplies’ at nitedevil.com. Power you need to investigate your cabling, connections, power supply and monitor.
- Page 33 Fault Finding Ensure that the BNC - BNC lead that you connect Can’t control via 2 wire RS485 between the camera and monitor has no shorts or If your camera seems unresponsive when attempting to control it open circuits. If you are making your own via RS485 check the following.
-
Page 34: Accessories
Other Products To Consider 10 Reasons is great value for money alienHero HD 8ch 1. 1080p Recording (broadcast quality) Order Codes ALIEN674N 4ch 2TB: 2. Built-in Video Analytics (finds evidence instantly!) ALIEN678N 8ch 2TB: 3. High Definition HDMI Output (along with VGA) 4. - Page 35 Other Products To Consider - HD-SDI Transmission Solutions HD-SDI to HDMI Converter HD-SDI Video Signal BNC Lead HDMI Lead HDM050 Converter HDMI HD-SDI Camera CAM320 Monitor/TV Ideal for converting the HD-SDI output of a camera into an HDMI output for direct connection HDM050 Order Code: into an HDMI monitor.
- Page 36 Other Products To Consider - HD-SDI Accessories HDMI Monitors HDMI Leads HDMI LED-backlit LCD Our HDMI leads have monitor in a range of 24k gold connections for sizes with HDMI, VGA great image quality. & DVI inputs. VID501 1m HDMI Lead: LCD822 VID502 22”...
- Page 37 Other Products To Consider - Cable & Accessories Antihum RG59+2 3pc BNC Crimps Glued foil sheath provides maximum protection Cables can be separated for fast, These traditional 3-piece against interference and prevents “loose” foil easy installation shorting to the centre pin BNC crimp-on plugs are the popular choice for CCTV Installers.
- Page 38 Other Products To Consider - Useful Tools BNC Ratchet Crimp CCTV Test Monitor • PTZ Control Testing • DC/AC Voltage Tester • RS485 Data Test Function • 29 Protocols Supported • Check Video Signal Strength • 12V Camera Power Function •...
- Page 39 Other Products To Consider - Rack Mount Power Supplies 12V DC 10-Amp PSU With 18 Outputs 24V AC 10-Amp PSU With 18 Outputs Regulated 12V DC 10 Amp 1.5U rack mount power Regulated 12V DC 10 Amp 1.5U rack mount power Regulated 12V DC 10 Amp 1.5U rack mount power A 24V AC 10 Amp 1.5U rack mount power supply with A 24V AC 10 Amp 1.5U rack mount power supply with...
- Page 40 NiteDevil CCTV - Cameras That See In The Dark! You can find everything you need and more at nitedevil.com As well as information and spec on all our cameras, we offer a wide range of support to help you get the most out of your NiteDevil equipment.
