Temperature Guard CM712 Manual And Installation Instructions

Hide thumbs

Advertisement

Quick Links

Model CM712
Manual and Installation Instructions

Advertisement

loading

Related Manuals for Temperature Guard CM712

Summary of Contents for Temperature Guard CM712

  • Page 1 Model CM712 Manual and Installation Instructions...

  • Page 2: Table Of Contents

    Index General Description Installation Programming with a Cell Phone Command Function Table Commands Explained 7-8, 10 Settings Table Programming with email Wiring Diagram Querying the CM712 Text Examples Limited Warranty...

  • Page 3: General Description

    The CM712 can send alarm condition text messages to four cell phones. Additional Features Configure the CM712 to send a daily status text at the time you spec- ify. All program settings can be password protected Sensors can be named to help identify the cause of the alarm.

  • Page 4: Installation

    Replace the cover, insert and tight the four screws. Plug in the power jack. Turn on the CM712 by sliding the power switch to the ON position. The CM712 will power up and register itself on the cell network. The green LED indicates the connection to the cellular network.

  • Page 5: Programming With A Cell Phone

    Programming with a Cell Phone Programming can be done with a cell phone or by email. This section only covers programming with a cell phone. It is recommended that you add the SIM number to your cell phone’s address book. It is recommended that you program the password last.
  • Page 6 Function Example Sets monitor to Celsius or Fahrenheit Units: Sets 1st phone number P1:8605551212 Sets 2nd phone number P2:8605552424 Sets 3rd phone number P3:8605553636 Sets 4th phone number P4:8605554848 UID: Names the monitor UID:Mountain Cabin Upper temp limit of internal sensor AU:85 Lower temp limit of internal sensor AL:35...

  • Page 7: Commands Explained 7

    Commands Explained In bold is the command, example in parenthesis. Units: (Units:C or Units:F) Unit is shipped in Fahrenheit. There is no ♦ need to use this command if you want degrees displayed in Fahrenheit. Changing from Fahrenheit to Celsius does not automatically change the limits.
  • Page 8 Freezer. CU: (CU:20) This example sets the upper limit of the external tempera- ♦ ture sensor 2 to 20 degrees. If the temperature were to exceed 20 de- grees for more than the programmed time limit, a text message would be sent.
  • Page 9 Default Setting Allowable Range Your Setting C or F Units: Empty 10 digit minimum Empty 10 digit minimum Empty 10 digit minimum Empty 10 digit minimum UID: Empty 10-16 characters -20to 120 -200 -20to 120 0-900 Internal Temp 2-16 characters AID: 10-95% 5-85%...
  • Page 10 Warning: The commands for PW: and CPW: must be in all caps! ♦ If you forget your password, the only way to clear it is to set the monitor back to factory defaults. That can only be done by turning the monitor off, pressing and holding the reset button, while turning it back on.

  • Page 11: Programming With Email

    Programming with email The monitor can be programmed with email in the same fashion as a text message with a few differences. When sending an email delete your signature line and any other extra characters attached to a generic email. Remember 160 characters max. Do not try to program every parameter in a single email.
  • Page 12 External Temp 1 UL 200F LL -200F T: 0 min External Temp 2 UL: 200F LL: -200F T: 0 min Room Temp UL 85F LL 33F T:2 Room Humidity UL 90% LL 10% T:10 Sent from: Mountain Cabin...

  • Page 13: Querying The Cm712

    Querying the CM712 ? (?) Simply sending a text message with a ? to the monitor’s ♦ cell number, a status message will be sent back to the phone it was sent from. Text will include readings from the external tem- perature sensors, internal sensor with humidity, door status, wa- ter status, and ID of the monitor.
  • Page 14 Text 1 Example Text 8 Example Units:C Pt:2 Wt:0 Rt:20 St:20 Text 2 Example Text 9 Example P1:8605551212 D1:1 P2:8605552323 1ID:Front Door P3:8605553434 P4:8605554545 Text 10 Example Text 3 Example D2:0 2ID:Server Rm. Door Uid:Vermont Office Text 11 Example Text 4 Example PW:23wF Au:75 al:35 at:2 Aid:Server Room...

  • Page 15: Limited Warranty

    Limited Warranty: 1. Warrantor: Dealer, Distributor, Retailer, and Manufacturer 2. Warranty and Remedy We believe that this is a high quality product. Although we test all products for proper functionality, we cannot guaranty that there will never be a defective unit, or that a unit will function everywhere due to poor cell coverage, and on all cell net- works.
  • Page 16 Microtechnologies, Inc. www.temperatureguard.com sales@temperatureguard.com support@temperatureguard.com Rev. 712 r6...
