  • Page 1 Mondo III Matrix Installation & Setup Guide...
  • Page 2 New Milford, CT 06776 USA This document and the Magenta Research products to which it relates, and the copyright in each, is the property of Magenta Research. Neither the document nor the products may be reproduced by any means, in whole or in part, without the prior written permission of Magenta Research.
  • Page 3 Magenta Research (New Milford CT USA) declares under our sole responsibility that the product Mondo III System to which this declaration relates is in conformity with the following standard(s) or other normative documents: EN 55022:1998/A1:2000/A2:2003 Class A ITE emissions requirements (EU AS/NZS).

  • Page 4: Table Of Contents

    MAGENTA MONDO MATRIX Contents Chapter Page 1. Specifications......…..............3 2. Overview & Design Guidelines…..…............4 3. Installation…………........… ........….14 4. Configuration………........… ........….18 5. Commands..................……..21 Mondo III SAP Design, Configuration, Usage........……..32 7. Troubleshooting…………………………………………………………………..35 Appendix A: Cable Pinouts..…………………………………………………………...36 Appendix B: Fan Filter Cleaning/Replacement……………………………………...39 Appendix C: Using the USB port on Mondo III SAP………………………………...40...

  • Page 5: Specifications

    RS 232 Serial: Serial signals are ported into the Mondo III Matrix via MultiView components or via a 3.5mm audio jack for simplex transmit in a Mondo Direct. Transmission is uni-directional broadcast in this mode. Mondo III SAP versions allow bi-directional serial sessions with individual receivers. There are 8 DB9 COM ports on each Mondo III SAP frame That can be used in conjunction with SAP enabled receivers for full bi-directional RS232 communication with the device attached to the receiver.

  • Page 6: Overview & Design Guidelines

    2.1 OverView The Mondo III Matrix CAT5 routing switch is a full matrix platform to easily distribute and route video, audio , and serial signals using the MultiView series of video over Cat5 products. It is available in configurations ranging from 16 inputs to 16 outputs up to 256 inputs to 512 outputs.
  • Page 7 When designing or installing a Mondo III system, the following should be adhered to: Equalize all Cat5 Input Cables to the Mondo III Matrix All Cat5 cable inputs should be as equal as possible between source transmitter and Mondo III Matrix switch (This does not apply to Mondo Direct inputs with VGA inputs).
  • Page 8 2.2 Design Guidelines, cont. Mondo III Matrix Sizing Mondo III Matrix frames are available in 16 output sizes. Inputs may vary from 1 to 64 in 16 port increments. To add outputs, frames are cascaded “vertically” in “rows”. To add inputs beyond the 64 input single frame limit, frames are cascaded “horizontally” in “columns”.
  • Page 9 CHAPTER 2: Overview/Design Guidelines 2.2 Design Guidelines, cont. Eight Frame Cascade Limit All inputs to the Mondo III are cascaded to subsequent frames via Cat5 cascade loop throughs on each input card. It is recommended to loop through no more than 8 frames or video performance may be affected beyond 8 frames.
  • Page 10 The master frame also requires to be re-initialized when a slave frame address is changed or added. This can be accomplished using the #I command or a power reset. Following are some examples of frame addressing based on specific Mondo III Matrix sizes. 64 input by 16 output single frame matrix switch.
  • Page 11 Use the following table to determine the correct address assignments and Input Output connections for each switch frame. Note that Mondo III addressing has changed from legacy Mondo systems. For legacy Mondo frame addressing, refer to previous Mondo Matrix user guides. Table 1: Mondo III Matrix Frame Addresses COL1: COL 2:...
  • Page 12 It is possible to breakout source input signals such as video, audio, or serial by utilizing the last input card cascade loop outs to the appropriate Magenta receiver. Note that these signals do not pass through the switch. Video Out...
  • Page 13 SAP mode offers the ability for bi-directional RS232 control of devices attached to SAP enabled receiver units. Reference Section 6, SAP Usage, for instructions on using SAP mode with the Mondo III Matrix. The Mondo III SAP option also features an additional USB control input that can be used with any serial terminal application on a PC.
  • Page 14 All commands are input via an RS232 serial port on the master frame via a third party control system such as Calypso Control Systems, Crestron, or AMX. A remote control panel, the Mondo TC touchscreen, is also available as a control option. Contact Magenta Research for details.
  • Page 15 2.2 Design Guidelines, cont. Front Panel Status Dashboard Each Mondo III frame features a front panel status panel that shows a frames current state with respect to power supply health, fan health, air filter service, internal frame temperature, system communications, and any alarm events.

  • Page 16: Installation

    3. Installation Install the Mondo III Matrix switch frames in a suitable rack fixture. The Mondo III Matrix is designed to install into a standard 19” wide cabinet. It is recommended to install all Mondo III Matrix hardware in a restricted access location such as a secure equipment room.
  • Page 17 3. Installation (cont) Depending on the version purchased, switch frames may have multiple sets of I/O Comm Ports. COM1 through COM8 are standard DB9 RS-232 interfaces that may be connected to a third party control system or the Mondo TC touch panel control unit (these COM ports need to be configured and set via the LCD for control mode.
  • Page 18 HD15 connectors. Ensure cables “click” securely into place. Connect Cat5 Output cables from Mondo III Matrix outputs to destination devices. Insert RJ45 cables gently — pushing too hard may damage connector pins. Ensure cables “click” securely into place.
  • Page 19 Adding Inputs beyond 64 Apply power to the Mondo III Matrix system. It is recommended that power is applied simultaneously to all switch frames. If this is not practical, then apply power to Slave switch frames first, then power up the Master switch frame.

  • Page 20: Configuration

    The following explains each setup screen as well as its possible values. After 10 seconds of inactivity within a setup screen, the Mondo III Matrix will exit setup mode and display the Default Status screen or a user defined status screen.
  • Page 21 This can be useful when multiple control points are used to control the Mondo III Matrix as a method to determine when a change has occurred. It is suggested to query the switch crosspoint status with the D, #D or #M commands after this event notification is received to update any control system menus.
  • Page 22 This can be useful when multiple control points are used to control the Mondo III Matrix as a method to determine when a change has occurred. It is suggested to query the switch crosspoint status with the D, #D or #M commands after this event notification is received to update any control system menus.

  • Page 23: Commands

    8-bit, No Parity, One Stop Bit No Handshaking is required Characters sent to the Mondo III Matrix are not echoed back to the controller. If using a simple terminal application, enable the local echo option. The Mondo III Matrix will reply with either “OK>“ (command accepted) or “ERxx>“ (error, command not recognized) after a command string is sent.
  • Page 24 MAGENTA MONDO MATRIX CHAPTER 5: Commands 5. Commands, cont. General Commands (cont): D = Displays entire crosspoint map of the system Displays format of xxx Vyyy A zzz Where xxx is output number, Vyyy is UTP pairs 1,2,3 and Azzz is UTP pair 4...
  • Page 25 5. Commands, cont. Standard Routing Commands: B = Both Video and Audio V = Video Only (UTP pairs 1,2,3) A = Audio Only (UTP pair 4) Parameters: xxx = Output yyy = Input (If yyy=0 then the output will be turned off) Note: Output (xxx) may be 1-3 digits, Input (yyy) may be 1-3 digits, however both must be the same number of digits (append leading zeros if required).
  • Page 26 MAGENTA MONDO MATRIX CHAPTER 5: Commands 5. Commands, cont. Salvo Routing Commands: X = Salvo Both Video and Audio Y = Salvo Video Only (UTP pairs 1,2,3) Z = Salvo Audio Only (UTP pair 4) Parameters: mmm = First Output in range...
  • Page 27 5. Commands, cont. Batch Routing Commands: E = Both Video and Audio F = Video Only (UTP pairs 1,2,3) G = Audio Only (UTP pair 4) EE = Take (Execute Batch Commands) Parameters: xxx = Output yyy = Input (If yyy=0 then the output will be turned off) Examples: Exxxyyy<CR>...
  • Page 28 MAGENTA MONDO MATRIX CHAPTER 5: Commands 5. Commands, cont. New Mondo III Matrix Reporting & Configuration Commands: The following commands are not supported in legacy Mondo systems. $GEO - System Geometry (M3) Read system geometry: Command: $GEO<CR> Response: xxx,yyy,ii,mm<LF><CR> OK><LF><CR>...
  • Page 29 5. Commands, cont. New Mondo III Matrix Reporting & Configuration Commands: $RFD - Report fan/filter data (M3) Report fan / filter data, all frames: Command: $RFD<CR> (One line for each frame) Response: frame,a,b,c,d,e<LF><CR> frame,a,b,c,d,e<LF><CR> OK><LF><CR> Report fan / filter data, one frame: Command: $RFDframe<CR>...
  • Page 30 MAGENTA MONDO MATRIX CHAPTER 5: Commands 5. Commands, cont. New Mondo III Matrix Reporting & Configuration Commands: $RST – Reset System, all frames (M3) Reset (soft): Command: $RST0<CR> Response: OK><LF><CR> (then system resets) Reset (hard): Command: $RST1<CR> Response: OK><LF><CR> (then system resets) Reset &...
  • Page 31 5. Commands, cont. Reporting/Configuration Commands: $LSF – Lock System Functions (M3) This command locks the serial ports from controlling the switch in a multi-user system. This is necessary so that significant switch configuration changes can all be accomplished without interruption by one user. An “unlock”...
  • Page 32 MAGENTA MONDO MATRIX CHAPTER 5: Commands 5. Commands, cont. Reporting/Configuration Commands: $RPS – Report Power Status (M3) Status of all frames: Command: $RPS<CR> Response: status info string<LF><CR> status info string<LF><CR> OK><LF><CR> Status of one frame: Command: $RPSframe<CR> Response: status info string<LF><CR>...
  • Page 33 5. Commands, cont. Reporting/Configuration Commands: $SPC – Serial Port Configuration (M3) For all baud-rates, the serial port data format is fixed at 8 data bit, no parity, 1 stop bit. Set port parameters: Command: $SPCf,n,b,x,m<CR> Response: OK><LF><CR> Read one port’s settings: Command: $SPCf,n<CR>...

  • Page 34: Mondo Iii Sap Design, Configuration, Usage

    MAGENTA MONDO MATRIX CHAPTER 6: Mondo III SAP Design, Configuration and Usage 6. Mondo III SAP Design, Configuration and Usage The Mondo III SAP option enables up to 8 serial COM ports on the Mondo Matrix to establish bi-directional serial sessions with SAP enabled receivers.
  • Page 35 Finally, it is important to know the actual Mondo III frame address that all SAP enabled COM ports are on as this information is required in order to issue the SAP port switch command to the Mondo III Matrix system.
  • Page 36 MAGENTA MONDO MATRIX CHAPTER 6: Mondo III SAP Design, Configuration and Usage 6. Mondo III SAP Design, Configuration and Usage (cont) Usage Guidelines: In order to use the Mondo III SAP option, first, the Mondo Matrix must be issued the SAP Control Command ($SCC) to switch the appropriate COM port to the appropriate Mondo Matrix output.

  • Page 37: Troubleshooting

    Mondo III Matrix is functioning (ensure “local echo” mode is enabled to see commands sent). In the case where a third party control application is used to control the Mondo III Matrix, please ensure serial connectivity using a simple terminal program such as Hyperterminal first, then check that the correct signal pins are connected to the Mondo III from the third party application.

  • Page 38: Appendix A: Cable Pinouts

    MAGENTA MONDO MATRIX Appendix A: Cable Pinouts Table A-1 RS 232 Control cable to Mondo III Switch Serial Input In a Mondo III system, only use this cable to connect a third party control system to the vertical 7 pin phoenix connector labeled 1-7.
  • Page 39 Appendix A: Cable Pinouts Appendix A: Cable Pinouts Table A-3. DB9 Female Serial connector (if installed) RS232 Ground Aux power * *Aux Power output is 5VDC at 100mA nominal. It is enabled via the Configuration LCD. Do not enable Aux Power on more than one COM port at a time. Table A-4.
  • Page 40 MAGENTA MONDO MATRIX Appendix A: Cable Pinouts Table A-5 Interframe control cable for legacy Mondo systems If using a Mondo III frame in an older system with legacy Mondo frames, It is re- quired to set the Mondo III frame to M2 Mode via the LCD, address it appropriately and use only the 7 pin phoenix connections for third party control and interframe communications.

  • Page 41: Appendix B: Fan Filter Cleaning/Replacement

    Appendix B: Filter Cleaning/Replacement Appendix B: Filter cleaning/replacement The Mondo III Matrix features filtered air cooling. A removable filter is located on the left side when facing the rear of the frame. This filter is easily removed by sliding out towards the rear.

  • Page 42: Appendix C: Using The Usb Port On Mondo Iii Sap

    Type B mini cable connected to a PC or laptop as well as a software driver file, MONDO3_USB.INF which is located on the CDROM shipped with the Mondo III System It can also be downloaded from http://www.magenta-research.com. To install the driver, follow the instructions below: 1.
  • Page 43 NOTES: 43 41...
  • Page 44 MAGENTA MONDO MATRIX Magenta Research 128 Litchfield Road, New Milford, CT 06776 USA (860) 210-0546 FAX (860) 210-1758 www.magenta-research.com PN: 5310218-01, rev 03, Jun 2011...
